1 Device Framework

1.1 Port Name

Note:
The framework figures in this chapter are just for reference, there is some minor difference
between the appearance of products and the corresponding figures, so please refer to the actual
products.
You can refer to the following figures for
Please refer to the following sheet for detailed information about port function.
SN Port Port Name
Audio output
AUDIO
1
OUT port
Audio input
2 AUDIO IN
port
port information. See Figure 1-1
Figure 1-1
Figure 1-2
Connector Function Note
Output audio signal to the speakers and other
RCA
devices.
Input audio signal, receive analog audio signal
from
RCA
pickup and other devices.
and Figure 1-2.
1
