You can control how much the source affects the destination by dialing in
a specific modulation amount with the
lation amount can either be positive or negative.
Use Poly Mod to create complex harmonic effects ranging from FM
(frequency modulation) to audio-rate filter modulation and beyond. Many
classic sounds on the original Prophet-5 were created through clever use
of Poly Mod.

Poly Mod Parameters

Selects the amount of modulation from the Filter Envelope
Filter Env:
that is applied to a selected destination. Modulation amount can be either
positive or negative.
Selects the amount of modulation from Oscillator 2 that is applied
Osc 2:
to a selected destination. Modulation amount can be either positive or
negative.
When using
affected by the waveshape currently chosen for Oscillator 2 (triangle, sawtooth, or
square/pulse). Try setting Oscillator 2 to low frequency (using the
further increase modulation possibilities.
Selects Oscillator 1 frequency as a modulation destination.
Freq 1:
Choose as a modulation source to produce FM effects with their
2
osc
characteristic complex harmonics and metallic timbre.
Selects the Oscillator 1 waveshape as a modulation destination.
Shape 1:
This can animate the timbre of Oscillator 1 in interesting ways.
When Oscillator 1 is set to pulse wave, choosing this as a destina-
PW 1:
tion modulates its pulse width. This will animate the timbre of Oscillator 1
in interesting ways.
Selects the Low-Pass Filter cutoff frequency as a modulation
LP Filter:
destination.
Selects the High-Pass Filter cutoff frequency as a modulation destination.
HP Filter:
34 Poly Mod
as a modulation source, the modulation character is
2
osc
or
filter env osc
Dave Smith Instruments
knobs. Modu-
2
switch) to
low freq
