Summary of Contents for VPI Nomad
- Page 1 VPI Nomad Turntable Manual Setup and Instruction Manual VPI Industries, Inc., 77 Cliffwood Ave. #5D, Cliffwood, NJ 07721 http://www.vpiindustries.com...
- Page 2 Nomad Turntable Packing List Serial #:________________ Nomad Chassis Cartridge Installed Instruction Manual Drive Belt Power Supply Platter Tonearm Date: __________ Final Check by: ____________________...
-
Page 3: Nomad Specifications
NOMAD SPECIFICATIONS: Type Belt drive (manual turntable) Motor 24 VAC Synchronous AC Motor Turntable Platter Machined MDF Diameter 11.81" (30.0 cm) Turntable Speeds 33-1/3 RPM and 45 RPM Wow and Flutter 0.06% WOW (In accordance with DIN specification) 0.04% Flutter (In accordance with DIN specification) Rumble <-80dB (IEC 98A Unweighted) -
Page 4: Important: Read Before Proceeding
Save all packing materials. The Nomad should only be moved or shipped in its original packaging to reduce the risk of damage in transit. The Nomad must be placed on a flat, level surface. This will make setup easy, provide better sound quality, and put less strain on the main bearing. SAFETY INSTRUCTIONS: Follow the instructions below to reduce risk of electrical hazard or injury. - Page 5 7. Verify the turntable is level by using a 9 or 12-inch bubble level front-to-back and side-to-side on the platter. If it is not level, rotate the aluminum cone feet up or down. If you must turn the Nomad feet more than three full turns, level the shelf or platform the table sits on first.
-
Page 6: Changing Speeds
You may adjust azimuth by loosening the side screws and turning the armtube. CHANGING SPEEDS: The VPI Nomad comes with a two speed pulley, 33 and 45. To adjust the speeds simply move the belt from one pulley groove to another. -
Page 7: Playing Records
PLAYING RECORDS Make sure the VPI slip mat that comes standard with the Nomad is secure. If using headphones, plug your headphones into the headphone amplifier located in the front left of the Nomad. Be sure to set your volume at a preferred level before listening. - Page 8 VPI Industries, Inc. (VPI) warrants this unit against defects in materials and/or workmanship for one(1)) year from the date of purchase by the original retail purchaser. VPI’s sole obligation under this warranty is limited to the repair or replacement, at VPI’s option, of any part(s) found to be defective. VPI’s obligation to repair or replace defective parts is the purchaser’s sole and exclusive remedy, and VPI shall not be...
