Rotary Hammer

HANDLING INSTRUCTIONS

Original Instructions
Before using this XINPU Rotary hammer, please carefully read though these
HANDLING INSTRUCTIONS. Ensure that you know how the machine works, and how it
should be operated. Maintain the machine in accordance with the instructions, and make
certain that the machine work correctly, please store this instriation and other enclosed
documents with the machine together.
106, No. 330 National Road, Huajie Industrial Zone, Yongkang City, Zhejiang 321300, P. R. China
Zhejiang Xinpu Industrial & Commercial Co., Ltd.
Model: XP-R30VA
Bj:2013
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XP-R30VA and is the answer not in the manual?

Questions and answers

Related Manuals for Xinpu XP-R30VA

Summary of Contents for Xinpu XP-R30VA

  • Page 1: Handling Instructions

    HANDLING INSTRUCTIONS Original Instructions Before using this XINPU Rotary hammer, please carefully read though these HANDLING INSTRUCTIONS. Ensure that you know how the machine works, and how it should be operated. Maintain the machine in accordance with the instructions, and make certain that the machine work correctly, please store this instriation and other enclosed documents with the machine together.

  • Page 3: General Power Tool Safety Warnings

    Drill bit Part of SDS plus shank Turn Staff Armor Flex Sheath Power source Indicator and carbon brushes Indicator Speed Adjuster Knob locked Pushbutton Function Knob Cover (10) Orientation Staff Guage (11) Papilionaceous Short Bolt (12) Core bit (13) Core bit shank (14) Drill bit (15)
  • Page 4 c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. 2) Electrical safety a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
  • Page 5 4) Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not(use the power tool if the switch does not turn it on and off.

  • Page 6: Safety Instructions

    Waste electrical products should not be disposed of with house hold waste, Please recycle where facilities exist. Check with your local Authority or retailer for recycling advice. SPECIFICATIONS Model No XP-R30VA Product No 8 8018 009 Voltage 220-240V...

  • Page 7: Standard Accessories

    STANDARD ACCESSORIES (1) Carbon Brush (6*10*14mm) …… …………………………………………….. 1 (2) Hammer grease ……………………………………… ……………………… 1 (3) Auxiliary handle…………………………………………………………………1 (4) Staff Guage……………………………………….…………………….………...1 Standard accessories are subject to change without notice. OPTIONAL ACCESSORIES (sold separately) 1. Through-hole drilling (Rotation + Hammering) (1) Drill bit (SDS-plus shank) Outer diameter (mm) Overall length(mm ) 2.

  • Page 8: Operation

    APPLICATIONS ○ Drilling holes in concrete ○ Drilling anchor holes ○ Crushing concrete, chipping, digging, and squaring (by applying optional accessories) OPERATION 1. Power source Ensure that the power source to be utilized conforms to the power requirements specified on the product nameplate.
  • Page 9 HOW TO USE THE ROTARY HAMMER CAUTION: To prevent accidents, make sure to turn the switch off and disconnect the plug from the receptacle when the drill bits and other various parts are installed or removed. The power switch should also be turned off during a work break and after work.

  • Page 10: How To Replace Grease

    4. Install the Orientation Staff Guage (Fig.6) (1) Loosen the papilionaceous short bolt on the auxiliary handle, and insert the staff gauge into the mounting hole on the side handle. (2) Adjust the staff gauge position according to the depth of the hole and tighten the papilionaceous short bolt securely.

  • Page 11: Maintenance And Inspection

    Faulty and /or discarded electrical or electronic apparatus have to be collected at the appropriate recycling location. CAUTION: Repair, modification and inspection of XINPU Power tools must be must be carried out by a XINPU Authorized Service Center. In the operation and maintenance of power tools, the safety regulations and standards prescribed in...
  • Page 12 XINPU Power Tools are constantly being improved and modified to incorporate the latest technological advancements. Accordingly, some parts (i.e. code numbers and/or design) may be changed without prior notice. NOTE: Due XINPU’s continuing program of research and development, the specifications herein are subject to change without prior notice.
