Summary of Contents for Westinghouse WRC613SB
- Page 1 INSTALLATION AND USER MANUAL WRC613SB Canopy Rangehood WRC913SB Canopy Rangehood...
-
Page 2: Table Of Contents
CONGRATULATIONS CONTENTS Congratulations and thank you for choosing our canopy Important safety instructions ....3 rangehood. We are sure you will find your new rangehood Description of your rangehood . -
Page 3: Important Safety Instructions
This manual explains the proper use of your new mental capabilities or lack of experience Westinghouse canopy rangehood. Please read and knowledge if they have been given this manual carefully before using the product. - Page 4 ELECTRICAL CONNECTION Check that the mains voltage matches with the voltage on the data plate inside the canopy rangehood. Check that the installation complies with standards of local building, gas and electrical authorities. Before connecting to the mains supply ensure that the mains voltage corresponds to the voltage on the rating plate inside the cooker hood.
-
Page 5: Description Of Your Rangehood
- - - - - - - - - - - - - - - - - - - 5. Main body and fan housing assembly - - - - - - - - - - 6. Grease filter(WRC613SB) - - - - - - - - - - - - - - - - 6. Grease filter(WRC913SB) -
Page 6: Rangehood Dimensions
RANGEHOOD DIMENSIONS WRC613SB WRC913SB Fig. 4... -
Page 7: Installation
INSTALLATION PRE-INSTALLATION Before installing the cooker hood, peel off any protective plastic covering and remove polystyrene from inside behind LOCATION The hood is to be mounted on the wall. When installed, the hood must be not less than 60cm above electric burners or 65cm above gas or mixed-fuel burners. - Page 8 250 mm 130 mm ceiling Flue cover wall moun ng brackets 230mm Range hood 250 mm moun ng points g point 51 mm Max. 800 mm Top of hob Fig. 6 WRC613SB WRC913SB 600 mm 900 mm 440 mm 550 mm...
- Page 9 INSTALLATION 3. Install flue cover wall mounting brackets with suitable fixings. Install suitable screws for rangehood mounting points (to support a total weight of 30kg) to the wall as 5. Hang the body hood on the mounting screws then...
- Page 10 INSTALLATION Depending on the preferred installation/ducting mode, follow step 6a or 6b below. 6a.Recirculating mode secure the recirculating T-piece to the wall with suitable screws/fixings (optinal kit AR610RK). Install flexible pipe between T-piece and reducer. Use cable ties or suitable duct tape to secure flexible pipe to T-piece and reducer (Fig.
- Page 11 INSTALLATION 7. Electrical connection Check that the installation complies with the standards of local building, gas and electrical authorities. Before connecting to the mains supply ensure that the mains voltage corresponds to the voltage on the rating plate inside the rangehood. 8.
-
Page 12: Using Your Rangehood
CONTROL PANEL CARE & MAINTENENCE normal conditions and a high speed when odours are CAUTION more concentrated. External surfaces are susceptible to scratches and abrasions, so please follow the cleaning instructions start cooking. to ensure the best possible result is achieved without damage. - Page 13 CARE & MAINTENENCE Hand washing Changing the LED lamps Soak grease filters for about one hour in hot water with a If LED lamps need replacing, they must be replaced by grease-loosening cleaner, then rinse off thoroughly with hot lamps as stated in the techinical specifications. water.
-
Page 14: Troubleshooting
TROUBLESHOOTING GUIDE P R O B L E M REMEDY Check that the hood is connected to an electrical supply The cooker hood will not start Check that a fan speed has been selected Check that the fan speed is set high enough for the task The grease filters are clean The kitchen is adequately vented to allow the entry of fresh air The cooker hood is not working... -
Page 15: Optional Ducting Accessories
OPTIONAL DUCTING ACCESSORIES AR150RC AR150F AR610FS AR610RK AR150WV AR610CF AR150FD AR125FDA Part Numbers Description AR150RC 150mm G/Bond Roof Cowl AR150WV 150mm Wall Vent & duct AR610RK T-piece & carbon filters Replacement carbon filter Stainless steel exhaust cover extension 1200mm AR150FD 150mm aluminum flexible duct AR125FDA 125mm aluminum flexible duct... - Page 20 Top Service encompasses the after sales service provided by The Electrolux Group to consumers including delivery, home service and spare parts. Westinghouse. We are part of the Electrolux family. Share more of our thinking at www. electrolux.com Part number: 60901730 Issue B ©...
