4. Daisy-chaining Mode
DIP Switch (C-link
DIP)
5. Reset button
6. Operation mode DIP
switch
7. Serial (CONSOLE)
Port
8. Digital output
9. Breaker
error code and the number of Daisy-
chaining
Set the mode of Daisy-chaining for
iPoMan II-1200.
Auto mode: For the master iPoMan II-
1200, set all the DIP switches of the C-
link to ON by moving all the switches
downward; for all the other iPoMan II-
1200s (slave iPoMan IIs) in the Daisy
Chain, set all the DIP switches of the C-
link to OFF by moving all the switches
upward. After setting the DIP switches for
all the iPoMan II-1200s in the Daisy
Chain, the Daisy Chain ID can be assigned
for each iPoMan II-1200 automatically.
Manual mode: The Daisy Chain ID for all
iPoMan II-1200s is assigned by user
manually. Please refer to DIP Switch
Setting Table on page 21.
Enable you to reset the iPoMan II-1200 in
case the system locks up.
Set the mode of operation for the iPoMan
II-1200.
Default mode (S1 off, S2 off): Set the DIP
switches S1 and S2 to OFF by moving the
switches upward for normal operations.
Enable you to configure the iPoMan II-
1200 using the serial port. User can also
connect an optional EMD to this port.
Connect up to digital outputs that are
normally open or normally closed.
Prevent excessive current flow to protect
the system.
