Specifications - General ASHA07LACM Service Manual

SPECIFICATI ON S
INDOOR UNIT
ELECTRICAL DATA
TYPE
INDOOR UNIT
COOLING CAPACITY
HEATING CAPACITY
MOISTURE REMOVAL
AIR CIRCULATION HIGH
FAN MOTOR
POWER SOURCE
Discrimination
High
FAN SPEED
Middle
( cool / heat )
Low
Quiet
NOISE LEVEL
HIGH
QUIET
MEASUREMENT
DIMENSIONS H x W x D
Gross / Net
WEIGHT
2007.05.14
ASHA07LACM ASHA09LACM
2.3 kW
2.7 kW
0.8 L/hr
500 m3/hr 550 m3/hr
1,140 / 1,140 r.p.m. 1,220 / 1,220 r.p.m.
1,000 / 1,050 r.p.m. 1,060 / 1,110 r.p.m.
880 / 980 r.p.m. 900 / 1,040 r.p.m.
700 / 800 r.p.m. 720 / 830 r.p.m.
35 dB(A)
21 dB(A)
www.enindel.com
COOL & HEAT
ASHA12LACM
2.7 kW 3.5 kW
3.3 kW 4.0 kW
1.0 L/hr 1.2 L/hr
580 m3/hr
230 V
MFD-34ROM
1,280 / 1,320 r.p.m.
1,100 / 1,180 r.p.m.
900 / 1,080 r.p.m.
750 / 860 r.p.m.
38 dB(A) 39 dB(A)
22 dB(A) 23 dB(A)
275 x 790 x 215 mm
12 kg / 9 kg
1
ASHA14LACM ASHA18LACM
4.2 kW
4.8 kW
1.4 L/hr
700 m3/hr
1,480 / 1,480 r.p.m. 1,480 / 1,480 r.p.m.
1,250 / 1,250 r.p.m. 1,250 / 1,250 r.p.m.
1,050 / 1,100 r.p.m. 1,100 / 1,100 r.p.m.
850 / 950 r.p.m. 950 / 950 r.p.m.
45 dB(A)
26 dB(A)
5.0 kW
6.0 kW
2.0 L/hr
700 m3/hr
45 dB(A)
28 dB(A)
