Viking VESC530-4B Installation Manual
Professional freestanding electric 30” range
Hide thumbs
Also See for VESC530-4B:
- User manual (26 pages) ,
- Install manual (12 pages) ,
- Installation manual (12 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Viking VESC530-4B
Summary of Contents for Viking VESC530-4B
- Page 1 Viking Installation Guide ® Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 or visit the Viking Web site at vikingrange.com Professional Freestanding 30” Electric Range F20508L EN (051513)
-
Page 2: Table Of Contents
Table of Contents IMPORTANT – Read and Follow! Warnings & Important Safety Instructions _______________________________________________3 • Before beginning, please read these Your safety and the safety of others is Dimensions _________________________________________________________________________6 instructions completely and carefully. very important. Specifications _______________________________________________________________________7 Clearance Dimensions (Proximity to Cabinets) ___________________________________________8 •... - Page 3 ELECTRICAL SHOCK any significant sources of water or moisture. HAZARD • Viking Range, LLC will NOT warranty any problems resulting from GFI outlets which are not To avoid risk of electrical installed properly or do not meet the requirements below.
-
Page 4: Dimensions
Dimensions Specifications Electric 30” Range Description VESC530-4B - 7 / ( 7 5 8 ” Overall width 29-7/8” (75.9 cm) Overall height To top of glass frame 35-7/8” (91.1 cm) min. 37” (94.0 cm) max. Legs adjust 1-1/8” (2.9 cm) Overall depth from To end of side panel—24-5/16”... -
Page 5: Clearance Dimensions (Proximity To Cabinets)
Clearance Dimensions Clearance Dimensions (Proximity to Cabinets) (Wood/Composite Overlay) • This range may be installed directly CAUTION adjacent to existing 36” (91.4 cm) high The bottom of a standard hood should be base cabinets. To prevent possible damage to cabinets and 30”... -
Page 6: Electrical Requirements
Electrical Requirements General Information Electrical Requirements • Viking Range, LLC will NOT warranty any problems resulting from GFI outlets which This product is manufactured with the READ AND FOLLOW ALL WARNING neutral terminal connected to the cabinet. are not installed properly or do not meet... -
Page 7: Installation
Leg Installation Installation CAUTION To avoid risk of personal injury or product damages, DO NOT use the handle or oven door to lift the oven. Remove door before installation to ensure that it is not used to lift the unit. DO NOT lift or carry the door by the handle. -
Page 8: Electrical Connection (3-Wire)
Electrical Connection (3-wire) Note: If you have a 4-wire connection, see following section for 4-wire connection instructions. WARNING WARNING Electrical shock hazard. Electrical shock hazard. To avoid risk or electrical To avoid risk of electrical shock, personal injury or shock, personal injury or death;... -
Page 9: Electrical Connection (4-Wire)
Electrical Connection (4-wire) WARNING WARNING Electrical shock hazard. Electrical shock hazard. To avoid risk or electrical To avoid risk of electrical shock, personal injury or shock, personal injury or death; grounding product to death; verify your appliance the frame of the unit may or may not has been properly grounded in be permitted through your local codes. -
Page 10: Leveling/Adjustments/Alignment
Leveling/Adjustments/Alignment Measure the four corners in cutout area to For uneven or sloped floors, level unit with Set the high corner of range so that the top of side trim is verify if flooring is level. metal shims only, as the adjustment required may 3/8”... -
Page 11: Final Installation
Anti-tip Device Installation Door Replacement and Adjustment (cont.) Reattach door to range. Open door completely. Reattach hinge trim. Attach bracket with mounting hardware provided. Final Installation Note: Refer to range electrical requirements section for proper installation information. Remove pins from hole in hinges. Close door. -
Page 12: Final Preparation
If buildup occurs, DO NOT use steel wool, knife, spatula, or any other material tool to Contact Viking Range, LLC, 1-888-845-4641, for the nearest service parts distributor in your abrasive cloths, cleansers, or powders! scrape stainless steel! Scratches are almost...
