Specifications

CPU
Chipset
Extra Chips
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
2
• LGA1155 socket for Intel
Core TM i3/Pentium
• DMI 5.0GT/s
®
• Supports Intel Active Management Technology
®
• Supports Intel Virtualization Technology
®
• Supports Intel Trusted Execution Technology
®
• Supports Intel Anti-Theft Technology
• 4 Phase Thermal Design Power
• VRD 12.0
• Supports DirectX 11.1 graphic core
®
• Supports Intel Turbo Boost 2.0 Technology
®
• Supports Intel Hyper-Threading Technology
®
• Intel Q77 Chipset
®
• Supports Intel
®
• Supports Intel Smart Connect Technology
®
• Supports Intel Rapid Start Technology
• NUVOTON NPCT420AA0WX TPM IC
• Dual-channel DDR3 memory architecture
• 2 x 204-pin DDR3 SO-DIMM sockets support up to 16 GB
• Supports DDR3 1600/1333 MHz DDR3 SDRAM
• 2 x mini PCI Express x1 slots
(the PCIE1 supports half-card, the PCIE2 supports full-card and
you can install a Mini SATA (mSATA) card into it)
• Supported by Intel
- 2 x Serial ATA 6Gb/s devices
- RAID 0/1/5/10 Configuration
• Realtek ALC662
- 2 Channel High Definition Audio Codec
- Compliant with HD audio specification
• Intel 82579LM Gigabit LAN
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• 1 x HDMI port
• 1 x Display port (DP)
• 1 x 19V DC_IN port
• 1 x RJ45 LAN connector
• 4 x USB 3.0 ports
• 1 x Audio port (1 x line-out, 1 x Microphone)
Q77H2-TI USER MANUAL
®
3 rd Generation Core
® ®
/Celeron processors
Small Business Advantage
®
Q77 Express Chipset
TM vPro i7/i5 and
