SENKO P 7 AIR Instruction Manual
  1. Manuals
  2. Brands
  3. SENKO Manuals
  4. Indoor Fireplace
  5. P 7 AIR
  6. Instruction manual

SENKO P 7 AIR Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

PELLET STOVES
P 7 AIR  7 kW
P 10 AIR  10 kW
SN-EN-7/15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P 7 AIR and is the answer not in the manual?

Questions and answers

Related Manuals for SENKO P 7 AIR

Summary of Contents for SENKO P 7 AIR

  • Page 1 PELLET STOVES P 7 AIR  7 kW P 10 AIR  10 kW SN-EN-7/15...
  • Page 2 Dear client, thank you for choosing a SENKO pellet stove! This product was designed and manufactured to its minutest details in order to fulfil your every need for functionality and safety. This Instruction manual will teach you to operate your stove properly, so please read the manual carefully before using the stove.

  • Page 3: Table Of Contents

    5.7. OPERATING MODE ……………………........38 5.7.1. MANUAL MODE (MANU) ............39 5.7.2. AUTOMATIC MODE (AUTO) ……………………..………….......40 5.7.3. ECO MODE (ECO) ...............41 5.7.4. WARM AIR FAN (FAN) ..............42 5.8. ADVANCED FUNCTIONS ……………….…...….…..42 5.8.1. AUTOMATIC SHUT DOWN (SLEEP) SENKO pellet AIR stoves – Instruction manual...
  • Page 4 ............60 6.12. ELECTRONIC COMPONENTS 7. MALFUNCTIONS / CAUSES / SOLUTIONS ........62 8. TECHNICAL SUPPORT ..............64 9. TECHNICAL DATA ................65 10. TERMS OF WARRANTY ..............66 WARRANTY SHEET .................67 INSTALLATION REPORT .................68 CE MARKING ....................69 SENKO pellet AIR stoves – Instruction manual...

  • Page 5: General

    The external appearance of the stove is shown on the first page of this Manual. When ordering the stove or the spare parts, it is necessary to state its full designation, for example: E 2402 P 7 AIR, colour PC-3. SIDE WALL COLOUR PALETTE : ...
  • Page 6 J) PVC feet with screw; K) Instruction manual. CAUTION ! The stove weighs over 120 kg. Extra caution is necessary when unloading, transferring, moving and installing the stove in order to avoid physical injury. SENKO pellet AIR stoves – Instruction manual...

  • Page 7: Warnings And Safety

    1. WARNINGS AND SAFETY SENKO pellet stoves are constructed in accordance with all the security measures prescribed by EN 14785:2006 norm. Attention paid to every stove component assures safety from potential accidents for both the user and the fitter. Our recommendations:...
  • Page 8 EN 14961-2, Ö-Norm M 7135, DIN 51731 or ENplus-A1. It is also necessary to mention:  All stoves before shipment may be activated and tested.  Children and infirm individuals are not allowed to handle the stove. SENKO pellet AIR stoves – Instruction manual...
  • Page 9 Also ensure appropriate fire extinguishers and/or call the local fire department.  If you lose this Manual, you can get a copy from SENKO Company or its authorized representative. You can also find it at http://en.senko.hr/.

  • Page 10: Safety Devices

    1.1. SAFETY DEVICES SENKO pellet stove consists of the following safety devices:  Motherboard  intervenes directly and activates the alarm until the stove completely cools off in operating conditions which deviate from the pre-set safety conditions;  Fuse  protects the stove from sudden changes in electricity voltage (max.6,3 A and 250 V) ;...

  • Page 11: Pellets

    Pellets must be stored in dry conditions!  Use of low quality pellets or any other fuel adversely affects the functionality of your stove and can result in void warranty and annulment of manufacturer responsibility! SENKO pellet AIR stoves – Instruction manual...

  • Page 12: Technical Features

    3. TECHNICAL FEATURES SENKO pellet stove AIR was constructed for the purpose of heating residential buildings, but also to serve as a piece of decorative element in any surroundings. Stove centre and load bearing construction are made from steel sheets.

  • Page 13: Installation

    4. INSTALLATION 4.1. RECOMMENDATIONS Figure 3 SENKO pellet AIR stoves – Instruction manual...
  • Page 14 500 mm from the side wall PELLET 800 mm from the front grid STOVE 500 mm floor protection 300 mm (measured from the maximum angle of firebox door opening ) Table 2 FLOOR PROTECTION Figure 4 RADIATION AREA SENKO pellet AIR stoves – Instruction manual...
  • Page 15 (max 3 + inspection and cleaning T-piece) and chimney horizontal parts (max total 3 m with a 3-5 % incline)  see 4.5. Connection to chimney. SENKO pellet AIR stoves – Instruction manual...

  • Page 16: Proper Installations

    When the afore mentioned devices are located in the adjoining rooms, which are in contact with the room where SENKO pellet stove is installed, it is forbidden to use these devices simultaneously in cases where there is a risk that underpressure will occur in one of the two rooms with regards to the other.
  • Page 17 If the air necessary for Figure 7 combustion is sucked via pipes directly from external environment, round pipe 90° downward incline must be installed outside, equipped with a protective grid, due to birds and potential accidental clogging. SENKO pellet AIR stoves – Instruction manual...

  • Page 18: Connecting To Chimney

    It is forbidden to use flexible pipes which are not made from acid-resistant material when connecting the stove with the chimney, even if the channels already exist. SENKO pellet AIR stoves – Instruction manual...
  • Page 19 H – reduction from Ø80 to Ø100 mm J – maintenance and cleaning opening K – maintenance and cleaning hatch L – T-piece with maintenance and cleaning opening M – fresh external air supply grid SENKO pellet AIR stoves – Instruction manual...
  • Page 20 IT IS NOT RECOMMENDED TO USE THE 90° ELBOW AS THE FIRST ELEMENT OF THE INSTALLATION SINCE THE ASH MIGHT QUICKLY CLOG THE SMOKE VENTING SPACE AND CAUSE PROBLEMS IN STOVE AND CHIMNEY SENKO pellet AIR stoves – Instruction manual FUNCTIONING!
  • Page 21 1 linear metre. CAUTION! DO NOT CONNECT the smoke venting pipe to a common smoke venting pipe used for other heat generators (water heaters, fireplaces, cookers and similar)  see figure 12. SENKO pellet AIR stoves – Instruction manual...
  • Page 22 Steel sheet with closed chamber Properly stove connection to the chimney max 3 mt 3-5° Insulated T- connection with T-connection T-connection inspection with inspection with inspection hatch hatch hatch Figure 12 SENKO pellet AIR stoves – Instruction manual...

  • Page 23: Chimney

    Be connected vertically and with a decline from the axis up to 45°;  Be appropriately physically removed from flammable materials by air-filled spaces or appropriately insulated; Figure 13 soot deposits soot deposits SENKO pellet AIR stoves – Instruction manual...

  • Page 24: Chimney Preparation And Control

    The chimney must be at least 0,5 meters removed above the roof ridge. The chimney must be smooth on the inside, well insulated and well fastened. All cleaning hatches must be well fastened. All gaskets must be regularly inspected and replaced when necessary. SENKO pellet AIR stoves – Instruction manual...

  • Page 25: Chimney Cap

    4.5.4. CHIMNEY CAP Chimney cap must meet the following requirements:  identical internal cross- section to that of the chimney,  operational exit cross- section no less than the double inner cross-section of the chimney, SENKO pellet AIR stoves – Instruction manual...
  • Page 26 1,3 m from the roof < 1,3 0,5 m above the roof ridge 45° > 1,3 2 m from the roof < 1,2 0,5 m above the roof ridge 60° > 1,2 2,6 m from the roof SENKO pellet AIR stoves – Instruction manual...

  • Page 27: Chimney Function

    UNDERPRESSURE Figure 16 from the stove The wind also influences the chimney function indirectly by creating areas of high (overpressure) and low (underpressure) pressure, both inside and outside the residential area (figure 17). SENKO pellet AIR stoves – Instruction manual...

  • Page 28: Handling The Stove

     Do not touch the surfaces because they still may be unstable;  Ventilate the room several times;  This stove must not be used for waste incineration. SENKO pellet AIR stoves – Instruction manual...
  • Page 29 After longer periods of inactivity, all pellet residues must be vacuumed from the tank due to the fact that they can absorb water which alters their original properties, making them unsuitable for combustion and transport to the firebox. SENKO pellet AIR stoves – Instruction manual...

  • Page 30: Loading The Pellets

    KEY: 1 – parameter selection and alteration (MODE, ESC, MANU / AUTO) 2 – parameter selection and alteration (-) 3 – parameter selection and alteration (MENU, OK) 4 – parameter selection and alteration (+) 5 – ON/OFF (turning on / turning off) SENKO pellet AIR stoves – Instruction manual...
  • Page 31  Should you, in any menu, shortly press key 5 (on/off), START display will automatically appear on your screen (display of stove operating status) without saving any changes not confirmed by „OK“ key. SENKO pellet AIR stoves – Instruction manual...

  • Page 32: Remote Control

    (as shown in figure 21) on the back side of the remote control and change the battery in accordance with the symbols displayed on it. 3V Lithium CR2025 battery is used in the remote control. SENKO pellet AIR stoves – Instruction manual...

  • Page 33: Before First Switching On

    (figure 22). Every 4 seconds the initial screen switches with another screen which, in the bottom line, indicates the type of stove currently stored in the main memory (P 7 AIR or P 10 AIR). During switching between these two displays, the backlight is maximally maintained and pressing any key will have no effect.
  • Page 34 „Eco“ active Eco is active* Alarm conditions active Warnings** * this notification is displayed only if the ECO option is enabled ** this notification is displayed only if at least one alarm is active SENKO pellet AIR stoves – Instruction manual...
  • Page 35 5. Turning on / turning off key (ON/OFF) returns the display to START screen. Mode:AUTO Menu Mode:MANU Menu Temp:23°C Fan:A Fire:5 Fan:4 23°C esc █ █ █ █ █ Temperature Fire Figure 25 SENKO pellet AIR stoves – Instruction manual...

  • Page 36: Date And Time Menu

    < Day Number > Should you not press any key within 10 seconds, the < Month > display returns to START screen without saving the changes! 2015 < Year > SENKO pellet AIR stoves – Instruction manual...

  • Page 37: Ignition / Shut Down

    If, after reactivation (after 15 minutes), the pellets are not yet ignited, check whether the burner pot is properly set. The burner pot must completely adhere to its casing and must not contain any ash. SENKO pellet AIR stoves – Instruction manual...
  • Page 38 < Charge Pellet > after that turn of dosage by pressing key 1 (esc) and return to START screen Charge Pellet Figure 28 23.0°C 10:23 Abilitation Charge Pellet SENKO pellet AIR stoves – Instruction manual...

  • Page 39: Operating Mode

    (figure 30). If the system is in automatic mode, pressing the upper left key (Mode) will change the mode into manual (MANU). Mode:MANU Menu Fire:2 Fan:3 Figure 30 SENKO pellet AIR stoves – Instruction manual...

  • Page 40: Automatic Mode (Auto)

    After each ignition, the stove returns to the operating mode selected before the last shut down ! SENKO pellet AIR stoves – Instruction manual...

  • Page 41: Eco Mode (Eco)

    (IGNITION → ON) and continues to operate until reaching 20°C. If the temperature, measured by the probe, is maintained above the set SENKO pellet AIR stoves – Instruction manual...

  • Page 42: Warm Air Fan (Fan)

     it is not recommended to set fan speed smaller than the set heating power !  otherwise, it comes to stove overheating and damage on the electronics. The ultimate consequence is loss of warranty on the product ! SENKO pellet AIR stoves – Instruction manual...

  • Page 43: Advanced Functions

    This function allows you to set 6 different on/off daily schedules. Each schedule can be assigned to one or more days of the week, which ensures a very flexible and easily adjustable weekly schedule which suits all your needs. SENKO pellet AIR stoves – Instruction manual...
  • Page 44 CHRONO function programmed (activated) deactivated whether the stove is in OFF-state or in ON-state!  If you have activated any of the Programmes, Chrono prog. will appear on the control panel START screen! SENKO pellet AIR stoves – Instruction manual...
  • Page 45 P1 Enable >  for the Chrono function to work, needs only programmed, but also activated < P1 Enable > (ENABLE) as shown in figure 34 23.0°C 10:41 < Enable > Chrono Prog. SENKO pellet AIR stoves – Instruction manual...

  • Page 46: Weekly Profiles

    You can see the selection procedure in figure 35, and the list of available pre-set default profiles in table 9. Figure 35 < Chrono > < Load Profile > Table 9 SENKO pellet AIR stoves – Instruction manual...

  • Page 47: Settings

    Backlight option enables you to set the time and the used level of backlight on the START screen. If you choose ON, the screen will be lighted all the time; other data set the time interval in which the backlight is reduced. SENKO pellet AIR stoves – Instruction manual...

  • Page 48: Pellet Feeder Correction (Pellet Recipe)

    The problems can be subdivided into two categories: INSUFFICIENT FUEL  the stove is not capable of developing suitable flame which is weak even when the stove is set to maximum heating power SENKO pellet AIR stoves – Instruction manual...
  • Page 49 +5 → +25%  for 25% more dosage  EXCESSIVE FUEL: use the same principle as in case of insufficient fuel, with the difference of reducing the dosage for a certain percentage (max. 25% lesser dosage)! SENKO pellet AIR stoves – Instruction manual...

  • Page 50: Pellet Feeder Filling (Charge Pellet)

    The bottom line of the menu indicates the denomination of the displayed value. Arrow keys allow browsing through various data in the menu. The following table lists different data in the menu in order of their appearance with their available values. SENKO pellet AIR stoves – Instruction manual...

  • Page 51: Alarms

    If you press the Info key longer than 5 seconds, while the alarm screen is displayed, you access the main menu where you can correct the potential errors. SENKO pellet AIR stoves – Instruction manual...
  • Page 52 Fumes Over-Temperature see Instruction manual stove body overheating let the stove cool down to the stove operating on maximum power too stove can be reactivated after resetting the alarm long or is poorly SENKO pellet AIR stoves – Instruction manual...
  • Page 53 Pellet Feeder Error Contact an authorized technician Electronic Motherboard - let the stove cool down to the end Error - reduce the stove heating power or increase the he warm air ventilator motherboard speed overheating SENKO pellet AIR stoves – Instruction manual...

  • Page 54: Cleaning And Maintenance

    Should you, during burner pot feeding phase, notice that apart from pellets, a lot of sawdust and dust is falling into the burner pot, you must clean the pellet tank as soon as possible. Otherwise, dangerous backfire SENKO pellet AIR stoves – Instruction manual...

  • Page 55: Heat Exchanger

    Should you try to clean during regular stove operation, it is possible for the lever to get stuck due to material dilatation effect. Also, the lever is hot during regular stove operation so there is danger of burns. SENKO pellet AIR stoves – Instruction manual...

  • Page 56: Ash Pan

    Perform the procedure with a vacuum cleaner with a container, only if the ash is cold. Figure 39 Once you have performed the cleaning, properly put the ash pan back into the casing frame ! SENKO pellet AIR stoves – Instruction manual...

  • Page 57: Door Glass

    Use a soft cloth with neutral cleaning liquid for cleaning. Never use metallic sponges and/or similar sponges, lest you damage the surface ! PAINTED OR ENAMELED SURFACES DO NOT CLEAN WITH ABRASIVE CLEANING AGENTS ! SENKO pellet AIR stoves – Instruction manual...

  • Page 58: Pellet Tank

    Unscrew the bolts to remove the plate located under the firebox. Use the vacuum cleaner to clean the combustion residues accumulated at the bottom of the channel. Figure 42 SENKO pellet AIR stoves – Instruction manual...
  • Page 59 Figure 43 In places where it was silicone sealant, it is necessary to put the After cleaning, it is necessary to assemble everything in new one (heat-resistant) to ensure SENKO pellet AIR stoves – Instruction manual reverse order. a good seal!

  • Page 60: Output Flue Gas Channel

    It is important to enable free circulation of air around the igniter, which prevents the igniter from burning out. igniter tube SENKO pellet AIR stoves – Instruction manual...

  • Page 61: Electronic Components

    (max 6,3A and 250 V). In that case, it is necessary to replace it by using the screwdriver to pull out the plastic part in the centre of the switch and to remove the fuse (figure 46). Figure 46 SENKO pellet AIR stoves – Instruction manual...
  • Page 62 Recommended cleaning and maintenance intervals of SENKO pellet stoves are listed in the following table. Table 15 CLEANING AND MAINTENANCE INTERVAL PART 1 day 1 year days days  Burner pot  Heat exchanger  Ash pan  Door glass ...

  • Page 63: Malfunctions / Causes / Solutions

    50 mm) shuts down  combustion air  check the igniter and replace it if necessary supply inadequate  when electricity is restored, the  pellet igniter stove will be cooled down and malfunctioning SENKO pellet AIR stoves – Instruction manual...
  • Page 64  Procedures marked with bold must only be executed by personnel authorized by the manufacturer!  Manufacturer bears no responsibility in case of failure to adhere with these procedures! SENKO pellet AIR stoves – Instruction manual...

  • Page 65: Technical Support

     warranty (at the back of this Manual),  written installation report (at the back of this Manual)  Instruction manual. The documents listed above are necessary to ensure the quickest and clearest removal of the occurring malfunction! SENKO pellet AIR stoves – Instruction manual...

  • Page 66: Technical Data

    Technical specifications refer to use of pellets with calorific value of 4,9 kWh/kg Technical specifications are indicative and variable as such. The manufacturer reserves the right to alter any technical specification for the purposes of product improvement SENKO pellet AIR stoves – Instruction manual...

  • Page 67: Terms Of Warranty

    10. TERMS OF WARRANTY These terms of warranty are valid in all European countries where SENKO products are sold. The client addresses the vendor or the nearest authorized servicing agent for all complaints; providing the purchase receipt with the date of purchase, warranty sheet and installation report in the process.

  • Page 68: Warranty Sheet

    _____________________________ _________________________ _________________________ Servicing agency comments: Servicing agency comments: _____________________________ _____________________________ _________________________ _________________________ Servicing completed: Servicing completed: __________________________ __________________________ date date Stamp and servicing technician Stamp and servicing technician signature: ____________________ signature: ____________________ SENKO pellet AIR stoves – Instruction manual...

  • Page 69: Installation Report

    Height (m): ……………………….. Underpressure (Pa): …………. Flue gases exit temperature (°C): ………… Last inspection date: ……………… Connection number: ………………. Smoke venting pipe ( if connected Cross-section (mm): …………….. Length (m): …………… Number of elbows: ………..SENKO kamini – Uputstvo za upotrebu...

  • Page 70: Ce Marking

    Produced in the EU DECLARATION OF CONFORMITY These products are certified in accordance with the EN 14785. Test reports number 30-12031-T-4 (P 7 AIR) and 30-12031-T-5 (P 10 AIR) from July 11 , 2014. The original product Certificates and Declarations of Performance available upon request.
  • Page 71 NOTES : ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ________________________________ SENKO kamini – Uputstvo za upotrebu...
  • Page 72 A HEALTHY ENVIRONMENT. You can find this Manual at http://en.senko.hr/ If you have any suggestions on how to improve this Manual or you have noticed any deficiency, feel free to contact us on tehnologija@senko.hr SN-EN-7/15 SENKO kamini – Uputstvo za upotrebu...

This manual is also suitable for:

P 10 air

Table of Contents
