OWNER'S MANUAL
ARP- 3012
PORTABLE AIR CONDITIONER
ACONDICIONADOR DE AIRE PORTÁTIL
Read and retain these instructions for future reference
For any Customer Support needs please
choose the Customer Support tab on
www.royalsovereign.com
Royal Centurian Inc.

Advertisement

loading

  Also See for Royal Sovereign ARP-3012

Royal Sovereign ARP-3010 Owner's Manual
Royal Sovereign ARP-3010 Owner's Manual 32 pages
Royal Sovereign ARP-3010 Owner's Manual
Royal Sovereign ARP-3010 Owner's Manual 32 pages

  Related Manuals for Royal Sovereign ARP-3012

  Summary of Contents for Royal Sovereign ARP-3012

  • Page 1 OWNER’S MANUAL ARP- 3012 PORTABLE AIR CONDITIONER ACONDICIONADOR DE AIRE PORTÁTIL Read and retain these instructions for future reference For any Customer Support needs please choose the Customer Support tab on www.royalsovereign.com Royal Centurian Inc.

  • Page 2: Electrical Specifications

    PORTABLE AIR CONDITIONER Model ARP-3012 INTRODUCTION Thank you for choosing this air conditioner to provide you and your family with all of the "Home Comfort" requirements for your home, apartment, or office. This appliance can be moved from room to room and set-up in just minutes.
  • Page 3 ARP-3012 WARNING Improper handling can cause serious damage to the appliance. Read this manual carefully before operating the unit. Do not wet the Do not cover the Do not allow housing or control air outlet while in children to play panel.

  • Page 4: Description Of Components

    DESCRIPTION OF COMPONENTS 1. Air Outlet(Up -Down) 6. Screen filter 2. Control Panel 7. Air intake (Evaporator) 3. Front panel 8. Air intake (Condenser) 4. Handle 9. Air outlet (Heat exchange) 5. Casters 10.Water drain with plug...

  • Page 5: Installation Instructions

    ARP-3012 INSTALLATION INSTRUCTIONS Connect exhaust hose assembly to the back of the unit. Extend hose to desired length and locate the exhaust nozzle through a window or wall for ventilation. EXHAUST ASSEMBLY AND INSTALLATION Window spacer Exhaust nozzle connector Exhaust hose Exhaust hose connector 1.

  • Page 6: Operation

    OPERATION Control panel Power Control Warning Light Display Fan Speed Control Mode Control Timer / Temp Set Control POWER CONTROL The power control turns the unit on and off. WARNING CONTROL Condensed water may accumulate in the unit . If the internal tank becomes full, the Warning Light will shine and the unit will not operate until the unit has been drained.
  • Page 7 ARP- 3012 DEHUMIDIFY MODE When dehumidify mode is selected, the indicator light will shine green. Air is dehumidified as it passes through the unit, without being in full Cooling mode.The fan will operate in Medium speed. Fan speed is not adjustable in Dehumidify mode. NOTE: The air exchange hoses must vent inside the room when using Dehumidify mode.
  • Page 8 OPERATION Air Conditioner Remote Control TIMER PROGRAMMING The functions work the same as your air conditioner's touch controls. 1. Press the button on the remote or the "Timer Setting" button on the control panel to turn on the Timer Function. 2.

  • Page 9: Troubleshooting

    ARP-3012 TROUBLESHOOTING The following cases may not always be a malfunction. Please check it before asking for srvice. Analysis Trouble If the protector strip or fuse is blown: Please wait for 3 minutes and start again, protector device may be Does not run preventing unit from working.

  • Page 10: Appliance Maintenance

    TROUBLESHOOTING Appliance maintenance 1. Cut off the power supply 2. Wipe with a soft and dry cloth 3. Never use volatile substance 4. Never sprinkle water onto Turn off the appliance first Use lukewarm water to clean such as gasoline or polishing the main unit.

  • Page 11: Specifications

    ARP-3012 ARP-1000ES SPECIFICATIONS Figures noted are for reference only; variation may result due to application in different countries or regions, and shall be based on the best of practical operation. Description of product Air Conditioner Model ARP-3012 Voltage / Frequency...
  • Page 12 This warranty is in lieu of any and all expressed warranties. In no event shall Royal Sovereign be liable for consequential or incidental damages. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
