4: Operation
7. Pull the UPS module forwards until the rear connectors are disconnected. DO NOT FULLY EXTRACT THE UNIT.
WARNING: Wait at least 2 minutes to allow the module's electrolytic capacitors time to discharge.
8. After waiting two minutes, fully withdraw the UPS-Module from the cabinet by pulling it horizontally.
9. If you are not intending to replace the UPS module immediately, cover the UPS compartment opening with an
appropriate protection cover and secure with four screws.

4.4.2 Inserting a UPS module

Key Point: The replacement module must be preset according to system personalization. Please make sure
with your nearest service centre for correct settings.
1. Remove the UPS module compartment protection cover (if fitted) by unscrewing four screws on the front.
2. Using two persons to lift the UPS module, slide two thirds of the module into the UPS-compartment (make sure not to
plug the UPS-Module into the rear connector).
3. Push UPS-module firmly into its final position, to assure good contact on the rear plugs.
4. Tighten the four screws on the front of module to secure it to the UPS cabinet / frame.
5. Connect the control panel cable to connector JD7.
6. Start the UPS module and bring it on line (see paragraph 4.2.2).
4.5

Replacing a module in a CAPACITY multi-module system

WARNING: All the operations in this section must be performed by authorised and trained personnel. By
opening or removing the UPS modules and module covers you run risk of exposure to dangerous voltages!
WARNING: When removing a UPS module wait for at least 2 minutes after it has been disconnected in
order to allow the DC Capacitors to fully discharge.
WARNING: When the UPS module is removed from the cabinet always fit an appropriate blanking cover.
WARNING: Two persons are needed to pull out the module from the UPS Frame. The weight of a DPA 50,
40kW module is 60kg. Employ suitable lifting aids and safety platforms where possible.
If a UPS module fails and there is not enough capacity left to protect the load by the remaining operating UPS modules,
the load will automatically transfer to the (static) bypass and continue to be supplied from the mains supply.
