Vicon VC2430B Installation & Operation Manual

1/3-inch monochrome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
X894-10
MODEL VC2430B
1/3-INCH MONOCHROME CAMERA
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: +44 (0) 1489 566300
WEB: www.vicon-cctv.com
Vicon part number 8006-8894-10-00
Rev 107 Section 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC2430B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vicon VC2430B

Summary of Contents for Vicon VC2430B

  • Page 1 X894-10 MODEL VC2430B 1/3-INCH MONOCHROME CAMERA VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788 TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116 24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: +44 (0) 1489 566300 WEB: www.vicon-cctv.com Vicon part number 8006-8894-10-00...
  • Page 5 To prevent fire or shock hazard, do not expose the unit WARNING to rain or moisture. The symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the unit. The symbol is intended to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 6 PRECAUTIONS 1. Do not attempt to disassemble the camera. In order to prevent electric shock, do not remove screws or cover. There are no user-serviceable parts inside. 2. Handle the camera with care. The camera could be damaged by improper handling or storage. 3.

  • Page 7: Packing List

    PACKING LIST 1. Iris lens connector plug for DC drive – 1pc 2. C-Mount lens adaptor ring – 1pc 3. Dust protective cap - 1pc 4. Manual – 1pc...

  • Page 8: Connectors And Controls

    CONNECTORS AND CONTROLS...
  • Page 9 CONNECTORS AND CONTROLS ① Video Output Connector (BNC) 1.0 V p-p/75Ω composite video signal is provided at this connector. ② Power Input Connector (screw terminal) This terminal accepts 12 VDC or 24 VAC power source. Power Requirement: Maximum 200 mA (12 VDC), Maximum 100 mA (12 VDC) Recommended Power Supply: Minimum 500 mA (12 VDC);...
  • Page 10 CONNECTORS AND CONTROLS ④ Autoiris Lens Connector for DC Drive Lens This connector supplies the control signals to the DC drive autoiris lens. When using a DC drive lens, the ELC/ALC switch (pole 1) on the DIP switch must be set to the ALC (OFF) position.
  • Page 11 CONNECTORS AND CONTROLS ELC/ALC Select Switch (EE/ELC is ON; ALC/AI is OFF) This switch is used to select EE (electronic exposure)/ELC (electronic light control) mode or AI (autoiris lens)/ALC (automatic light control) mode. Pole 1 is set to ON for EE/ELC and OFF for AI/ALC. In the EE/ELC mode, a continuously variable electronic shutter is employed to automatically control the exposure time of the CCD image sensor according to the incoming light level.
  • Page 12 CONNECTORS AND CONTROLS AGC ON/OFF Switch This switch is provided for the AGC circuit. The AGC circuit incorporated into the camera boosts the sensitivity automatically when the scene illumination is insufficient. INT/LL Switch (LL is ON; INT is OFF) This camera can operate independently, using its internal crystal-controlled sync generator, or it may be synchronized using line-locking.
  • Page 13 CONNECTORS AND CONTROLS 1. While observing the video output signals from both cameras on an oscilloscope, turn camera A's V-phase control (on back of camera) “ V-phase” control until vertical sync from both cameras are in phase. (variable resistor) 2. If camera A's adjustment range is insufficient, adjust camera B's V-phase control in the opposite direction to camera A until they are in phase.
  • Page 14 CONNECTORS AND CONTROLS ⑪ ALC Level Adjustment Potentiometer for DC Drive Lens This potentiometer is used only if the camera is fitted with a DC drive autoiris lens. It is used to control the amount of light striking the CCD image sensor. LENS-IRIS level control LEVEL Monitor Screen...
  • Page 15 CONNECTORS AND CONTROLS ⑬ Backfocus Adjustment Screw This screw is used to position the CCD image sensor at the precise point of focus of the lens. Backfocusing Fixed-Focal-Length Lenses 1. Install a lens and connect the camera to a monitor and power supply as described in this manual.
  • Page 16 CONNECTORS AND CONTROLS ⑭ C-Mount Adaptor Ring The C-mount adaptor ring is used only if a C-mount lens is used on the camera. If a CS-mount lens is used, the adaptor is not necessary. To install the adaptor, first screw it into the lens mount opening on the camera. Then screw the C-mount lens into the adaptor.

  • Page 17: Examples Of Connections

    EXAMPLES OF CONNECTIONS 1. Simplest : One monitor system with one camera 2. One monitor system with two or more cameras...
  • Page 18 DIMENSIONS...

  • Page 19: Specifications

    SPECIFICATIONS VC2430B VC2430B-C MODEL TV SYSTEM CCIR EFFECTIVE PIXELS 768(H) X 494(V) 752(H) X 582(V) IMAGE DEVICE 1/3” INTERLINE TRANSFER CCD SCANNING SYSTEM 2:1 INTERLACE SYNCHRONIZING SYSTEM INTERNAL/LINE LOCK SELECTABLE HORIZONTAL RESOLUTION 580 TV LINE VIDEO OUTPUT LEVEL 1 V pp/75 ohm...

  • Page 20: Shipping Instructions

    Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.

  • Page 21: Coaxial Cable Recommendations

    Coaxial Cable Recommendations Caution: Careful selection of proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended, or equivalent, are installed. In all cases, coaxial cable impedance should be 75 ohms.
  • Page 22 Notes...

  • Page 23: Vicon Standard Equipment Warranty

    Software supplied either separately or in hardware is furnished on an “As Is” basis. Vicon does not warrant that such software shall be error (bug) free. Software support via telephone, if provided at no cost, may be discontinued at any time without notice at Vicon’s sole discretion.
  • Page 24 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office Planet II - Unit E...
