- Page 1 PC/HD to DVI Format Converter Operation Manual CP-261D...
-
Page 2: Operation Controls And Functions
YPbPr. Use VGA to 3 RCA adaptor cable to connect between your source equipment and the CP-261D. - Set the switch to RGB when the output format of your source equipment is RGBHV. Use- HD-15 D-Sub VGA cable to connect between your source equipment and the CP-261D. -
Page 3: Specifications
Operation Controls and Functions 6. Output format switch: When the input is YPbPr set the switch to bypass for digital YPbPr out, set the switch to RGB for digital RGB out. When the input is RGB, set the switch to either position for the digital RGB out. There is no YPbPr out for RGB input. -
Page 4: Connection And Installation
DVI-I Pin Configuration DVI-Integrated(DVI-I): Supports both analog and digital connections to the display. This 29-pin connector can carry single or dual-link all-digital video/data signals on 24 pins and uses 5 pins to carry analog video/data signals and ground. 8 C1 C2 Combined Analog and Digital Connector Pin Assignments Pin Signal Assignment Pin Signal Assignment...
