  • Page 1 Owner’s Manual 21 Healey Road Dandenong, 3174 Victoria, Australia ACN# 088 609 661 www.pridemobility.com...
  • Page 2 Performing a prohibited action can cause injury to personnel and/ or damage to equipment (black symbol with red circle and red slash). 088 609 661 Copyright © 2005 This product is manufactured by: Pride Mobility Products Corporation 182 Susquehanna Avenue Exeter, PA 18643 INFMANU3076/RevA/September05 www.pridemobility.com...

  • Page 3: Table Of Contents

    This owner’s manual is compiled from the latest specifications and product information available at the time of publication. We reserve the right to make changes as they become necessary. Any changes to our products may cause slight variations between the illustrations and explanations in this manual and the product you have purchased. Jazzy 610 www.pridemobility.com...

  • Page 4: Introduction

    I N T R O D U C T I O N SAFETY WELCOME to Pride Mobility Products Corporation (Pride). The power chair you have purchased combines state-of- the-art components with safety, comfort, and styling in mind. We are confident that these design features will provide you with the conveniences you expect during your daily activities.
  • Page 5 T T T T T = Terminal Post Connect Red wire to T T T T T with + + + + + Connect Black wire to T T T T T with – – – – – Jazzy 610 www.pridemobility.com...
  • Page 6 Prevent personal injury and equipment damage. Do not connect an extension lead to the AC/DC converter or the battery charger. EMI-RFI - This product has been tested and passed at an immunity level of 20 V/m. www.pridemobility.com Jazzy 610...

  • Page 7: Safety

    ! Check all controller connections to the power base. Make sure they are secured properly. ! Check the brakes. See VIII. “Care and Maintenance.” ! Check battery charge. See VI. “Batteries and Charging.” NOTE: If you discover a problem, contact your authorised Pride Provider for assistance. Jazzy 610 www.pridemobility.com...
  • Page 8 WARNING! When on any sort of an incline or decline, never place the power chair in freewheel mode while seated on it or standing next to it. Doing so may result in personal injury and/or damage to your power chair. WARNING! Never travel down an incline rearward. This may result in personal injury. www.pridemobility.com Jazzy 610...
  • Page 9 WARNING! If you anticipate being seated in a stationary position for an extended period of time, turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources. Failure to do so may result in personal injury. Jazzy 610 www.pridemobility.com...
  • Page 10 Power chairs are not designed to travel up or down stairs or escalators. Always use a lift. WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to yourself and to others and/or damage your power chair. www.pridemobility.com Jazzy 610...

  • Page 11: Iii. "Your Power Chair

    If you will be traveling with your power chair, you may find it necessary to use a lift/elevation product to aid in transporta- tion. Pride recommends that you closely review the instructions, specifications, and safety information set forth by the manufacturer of the lift/elevation product before using that product. Jazzy 610 www.pridemobility.com...
  • Page 12 This may cause your power chair to tip, possibly resulting in personal injury. WARNING! Prevent personal injury! Keep your hands away from the tyres when driving. Be aware that loose fitting clothing can become caught in drive tyres. www.pridemobility.com Jazzy 610...
  • Page 13 WARNING! Do not operate your power chair while you are under the influence of alcohol, as this may impair your ability to operate your power chair in a safe manner. Jazzy 610 www.pridemobility.com...
  • Page 14 NOTE: For further information on EMI/RFI, go to the Resource Center on www.pridemobility.com. If unin- tended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Contact your authorised Pride Provider to report the incident. www.pridemobility.com Jazzy 610...
  • Page 15 THE JAZZY 610 The Jazzy 610 has two main assemblies: the seat assembly and the power base assembly. See figure 5. Typically, the seat assembly includes the armrests, seatback, and seat base. The power base assembly includes two motor/brake assemblies, two drive wheels, four caster wheels, two batteries, and wiring harnesses.
  • Page 16 I I I . Y O U R P O W E R C H A I R JAZZY 610 SPECIFICATIONS Suspension: Active-Trac Extreme (ATX) Class of Use: Drive Wheels: 25 cm, pneumatic (25 cm solid optional) Front Caster Wheels:...
  • Page 17 TRAPEZE BARS FRONT COVER MOTOR/BRAKE ASSEMBLY Figure 6. The Jazzy 610 Power Base ELECTRICAL COMPONENTS The electrical components are located inside the power base. The ammeter and the charger power lead receptacle are located on the right side of the power base. The main circuit breaker is located on the front of the battery tray. The controller connector(s) are located inside the power base.
  • Page 18 CHARGER INHIBIT CONNECTOR FLIGHT POWER MODULE CHARGER CIRCUIT FUSE BATTERY CONTROLLER CONNECTOR CONNECTOR MOTOR CONNECTORS BATTERY MOTOR CONNECTOR CONNECTORS VSI CONTROLLER ONBOARD BATTERY CHARGER CHARGER POWER LEAD RECEPTACLE AMMETER MAIN CIRCUIT BREAKER Figure 7. Jazzy 610 Electrical Components www.pridemobility.com Jazzy 610...
  • Page 19 Pride Provider. MANUAL FREEWHEEL LEVERS The Jazzy 610 has a manual freewheel lever on each motor. Manual freewheel levers enable you to disengage the drive motors from the gearboxes and maneuver the chair manually. WARNING! Do not use the power chair while the drive motors are disengaged! Do not disengage...

  • Page 20: Assembly

    ARMREST WIDTH ADJUSTMENT SEAT INSTALLATION ARMREST ANGLE ADJUSTMENT SEAT HEIGHT/ANGLE ADJUSTMENT CONTROLLER POSITION TYRE/TUBE REPLACEMENT FOOT PLATFORM ANGLE ADJUSTMENT FOOT PLATFORM HEIGHT/DEPTH ADJUSTMENT Figure 10. Jazzy 610 Assembly View (Universal Mounting System Shown) www.pridemobility.com Jazzy 610...
  • Page 21 8. Reinstall the rear shroud. Turn the rear shroud fasteners clockwise one-quarter turn to lock. 9. Route the controller cable so that it cannot be pinched in the seat hinge. 10. Secure the controller cable to the armrest receiver with one or more wire ties. Jazzy 610 www.pridemobility.com...
  • Page 22 Align the seat plate interface bracket onto the actuator. See figure 12. 2. Insert screws into the actuator and insert and tighten the hard- ware. 3. Place seating system onto the seat plate and secure. Figure 12. Power Seat Actuator www.pridemobility.com Jazzy 610...

  • Page 23: Comfort Adjustments

    9. Move the trapeze bars up or down to the desired height. NOTE: Change the seat dump by raising or lowering only one set of posts (front or back). RETAINING CLIPS 10. Reinstall the retaining clips from step 8. Figure 14. Seat Height Adjustment - Trapeze Bars Jazzy 610 www.pridemobility.com...
  • Page 24 The lever is located on the right side of the seat base. To adjust the recline angle: Figure 16. Seat and Armrest Adjustments 1. Pull up on the seatback release lever. 2. Lean forward or rearward to the desired position. 3. Release the lever. www.pridemobility.com Jazzy 610...
  • Page 25 The quick release fastener has two states: clamped and unclamped. When the lever is open, the quick release fastener is unclamped. When the lever is closed, the quick release fastener is clamped. Jazzy 610 www.pridemobility.com...
  • Page 26 10. Route the controller cable to the rear of the power base. 11. Plug the controller connector(s) into the power base. 12. Use a wire tie to secure the controller cable to the arm- rest. 13. Reinstall the rear shroud and tighten the fasteners. www.pridemobility.com Jazzy 610...
  • Page 27 2. Move the leg rest hanger in or out to the desired position. 3. Align the adjustment holes in the leg rest hanger with those in the side rail. 4. Reinstall the adjustment bolts to secure the leg rest hangers. Figure 23. Heavy Duty Drop-In Leg Rests Jazzy 610 www.pridemobility.com...
  • Page 28 3. Tighten the hardware. To change foot plate angle (D): 1. Turn the setscrew clockwise to decrease the angle. 2. Turn the setscrew anticlockwise to increase the angle SETSCREW LOCATION Figure 24. Multi-Axis Foot Plate (ELR Shown) www.pridemobility.com Jazzy 610...
  • Page 29 NOTE: The power elevating seat option is equipped with a system that reduces the speed of the power chair by one half when the seat is elevated more than 2.5-5 cm. Always check to be sure this system is operating properly before using your power chair. Jazzy 610 www.pridemobility.com...

  • Page 30: Batteries And Charging

    BATTERIES AND CHARGING The Jazzy 610 uses two long-lasting, 12-volt, deep-cycle batteries. These batteries are sealed and maintenance free. Since they are sealed, there is no need to check the electrolyte (fluid) level. Deep-cycle batteries are designed to handle a longer and deeper discharge.
  • Page 31 If you use your power chair on a daily basis, charge the batteries as soon as you are finished using your power chair. Your power chair will be ready each morning to give you a full day’s service. It is recommended that you charge the batteries 8 to 14 hours after daily use. Jazzy 610 www.pridemobility.com...
  • Page 32 It will be well worth it to take the time to break in your battery properly. NOTE: The useful life of a battery is quite often a reflection of the care it receives. www.pridemobility.com Jazzy 610...
  • Page 33 What about shipping? If you wish to use a freight company to ship your power chair to your final destination, repack your power chair in the original shipping container and ship the batteries in separate boxes. Jazzy 610 www.pridemobility.com...

  • Page 34: Operation

    Figure 26. VSI Controller (Optional 6-Key Shown) complete stop. WARNING! If your power chair begins to move in an unexpected manner, immediately release the joystick. Unless the joystick is damaged, this action should stop your power chair. www.pridemobility.com Jazzy 610...
  • Page 35 If your power chair was programmed with a drive profile, contact your authorised Pride Provider for more information. NOTE: We recommend that the first few times you operate your power chair, you use the lowest speed setting until you become familiar with your new power chair. Jazzy 610 www.pridemobility.com...
  • Page 36 Motor Connectors This connects the VSI to the power chair’s motors and motor/brakes. Battery Connector This connects the VSI to the power chair’s batteries. Actuator Connector (Optional) This connects the VSI to the power seat actuator. www.pridemobility.com Jazzy 610...
  • Page 37 The parking brakes have a bad connection. Check the parking brake and motor connections. Make sure the controller connections are secure. An excessive voltage has been applied to the controller. This is usually caused by a poor battery connection. Check the battery connections. Jazzy 610 www.pridemobility.com...
  • Page 38 Keypad The keypad is located in front of the joystick. It contains keys necessary to operate your power chair. See figure 29. Figure 28. FLIGHT Controller Horn Key The horn key activates the horn. www.pridemobility.com Jazzy 610...
  • Page 39 1. While the FLIGHT is locked, press the on/off key to turn on the FLIGHT. All LEDs will flash briefly. The LEDs will then slowly ripple from right to left. 2. Press the horn key twice before the LED ripple has completed, approximately 10 seconds. The FLIGHT is now unlocked. Jazzy 610 www.pridemobility.com...
  • Page 40 Check the communications connections and wiring. FLIGHT Power Module Fault Check the communications connections and wiring. FLIGHT Communications Fault Check the communications connections and wiring. Unknown Fault Contact your authorised Pride Provider. Incompatible Controller Fault Contact your authorised Pride Provider. www.pridemobility.com Jazzy 610...

  • Page 41: Care And Maintenance

    M A I N T E N A N C E CARE AND MAINTENANCE Your Jazzy 610 is a sophisticated power chair. Like any motorised vehicle, it requires routine maintenance checks. You can perform some of these checks, but others require assistance from your authorised Pride Provider. Preventive maintenance is very important.
  • Page 42 ! Keep your power chair clean and free of foreign material, such as mud, dirt, hair, food, drink, etc. Yearly Checks Take your power chair to your authorised Pride Provider for yearly maintenance. This helps ensure that your power chair is functioning properly and helps prevent future complications. www.pridemobility.com Jazzy 610...
  • Page 43 NUTS 10. Reinstall the drive wheel nut onto the wheel hub and tighten. 11. Inflate the pneumatic tyre to 2.4 bar (35 psi). Figure 30. Jazzy 610 Drive Wheel 12. Remove the power chair from the blocks. Jazzy 610 www.pridemobility.com...
  • Page 44 13. Slide the battery tray back into the power base. 14. Connect the battery harness to the rear battery. 15. Reinstall the front cover. 16. Reinstall the rear shroud and tighten the fasteners. 17. Charge the batteries. See VI. “Batteries and Charging.” www.pridemobility.com Jazzy 610...
  • Page 45 V I I I . C A R E A N D M A I N T E N A N C E REAR SHROUD FASTENERS BATTERY WIRING DIAGRAM LABEL REAR SHROUD FRONT BATTERY REAR BATTERY Figure 31. Battery Installation Jazzy 610 www.pridemobility.com...
  • Page 46 Disconnect both batteries before load testing and follow the directions that come with the load tester. If either one of the batteries fails the load test, replace both of them. If your power chair still does not power up, contact your authorised Pride Provider. www.pridemobility.com Jazzy 610...
  • Page 47 Replacement Units The availability of replacement units is subject to the discretion of the provider, not the manufacturer. For more information regarding replacement units, contact your authorised Pride Provider. Jazzy 610 www.pridemobility.com...
  • Page 48 N O T E S www.pridemobility.com Jazzy 610...
  • Page 49 N O T E S Jazzy 610 www.pridemobility.com...
  • Page 50 N O T E S www.pridemobility.com Jazzy 610...
  • Page 51 N O T E S...
  • Page 52 Quality Control - Jazzy 610 Thank you for making the Jazzy 610 your choice in power chairs. Q u a l i t y C o n t r o l - M o d e l 1 400 We have thoroughly inspected your power chair. The following checkmarks indicate that it has been test driven and inspected.
