| Introduction
C 1
HAPTER
Description of Hardware
Table 3: System Status LEDs
LED
Diag
PoE
P S
OWER UPPLY
There is one power inlet on the rear panel of the switch. The standard power
inlet is for the AC power cord.

Figure 4: Power Supply Inlet

G P
ROUNDING
To prevent accidental electrical shock or damage to your switch, it is
recommended that you ground the switch to an earth point by attaching a
grounding wire (not supplied) to the grounding point located on the rear panel,
with a metal screw. If located in a tall building, grounding points include metal
Condition Status
On Green The system diagnostic test has completed successfully.
Flashing The system boot up is in progress.
Green
On Amber / The system diagnostic test is in progress.
Flashing
Amber
Off The system diagnostic has completed.
On Amber Powered device connected.
Off No powered device connected.
I
NLET
OINT
