7 . Stereo/Mono: Ste, Mon (Stereo, Mono)—
stereo operation. When set to Mono, this parameter defeats all pan settings
and modulation, effectively making each of the outputs a mono output.
8 . Pgm Dump: Prg, Ten, Ban, usr, All (Program, Tens, Bank, User
Transmits the current program, ten programs from the
Banks, All)—
currently selected bank and tens location, the current bank, all user
banks (0-4), or all banks (both user and factory) in SysEx format via the
selected MIDI port. (See: "MIDI Sysex.") Dumped programs will load
back into the same bank and program location in memory when received by
the Prophet-6 via MIDI.

Oscillators

Oscillators provide the raw building blocks of the Prophet-6's sound by
producing waveforms, each of which has its own inherent sound charac-
ter based on its harmonic content. The Prophet-6 has two oscillators, plus
a sub oscillator and a noise generator per voice. Level controls for each
of these are located in the Mixer section.
Each oscillator is capable of generating triangle, sawtooth, and variable-
width pulse waves. These waveshapes are continuously variable and
smoothly transition from one shape to the next as you turn the
knob. This provides a variety of "in-between" waveshapes.
The oscillators on the Prophet-6 are extremely stable. To emulate the random
pitch drift and oscillator instability of vintage instruments, use the
dial in as little or as much drift as you like.
FREQUENCY
FREQUENCY
Oscillators 1 and 2
Prophet-6 Operation Manual
OSCILLATOR 1
SYNC
SHAPE
OSCILLATOR 2
FINE SHAPE
The Prophet-6 defaults to
PULSE WIDTH
LOW FREQ
PULSE WIDTH
shape
parameter to
slop
SLOP
AMOUNT OSC 1
KEYBOARD
SUB OCTAVE
Oscillators
MIXER
OS
NO
15
