DUCTING

A minimum of 6" round for AK65 and 7" round
for AK21 and AK25 or 3-1/4" x 10" rectangular
Always use rigid type metal ducts only. Flexible
available duct run when using elbows, transitions
and caps.
ALWAYS, when possible, reduce the number or
transitions and turns. If long duct run is required,
increase duct size from 6" to 7" or 7" to 8".
If turns or transitions are required; install as far
away from hood duct output and as far apart,
between the two as possible.
Minimum mounting height between range top to
hood bottom should be no less than 24".
Maximum mounting height should be no higher
than 32".
It is important to install the hood at the proper
mounting height. Hoods mounted too low could
hoods mounted too high will be hard to reach and
If available, also refer range manufacturer's height
i n .
clearance requirements and recommended hood
" m
a x .
mounting height above range.
" m

Vertical Ducting:

3-1/4" x 10" rectangular minimum

Horizontal Ducting:

3-1/4"x10" rectangular minimum

DAMAGE-SHIPMENT / INSTALLATION:

installation.
unit to the store in which it was bought for
repair or replacement.
or replacement is the responsibility of the
customer.
must be made by arrangement between
customer and installer.
8
