LINK ELECTRONICS, INC.
SDI TO ANALOG CONVERTER
DigiFlex 1165
MADE IN THE USA
FEATURES
SDI to RGB
Composite Video Out
Composite Sync Out
10 BIT Resolution
525 or 625 Standards
Mounts in Stand-alone case
Mounts in 1000 11 Module Frame
The LINK 1165 digital to analog converter provides
an accurate means of converting component serial
digital (S MPTE 259M) video to component analog
RGB video. The 1165 takes advantage of the
latest integrated circuit technology to offer
outstanding performance.
All parallel digital processing features 10-bit
resolution.
Post-filtering
specifications is handled by a high-performance
hybrid analog filter. The digital front-end features
automatic gain and equalization with outstanding
return loss performance. Both 525/60 and 625/50
standards are supported, jumper selectable. Front
panel and rear panel LEDs indicate input
presence.
LINK
ELECTRONICS, INC.
1000
1000/2 - Dual Power Supply, Holds 10 Modules
7200
to
full
CCIR-601
2137 Rust Avenue
Phone 573 334 4433
Mounting Frame Options
- Single Power Supply, Holds 11 Modules
- Mounting Frame, Holds 1 Module
The 1165 also provides analog composite video
and composite sync output.
The DigiFlex 1165 is designed to reside in LINK's
1000-Series frame. This frame can house up to 11
modules of various types.
applications, the DigiFlex modules may be
mounted in a small portable chassis for single
module use, model
7200.
"single-module frame" features a modular power
supply for insertion of any DigiFlex series front
and rear modules.
All Link products carry a ten-year warranty
including parts and labor. Mix and match any of
the 1000 series modules in the DigiFlex frame.
Cape Girardeau, MO 63703-7668
FAX 573 334 9255
1000 SERIES DIGIFLEX
For stand-alone
The 7200-Series
