Page 1: Care And Handling
AMPLIFIER 40.0 OPERATION MANUAL RCA/YL LEFT XLR/GN RIGHT BIAS INPUT 40.0 C O D A T E C H N O L O G I E S I N C . PRECISION BIAS AB AMPLIFIER SAFETY PRECAUTIONS INTRODUCTION INITIAL SETUP... -
Page 2: Safety Precautions
SAFETY PRECAUTIONS CAUTION CAUTION WARNING WARNING CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. THIS SYMBOL IS TO ALERT YOU OF THE PRESENCE OF UNINSULATED DANGER- OUS VOLTAGE WITHIN THE UNIT'S ENCLOSURE THAT MAY BE OF SUFFI- CIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK. - Page 3 INTRODUCTION Thank you for purchasing the AMPLIFIER 40.0. This ampli er is a precision device, designed in an e ort to provide the listener with unmatched sound quality through superb design and construction. Although its operation is fairly simple, in order to operate your ampli er properly and to realize all of the capabilites of the ampli er we recommend that you read this entire manual carefully.
-
Page 4: Initial Setup
Connecting or disconnecting cables while the ampli er is powered on could cause damage to your speakers. The diagram below shows the default connections necessary to operate the 40.0 as a stereo ampli er. This is the simplest and most common mode of operation, and the quickest way to get started. -
Page 5: Detailed Installation
AC input, is set to the appropriate voltage for your country. When changing voltages, ensure that the power cable is disconnected from the amplifier. NOTE: If the fuse in your amplifier blows, contact a Coda dealer or call Coda directly before attempting to use the amplifier again. - Page 6 PRECISION BIAS AB AMPLIFIER BIAS INPUT 40.0 C O D A T E C H N O L O G I E S I N C . PRECISION BIAS AB AMPLIFIER Note: If a power interruption occurs to the system the ampli er will power on with the...
- Page 7 See the next page for a diagram of a stereo ampli er con guration using two bridged mode 40.0 ampli ers. Speaker terminals in the diagram are marked with their bridged mode polarities.
- Page 8 DETAILED INSTALLATION IV. BRIDGED SETUP DIAGRAM...
- Page 9 Coda factory for reprogramming. If you are programming your remote for use with other devices and are unsure if you are going to interfere with Coda programming, contact us at the phone number or email address on the back of this manual.
-
Page 10: Design Philosophy
The subtlety of the design process at this level of performance makes it impossible to easily explain all of the advantages inherent in the 40.0. However, we present here an overview to give you an understanding of some of its unique features and an idea of the listening experience you can expect. - Page 11 Coda. As with all high-power ampli ers, heat dissipation is important. The 40.0 uses six massive aluminum heat sinks without fans for e cient, noiseless, and clean thermal relief. The thermal coe cient of the 40.0 heat sinks is one of the lowest and most e ective in the audio industry.
- Page 12 DESIGN PHILOSOPHY II. Material Quality The amplifier’s chassis is made from machined aluminum. All exterior metal parts are anodized or powder coated for durability. Printed circuit boards are fiberglass epoxy with gold plating over a tin/nickel barrier. The gold layer will not corrode, while the barrier layer prevents the gold from migrating to the lower copper layer.
-
Page 13: Technical Data
TECHNICAL DATA STEREO Rated Power: 400 Watts class AB @ 8 Ohms, 800 Watts class AB @ 4 Ohms Frequency Response: DC to -3dB @ 100kHz Distortion: < .02 percent from 10Hz to 20kHz @ rated power Gain: 26dB Maximum Current: >100 Amperes peak per channel Noise: -120dB referenced to rated output... -
Page 14: Care And Handling
CARE AND HANDLING The interior of the amplifier requires no special care. If exterior cleaning beyond simple dusting is required, any dilute ammonia-based product is recommended. Do not use any abrasive rags, cleaners or chemical solvents on the amplifier. When handling the amplifier, take care not to mar the faceplate. Aluminum is a medium hardness metal and can be scratched by harder tool steels, and the grained surface can be easily marred if the amplifier is set face-down on a hard surface. -
Page 15: Warranty And Disclaimer
Products purchased outside of the United States will be covered by the those given above. iii. Exclusion of Coverage - Coda Technologies is not obligated to service the product in certain conditions, as according to the following subsections. a. The product has been damaged through: i. -
Page 16: Warranty Registration
WARRANTY REGISTRATION Fill in this registration sheet and fax or mail it to Coda Technologies to ensure you are in our warranty system. This will facilitate warranty service should it become necessary. It is recommended that you retain a copy of this form for your own records. - Page 17 WARRANTY REGISTRATION Fill in this registration sheet and fax or mail it to Coda Technologies to ensure you are in our warranty system. This will facilitate warranty service should it become necessary. It is recommended that you retain a copy of this form for your own records.
- Page 18 7850 CUCAMONGA AVENUE #34 SACRAMENTO, CA 95826 USA +01 916.383.3653 +01 916.455.3653 phone CODA.CC on the web at info@coda.cc email us at...
