Stirling STR-SSAC12000 Instruction Manual

Stirling STR-SSAC12000 Instruction Manual

Reverse cycle inverter split system air conditioner
Hide thumbs Also See for STR-SSAC12000:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
PROTECT YOUR WARRANTY
This unit must be installed by a registered,
licensed installer as required by
Government regulations.
Reverse Cycle Inverter
Split System Air Conditioner
Model Number STR-SSAC12000
INSTRUCTION MANUAL
IM Version No: V1.1
Issue Date: 01 October 2015
AFTER SALES SUPPORT
info@tempo.org
AUS
1300 886 649
MODEL: STR-SSAC12000 PRODUCT CODE : 51673 12/2015
