- Page 1 Dahua HD Pinhole Network Camera Quick Start Guide Dahua HD Pinhole Network Camera Quick Start Guide Version 1.0.0 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.
-
Page 2: Important Safeguards And Warnings
Welcome Thank you for purchasing our network cameras. This user’s manual is designed to be a reference tool for using your product. Please read the following safeguards and warnings carefully before you use this series product. Please keep this user’s manual well for future reference. Important Safeguards and Warnings Electrical safety ... - Page 3 Operation and Daily Maintenance Do not directly touch the heat dissipation component of the device to avoid scald. Do not dismantle the device because there is no component that can be fixed by users themselves. Otherwise, it might cause water leakage or bad image due to unprofessional dismantling.
-
Page 4: Regulatory Information
Do not provide two or more power supply sources for the device; otherwise it might damage the device. Disclaimer This manual is for reference only. Please refer to the actual product for more details. Minor differences might be found in user interface, and there might be deviation between the actual value of some data and the value provided in the manual due to the reasons such as the real environment is not stable. - Page 5 Note Please refer to the disk for more details, check and download the corresponding user’s manual and tool. Before installation, please open the package and check all the components are included. Contact your local retailer as soon as possible if something is broken in your package. Accessory Name Amount Accessory Name...
-
Page 6: Table Of Contents
Table of Contents 1 Device Framework ........................17 1.1 External Cable ........................17 1.2 Dimension ......................... 19 2 Device Installation ........................20 3 Network Configuration ......................24 3.1 Device Initialization ......................24 3.2 Modify IP Address ......................26 3.3 Login WEB Interface ......................26... -
Page 7: Device Framework
1 Device Framework 1.1 External Cable Note The following structure figures are for reference only. They are only used to know the functions of structure components and cable ports. There might be some minor differences between different devices, so please refer ... - Page 8 Port Port name connector Function description Audio output Output audio signal to the speakers and other 3.5mm AUDIO port devices. Audio input Input audio signal, receive analog audio signal 3.5mm AUDIO IN port from pickup and other devices. Micro SD Micro SD Micro SD card storage.
-
Page 9: Dimension
Port name Cable port name Function description Alarm output port 1, output alarm signal to alarm device. Alarm output port 2 (reserved). Table 1-2 1.2 Dimension Refer to Figure 1-4 for the dimension of Model A. The unit is mm (inch). Figure 1-4 Refer to Figure 1-5 for the dimension of Model B. -
Page 10: Device Installation
Refer to Figure 1-7 for the dimension of Model D. The unit is mm (inch). Figure 1-7 Refer to Figure 1-8 for the dimension of Model E. The unit is mm (inch). Figure 1-8 2 Device Installation The device is detachable, which means both front and rear part of the device need to be installed respectively. - Page 11 Figure 2-1 To install the back-end box, do the following: Stick installation position map to the mounting surface where you will install the device. Dig holes according to the hole sites marked on installation position map. Open accessories bag, take out expansion bolts and insert them into the holes you just dug.
- Page 12 Figure 2-2 Take out mounting bracket from the packing box (with mounting foam), tear off the foam membrane and stick it on the mounting surface. Put the front lens into the mounting bracket and then lock the self-tapping screw firmly. Tighten the rotation ring firmly.
- Page 13 Step 3 Installation for model F and G. Please select installation mode according to the actual situation. Note It needs to implement the following step when the device is model F or G. Figure 2-4 Use self-tapping screws to fix the mounting bracket on the mounting surface.
-
Page 14: Network Configuration
Step 2 Connect alarm output device to the alarm output port of I/O port cable. N1 and C1 or N2 and C2 form a switch, which is shown in Figure 2-6, the switch is used to provide alarm output. Generally the switch is opened; the switch will be closed when there is alarm output. - Page 15 Click to enter the interface where you can modify IP address, click Search Setting, the system will display the Setting dialog box. Step 3 Set the device network segment, login user name and password, and then click OK. The system will display the searched devices after searching completes.
-
Page 16: Modify Ip Address
3.2 Modify IP Address Step 1 Double click "ConfigTool.exe" and open quick config tool. Step 2 Click to enter the interface where you can modify IP address, click Search Setting, the system will display the Setting dialog box. Step 3 Set the device network segment, login user name and password, and then click OK. - Page 17 For the first login, click Click Here to Download Plug-in, install controls according to system prompt. The main interface will be shown in Figure 3-3 after control installation is completed. Figure 3-3 Zhejiang Dahua Vision Technology Co., Ltd Address：No.1199 Bin’an Road, Binjiang District, Hangzhou, PRC. Postcode: 310053...
