  • Page 1 Stereo Preampli er OPERATION MANUAL 07x PREAMPLIFIER BALANCE 1 BALANCE 2 DISC PROCESSOR MONO BYPASS VOLUME/BALANCE MAIN LEFT RIGHT VOL/BAL dB LEVEL SAFETY PRECAUTIONS INTRODUCTION INSTALLATION CONNECTIONS DETAILED INSTALLATION DESIGN PHILOSOPHY SPECIFICATIONS & TECHNICAL DATA CARE AND HANDLING WARRANTY & REGISTRATION...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS CAUTION CAUTION WARNING WARNING CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. THIS SYMBOL IS TO ALERT YOU OF THE PRESENCE OF UNINSULATED DANGER- OUS VOLTAGE WITHIN THE UNIT'S ENCLOSURE THAT MAY BE OF SUFFI- CIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK.
  • Page 3 This preampli er is a precision device, designed in an e ort to provide the listener with unmatched sound quality, design, and construction. In order to operate your preampli er properly and to realize all of the capabilities of the 07X PREAMPLIFIER we recommend that you read this entire manual carefully.

  • Page 4: Installation Connections

    INSTALLATION CONNECTIONS Illustrated below is the rear panel of the 07X. The connections are standard and typical of any audio preampli er. Any unknown features should be adequately explained by the function descriptions on the following page. Both sets of balanced receptacles on the le side are identical stereo outputs suitable for connection to multiple ampli ers.

  • Page 5: Detailed Installation

    3. The MONO button combines the le and right audio channels. 4. The BYPASS button will cause the gain to drop to unity, bypassing the normal 12dB standard gain of the 07x. 5. Volume and balance setting is indicated by the decibel (dB) display.
  • Page 6 DETAILED INSTALLATION The 07X can be operated by remote control. The MX- 350 Learning Remote is included with the preamp. The relevant pages of the remote interface are described below. For instructions on using the MX-350 itself see the manual included with the remote.

  • Page 7: Design Philosophy

    DESIGN PHILOSOPHY The circuity used in the FET PREAMPLIFIER 07x is the result of an advanced and com- plete design process combining innovation and prove fundamentals. This process avoids both the limitations of total adherence to convention and the aws resulting from inappropriate applications of clever circuit gimmicks.
  • Page 8 6. Connectors - Coda employs a standard RCA con guration with a gold plated case. The balanced connectors are Neutriks from Switzerland. 7. Wire - All signal wire has been eliminated whenever possible. Where wire is used, Coda employs silver plated copper, 141 strand, 18 guage wire with a silicone insulation.

  • Page 9: Specifications

    SPECIFICATIONS Frequency Response: -3dB @ 5Hz to 200kHz Distortion: < .005% from 10Hz to 40kHz @ 5V peak into 600 ohms or higher, shunted by 1000pF or less. Gain: 12dB plus 0-18dB variable per input in 1dB steps. Unity gain when Bypass feature is enabled. Maximum Output: 10V peak Noise:...

  • Page 10: Care And Handling

    CARE & HANDLING The interior of the ampli er requires no special care. If exterior cleaning beyond simple dusting is required, any dilute ammonia-based product is recommended. Do not use any abrasive rags, cleaners or chemical solvents on the ampli er. When handling the ampli er, take care not to mar the faceplate.

  • Page 11: Warranty And Disclaimer

    WARRANTY & DISCLAIMER i. Warranty - Any failure of the Coda product, herea er known as the product or I. Warranty- Any failure of the Ampli er S5 to operate or to meet speci cations, original product, to operate or to meet speci cations, applicable at time of manu-...

  • Page 12: Warranty Registration

    WARRANTY REGISTRATION Fill in this registration sheet and fax or mail it to Coda Technologies to ensure you are in our warranty system. This will facilitate warranty service should it become necessary. It is recommended that you retain a copy of this form for your own records.
  • Page 13 WARRANTY REGISTRATION Fill in this registration sheet and fax or mail it to Coda Technologies to ensure you are in our warranty system. This will facilitate warranty service should it become necessary. It is recommended that you retain a copy of this form for your own records.
  • Page 14 7850 CUCAMONGA AVENUE #34 SACRAMENTO, CA 95826 USA +01 916.383.3653 +01 916.455.3653 phone CODA.CC on the web at info@coda.cc email us at...
