DESCRIPTION OF COMPONENTS

2
3
1. Air Outlet(Up -Down)
2. Control Panel
3. Front panel
4. Handle
5. Casters
1
6
4
7
8
5
6. Screen filter
7. Air intake (Evaporator)
8. Air intake (Condenser)
9. Air outlet (Heat exchange)
10.Water drain with plug
4
9
10
