  • Page 1 PC/HD With Audio to HDMI Format Converter Operation Manual CP-261H...

  • Page 2: Operation Controls And Functions

    - Set the switch to RGB when the output format of your source equipment is RGBHV. Use HD-15 D-Sub VGA cable to connect between your source equipment and the CP-261H. 2. HD-15 D-Sub input: Connects to PC or YPbPr output connector of your PC or YPbPr source equipment using VGA cable, or D-Sub to 3 RCA adaptor cable.

  • Page 3: Connection And Installation

    Specifications * Video Input: HD-15 (RGBHV/YPbPr) * Input signal: RGB: 0.7 Vp-p 75 ohm H + V: 3 to 5 Vp-p or Y :1 Vp-p 75 ohm, Pb/Pr:0.7 Vp-p, 75 ohm * Audio Input: Analog audio L,R * HDMI is compliant with HDMI 1.2 * Operation frequency: up to 165MHz * Input/Output resolution: PC：VGA@60、VGA@72、VGA@75、VGA@85...
