Microscan MINI Hawk User Manual page 245

10 Camera and IP Setup
Contents
Camera and IP Setup by ESP .................................................................................................... 10-2
Camera and IP Setup Serial Commands.................................................................................... 10-3
Video........................................................................................................................................... 10-4
Evaluation ................................................................................................................................... 10-5
Calibration................................................................................................................................... 10-8
Window of Interest ...................................................................................................................... 10-9
Configuration Database ............................................................................................................ 10-13
Dynamic Setup ......................................................................................................................... 10-14
X-Mode™.................................................................................................................................. 10-15
Pixel Sub-Sampling .................................................................................................................. 10-16
Camera Settings ....................................................................................................................... 10-18
Camera Settings (3 Megapixel) ................................................................................................ 10-19
Focal Distance .......................................................................................................................... 10-20
Focal Distance (3 Megapixel) ................................................................................................... 10-21
Focal Distance Table (Read-Only) ........................................................................................... 10-22
Focal Distance Table (Read-Only) (3 Megapixel)..................................................................... 10-23
Increment Focus Position ......................................................................................................... 10-24
Decrement Focus Position........................................................................................................ 10-24
Increment Focus Position (3 Megapixel) .................................................................................. 10-25
Decrement Focus Position (3 Megapixel)................................................................................. 10-25
Illumination Brightness.............................................................................................................. 10-26
Color Filter ................................................................................................................................ 10-27
Skew Correction ....................................................................................................................... 10-28
Morphological Pre-Processing.................................................................................................. 10-31
Morphological Operation and Operator Size ............................................................................ 10-32
This section provides adjustment parameters for the physical controls of the camera,
image acquisition, database settings, and image diagnostics.
MINI Hawk High Performance Imager User's Manual
10-1
