Proteco SIMPLY Installation Manual
  1. Manuals
  2. Brands
  3. Proteco Manuals
  4. Gate Opener
  5. SIMPLY
  6. Installation manual
Proteco SIMPLY Installation Manual

Proteco SIMPLY Installation Manual

Double swing gate automation
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation Manual for the Kit Simply 230V

Double Swing Gate Automation
For more information on GateMotors full line of automatic gate openers and access controls visit our website at
www.gatemotors.co.uk
Phone Sales Lines
UK:
01202 717191
Outside UK:
(+44)1202 717191
Phone Technical Lines
UK: 0905 235 1700* (service available 8:30am to 5:30pm Monday to Friday only, closed Weekends and Public Holidays)
ROI: 156 099 9667** (service available 8:30am to 5:30pm Monday to Friday only, closed Weekends and Public Holidays)
Email: support@gatemotors.co.uk
*UK calls to this number are billed by the second and cost £1.02 per minute from a standard landline; other networks charges may also apply.
**IRISH calls to this number are billed by the second and cost €1.25 per minute from a standard landline; other networks charges may also apply.
Service is provided by Digital Select Ltd, 271 Regent Street, London, W1B 2ES whose helpline number is 0844 448 0165
Trading address: GateMotors UK, Unit 16c, Chalwyn Industrial Estate, St. Clements Road, Poole, Dorset. BH12 4PE.
GateMotors is the trading name of Screwjack Limited - registered office at 21 Oxford Road, Bournemouth, Dorset. BH8
8ET. Registered # is 4287804, VAT #:785 3450 06
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIMPLY and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Proteco SIMPLY

Summary of Contents for Proteco SIMPLY

  • Page 1: Installation Manual For The Kit Simply 230V

    Installation Manual for the Kit Simply 230V Double Swing Gate Automation For more information on GateMotors full line of automatic gate openers and access controls visit our website at www.gatemotors.co.uk Phone Sales Lines 01202 717191 Outside UK: (+44)1202 717191 Phone Technical Lines...

  • Page 2: Quick Reference: Measurement Charts

    Quick Reference: Measurement Charts PLEASE READ THIS FIRST! Thank you for purchasing the Kit Simply 230v Double Swing Gate automation. The gate kit is designed to be a “do-it-yourself” automatic gate opener kit. When correctly installed and properly used, your GateMotors Kit Simply 230v Double Swing Gate automation will give you many years of reliable service.

  • Page 3: Table Of Contents

    Table of Contents Contents Installation Manual for the Kit Simply 230V ................... 1 Quick Reference: Measurement Charts ....................2 Contents .............................. 3 Kit Simply 230v Specification ......................7 Kit Simply 230v Dimensions ........................ 7 Kit Simply 230v Component Breakdown .................... 8 Kit Simply Bracket Pack Contents .......................
  • Page 4 Because automatic gate openers produce high levels of force, consumers need to know the potential hazards associated with improperly designed, installed, and maintained automated gate opener systems. Keep in mind that the gate opener is just one component of the total gate operating system. Each component must work in unison to provide convenience, security, and safety.
  • Page 5 B5. Pay close attention to the diagram below and be aware of these areas at all times. If you identify areas of immediate high risk, please consider adding extra non contact safety device (Safety Photocells) and/or contact safety devices (Gate Safety Edges) from the selection that is available from the GateMotors website.
  • Page 6 D3. Do not attempt to “beat the gate” while the gate is closing. This is extremely dangerous. D4. Do not allow children or pets near your gate. Never let children operate or play with gate controls. Keep the remote controls away from children and unauthorised users; store controls where children and unauthorised users cannot obtain access to them.

  • Page 7: Kit Simply 230V Specification

    Kit Simply 230v Specification TECHNICAL CHARACTERISTIC MODEL SIMPLY 230V Power Supply 230v ~ 50Hz Current 1,2 - 1,7A Motor Power 300W Capacitor 10uF Thermic Protection 150 Degrees Celsius Maximum Thrust 280Nm Class IP Protection Revolutions (speed) 1400 g/m Working Temperature Range .

  • Page 8: Kit Simply 230V Component Breakdown

    Kit Simply 230v Component Breakdown NB: Please quote above part numbers when enquiring about replacements for the Kit Simply 230v model components from GateMotors. Page 8...

  • Page 9: Kit Simply Bracket Pack Contents

    Kit Simply Bracket Pack Contents Kit Simply - Before Installation..Tools Needed: Tape Measure Power Drill Adjustable wrench Hacksaw or Heavy Duty Bolt Cutters Small (flat head) screwdriver Small (Pozi Drive) Phillips screwdriver Wire Strippers You may also need these items before you begin the installation...
  • Page 10 - illustrated left. This distributes the torque force produced by the motor and protects the gate from potential damage. In this instance, the Simply motor arm can be directly bolted to the gate, shown left. Re-enforced Gate - Metal Thin walled tube gates –...
  • Page 11 Gate Preparation The gate must be plumb, level and swing freely on its hinges. The Kit Simply is designed to move the weight of the gate only. If hinges are stiff, loosen with lubricating oil. The gate must be able to move throughout its arc without binding or dragging on the ground.

  • Page 12: Installation Overview: Which Motor Is Left Or Right Hand

    Installation Overview: Which motor is left or right hand? The Kit Simply motors are manufactured according to their mounting orientation, left hand or right hand depending on which side the gate is hinged. This handing is stipulated by the positioning of the main drive shaft of the motor.

  • Page 13: Identifying The Fixing Point On The Gate

    Identifying the fixing point on the gate Identify the Fixing Point on the Gate The above connection points to the gate are suggested fixing points. This is based according to the gates shape and the fixing possibilities: a) If the gate leaf is large in height and width, you can position the motors connecting arm on the gate at any height with no restriction.

  • Page 14: Inward Opening Mounting

    With the Kit Simply being a versatile motor, there are NO set measurements that need to be achieved in order for the motor to operate correctly – instead there are only maximum measurements and as long as the motor operates within these measurements (A, B &...

  • Page 15: Outward Opening Mounting

    Outward Opening Mounting Identify the Fixing Point on the Pillar – Gate Hinged in the Centre This is an arrangement where the hinge of the gate is on the centre of the pillar. This gives the option of opening the gate to a maximum 90 degree angle as the pillar will physically stop the gate from opening further (Fig.

  • Page 16: Fixing The Motor's Anchor Plate To The Pillar

    There is no structural benefit to this arrangement, only aesthetic. The motor will be visibly seen sitting proud on a ‘shelf’. Once the anchor plate is positioned and strongly fixed to your pillar, next we look to anchor the Kit Simply motor to the bracket.

  • Page 17: Fixing The Motor To The Anchor Plate

    Fixing the Motor to the Anchor Plate Place the motor onto the anchor plate, paying particular attention to the positioning of the drive shaft for the motor. This drive shaft must be positioned nearest to the gate leaf to enable the articulated arm to operate at efficiently.

  • Page 18: Assembling The Articulated Galvanised Arms

    Once the motor has been anchored to its mounting plate with the shelf in the lower position, when the motor cover is replaced the plate will be hardly visible and the motors drive shaft will visible - illustrated left. Once attached to the gate pillar, the complete anchor plate will not be visible - illustrated right.

  • Page 19: Installing The Articulated Arm To The Motor Drive Shaft

    Stand M12 bolt on its head. Place S3 Gate bracket over the threaded bolt stem. Place M12 washer over threaded bolt stem. Place eye of curved arm over the M12 threaded bolt stem. Place second M12 washer over threaded bolt stem Secure in place with M12 lock nut.

  • Page 20: Fixing The Articulated Arm To The Gate Leaf

    Fixing the Articulated Arm to the Gate Leaf At this stage of the installation, we have the motor anchored on its mounting plate which in-turn has been fixed to the pillar and the articulated has been assembled and ready to attach to the gate leaf. To attach to the gate leaf, it will be necessary to unlock the motor so we can physically push and pull the motor drive spindle in order for the articulated arm to reach the gate leaf for attaching.

  • Page 21: Attaching Articulated Arm To The Gate Leaf

    It is an electrical gate stop and preserves the long lasting life of the motor’s components. Compared to the linear range of motors, the Kit Simply is designed in a very different way therefore the limit switches are to be used. Physical gate stops are required to present the form of resistance the motors needed in accompany the installation to regulate the duty cycles to ensure continued smooth operation.
  • Page 22 STEP 1 Locate the CAM switches towards the back of the motor. These are loose upon manufactuering for ease of being set. These CAMS rotate around a pole that is directly connected to the motors drive spindle shaft. STEP 2 When the cams rotate on the vertical pole during the gates opening or closing cycles (the drive spindle turns clockwise / anti-...
  • Page 23 The CAM switches can be re-positioned at any time if the need for a shorter / wider opening angle arises. Simply follow the steps 1 to 4 and re-perform the Sequential Programming as described in the Q60AR Control Board for Swing Gates Instruction guide (page 22) to enable the control board to adjust its motor running time parameters to suit.

  • Page 24: Connecting Motor Wiring To The Q60Ar Control Board

    Re-lock the motor using the release key supplied to ensure the gate cannot move when manual force is applied. This ensures the spring mounted release mechanism has interlocked with the motor gears. If the motor is not re-locked, when the automation is activated the motor spindle will just spin with no movement produced by the articulated arm.

  • Page 25: One Gate To Open Before The Other

    Connecting Right Hand Motor Connecting to the right hand motor to the control board will require the use of 1.5mm 4 core armoured cable. 4 core cable flex could be used but it is strongly recommended to use armoured cable for safety as often cables need to be laid under the driveway to connect the right hand motor.

  • Page 26: Inward And Outward Opening

    Inward and Outward Opening The Kit Simply is versatile in which direction it can travel so it can open inwards and outwards. The following few pages show wiring diagrams to explain how the motors are connected to the Q60AR Control Board depending on how they are to operate depending on whether the gates are to open inwards or outwards.

  • Page 27: Installation Complete

    Outward Opening Double Leaf Gate For gates that open outwards, The Kit Simply can operate a specific handed gate leaf before the other. This comes into play where there is a “lip” on a gate leaf which keeps the gates together or there are specific requirements to have one leaf open before the other.

  • Page 28: Warranty

    Warranty The 12 months Limited Warranty on all goods supplied by GateMotors is on a return for repair basis. Any longer warranty issued by a manufacturer will require these to be returned to the manufacturer’s head office or service address, in or outside the United Kingdom. GateMotors shall not be liable in any way for failure of any product supplied.

  • Page 29: Kit Simply 230V - Faq's

    Kit Simply 230v – FAQ’s Will my gates still open in the winter when it is very cold and icy? Climate conditions do affect how the internal mechanics operate. During periods where the outside temperature can drop as low as -20 in some parts of the UK, the motors can physically have trouble starting, just like a motor vehicle.

  • Page 30: Kit Simply - Accessories

    This is plugged into the 10-pin socket located on the gate control board, and then connected using 2-wire configuration. The expansion card transmits 12v charge to the lock which releases its locking pin. In addition, the electro-lock can be used as a stand-alone lock, simply using the two 'Yale' type keys supplied. Digital Keypads Available in Solid Metal, Narrow Style Metal Pressure Sensitive or Plastic Membrane Covered.

  • Page 31: Comments & Feedback

    Comments & Feedback We thank you for taking the time in reading and following the new version of our instructions. This instruction guide has been compiled from comments and feedbacks received from previous / existing customers who are familiar with our automation and had followed the old version (also included alongside with this guide).

Table of Contents
