Page 1 Easy Educator EZ-900 Quick Start Guide E-Collar Technologies, Inc.
Page 2 Welcome Thank you for trusting us with your purchase of the 900 Easy Educator Remote Education Collar. We have made every attempt to provide you with the most technologically advanced product using the most stringent quality and manufacturing standards. We are confident you will be pleased with the results you will attain with the 900 Easy Educator.
Page 3: Table Of Contents
TABLE OF CONTENTS Characteristics Package Contents Turning ON/OFF the EZ-900 System / Charging Instructions EZ-900 Functions LCD Display 1 Dog Mode Buttons Descriptions and Stimulation Button Assignments I Mode / Lock and Unlock Stimulation Level Booster Level Setup / Lost Transmitter Activation EZ-900 One Dog Default Settings Expand to Two Dog Pairing...
Page 4: Characteristics
CHARACTERISTICS 1/2 mile Range Employs Quick Charge Li-Polymer Batteries Convenient Intensity Dial for Quick Adjustment Stimulation Levels Adjustable from 0 to 100 Collar Receiver Light for Night Tracking “Lock and Set” Stimulation Safety Feature User Adjustable Boosting Levels Patented “I” Mode Provides Instant Stimulation Waterproof and Shock Resistant Easily Expandable to 2 Dogs...
Page 5: Package Contents
PACKAGE CONTENTS Ergonomic Transmitter Waterproof Collar Quick Start Owner’s Receiver High Quality - Remote-Sender Guide Biothane Strap Easy Educator EZ-900 Quick Start Guide E-Collar Technologies, Inc. Test Light Contact Point Tool 5/8” and ¾” Contact Points Lanyard Battery Charger...
Page 6: Turning On/Off The Ez-900 System / Charging Instructions
T urning ON/OFF the EZ-900 System Turn ON/OFF the transmitter by pressing the lower right button for 1 second. Turn ON/OFF the collar receiver by placing the red dot on the transmitter on the red dot on the collar receiver for 1 second. Charging Instructions Please charge the units on or before the low battery indication.
Page 7: Ez-900 Functions
EZ-900 Functions Easy Educator 900 provides 5 types of stimulation sensations, tone, and vibration. Stimulation Icon Function Description Momentary Stimulation Send momentary stimulation (volume level) Send momentary boosting stimulation Momentary Boost Stimulation (volume + boost Level) Send continuous stimulation Continuous Stimulation (max 10 sec, volume level) Sends continuous boosting stimulation Continuous Boost Stimulation...
Page 8: Lcd Display 1 Dog Mode
LCD DISPLAY 1 DOG Mode Icon Description Remarks Momentary Stimulation Short Pulse of Stimulation Momentary Boost Stimulation Short Pulse of Boosted Stimulation Continuous Stimulation Up To 10 Seconds of Stimulation　 Continuous Boost Stimulation Up to 10 Seconds of Boosted Stimulation Stimulation Level Displayed on the LCD, Instant Stimulation Mode Must Start From “0”...
Page 9: Buttons Descriptions And Stimulation Button Assignments
Buttons Descriptions and Stimulation Button Assignments The 900 Easy Educator has 4 control buttons which are assigned to stimulation, vibration and tone. It also has 2 program buttons for changing modes (P) and turning the unit ON and OFF. The convenient dial provides for easy and sight free control of the stimulation level.
Page 10 Program Function Description Buttons Press more than 1 sec to turn ON Power ON/OFF Press more than 2 sec to turn OFF ON/OFF Press ON/OFF quickly to activate Light Night Light Toggles (Blinking → Solid → OFF) Press more than 1 sec to Volume Lock Lock/Unlock Stimulation Level Stimulation Lock Level...
Page 11: I Mode / Lock And Unlock Stimulation Level 1
I Mode / Lock and Unlock Stimulation Level “I” Instant Stimulation Mode “I” Instant Stimulation Mode The "I" mode is a patented feature which allows the stimulation to increase gradually as determined by the user. The gradual introduction of stimulation provides a more gentle sensation and removes the startling effect sometimes associated with applying a constant level of stimulation.
Page 12 Lock and Unlock Stimulation Level Lock and Unlock Stimulation Level * Important Note: Blinking “1D” Indicates Unlocked Stimulation / * Important Note: Blinking “1D” Indicates Unlocked Stimulation / Solid “1D” Indicates Locked Stimulation Solid “1D” Indicates Locked Stimulation 1. Set the desired stimulation level to be locked by rotating volume dial. 2.
Page 13: Booster Level Setup / Lost Transmitter Activation 1
Booster Level Setup / Lost Transmitter Activation Booster Level Setup 1. Change the mode of any S button to Momentary if not already programmed to “M” mode. 2. Change the Stimulation level to “0” (Stimulation level should be unlocked) 3. Press Momentary button for more than 5 sec and enter into Booster Level Change Mode.
Page 14: Ez-900 One Dog Default Settings
EZ-900 One Dog Default Settings Factory default setting of EZ-900 is as below. You can change Tone Mode, Vibration Mode, and Instant Mode by using computer interface tool which can be downloaded at http://www.ecollar.com http://www.ecollar.com Factory Default Setting S1-Button Momentary S2-Button Continuous S3-Button...
Page 15 Pairing/Syncing When you change transmitters or collar receivers they will need to paired/ synced to each other for them to communicate with each other. Pairing/Syncing (ON/OFF + S3) 1. Turn on the Transmitter. 2. Rotate the intensity dial to “0”. 3.
Page 16: Expand To Two Dog
Expand to Two Dog (Press On/Off+S3+S4 for 5 sec) EZ-900 can be easily expanded to two dog EZ-902. When you purchase additional Collar Receiver,you can change EZ-900 Transmitter to operate lke an EZ-902, see website for owner's manual. 1. Rotate the intensity dial to “0”. 2.
Page 17: Warranty And Registration
WARRANTY AND REGISTRATION To register your Pro Educator please select one of the following procedures (1) Go to the “Products” section on www.ecollar.com www.ecollar.com and click the “Register Your e-Collar Products” tab and complete the form (2) Fill out the provided warranty registration card and mail it or fax it to us at 1-855-226-5527.
Page 18: Contact Information
International : 001-260-357-0051 www.ecollar.com sales@ecollar.com customerservice@ecollar.com This product is covered by various patents including but not limited to patents 8757098 and 8833309. Patent is pending on the Instant Stimulation Feature on this device. Copyright 2014 E-Collar Technologies, Inc. All Rights Reserved.
Page 19: Important Notice
IMPORTANT NOTICE About Contact Points: Many dogs in our modern society have developed sensitivity to nickel which is a metal in all stainless steel products. Keep a watchful eye on your dogs skin where the contact points are touching his/her skin for redness or any signs of irritation. This should be done hourly at first and slowly transition to once every four hours after a month of daily wearing of the e-collar.
Page 20 E-Collar Technologies, Inc. 2120 Forrest Park Drive Garrett, IN 46738-9471 1-260-357-0051 (US & Internationa) 1-855-326-5527 (US Toll Free) 1-855-226-5527 (US Toll Free Fax) sales@ecollar.com www.ecollar.com...
