Inno Pocket Fusion
DNST
- This mode can be used as a precaution mode, that
in case the DMX signal is lost, the operating mode chosen in
the setup is the running mode the fixture will go into when
the DMX signal is lost. You can also set this as the operat-
ing mode you would like the unit to return to when power is
applied.
1. Press the MENU button until "DNST" is displayed, press
ENTER.
2. Either "MAST" or "LAST" will be displayed. Choose an oper-
ating mode you would like the unit to start up in when power is
applied or the DMX signal is lost.
• MAST (Master Slave) - If the DMX signal is lost or power is
applied, the unit will automatically go into Master Slave mode.
• LAST (Last State) - If the DMX signal is lost the fixture will stay
in the last DMX set up. If power is applied and this mode is set,
the unit will automatically go into the last DMX set up.
3. Press ENTER to confirm your desired set up
DIND -
In this mode you can select the dimmer curve.
1. Press the MENU button until "DIND" is displayed, press
ENTER.
2. The current dimmer curve setting will be displayed.
3. Press the UP or DOWN buttons to find your desired dimmer
curve and press ENTER to confirm. See the Dimmer Curve Chart
on page 30 for more information.
PINT -
Pan Inversion
1. Press the MENU button until "PINT" is displayed, press
ENTER. Either Yes or No will be displayed.
2. To activate the Pan inversion press the UP or DOWN buttons
ADJ Products, LLC - www.adj.com - Inno Pocket Fusion Instruction Manual Page 14
System Menu Inno Pocket Fusion
until YES is displayed, press ENTER to confim. To deactivate
Pan inversion, select NO and press Enter.
TINT -
1. Press the MENU button until "TINT" is displayed, press
ENTER. Either YES or NO will be displayed.
2. To activate the Tilt inversion press the UP or DOWN buttons
until YES is displayed, press ENTER to confim. To deactivate
Tilt inversion, select NO and press Enter.
LED -
turn off after 10 seconds.
1. Press the MENU button until "LED" is displayed, press
ENTER.
2. The display will show either "ON" or "OFF". Press the UP or
DOWN buttons to select "ON" to keep the LED display on at
all times, or "OFF" to switch to have the LED display switch off
after 10 seconds.
3. Press ENTER to confirm. To make the LED display reappear
after it has turned off, press any button.
DISP -
1. Press the either the MENU button until "DISP" is displayed,
press ENTER.
2. Press the UP button to select "DSIP" to "flip" the display, or
"DISP" to change the display back.
3. Press ENTER to confirm.
TEST
program will test pan/tilt movement and colors.
Tilt Inversion
With this function you can have the LED display
This function will reverse the display 180º.
- This function will run a self test program. The test
ADJ Products, LLC - www.adj.com - Inno Pocket Fusion Instruction Manual Page 15
