JAZZY
SELECT SERIES
Jazzy Select
Jazzy Select 6
Jazzy Select 6 with Power Seat
Including Models: Jazzy Select, Jazzy Select 6, and
Jazzy Select 6 with Power Seat
1-800-800-8586 (US) 1-888-570-1113 (Canada)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jazzy Select and is the answer not in the manual?

Questions and answers

Wendell Alcorn Jr.
June 2, 2025

I can't get the batteries to charge on my Jazzy

0
William Willett
January 16, 2025

all the LEDs blink 9 times then a pause. What does that mean? I just replaced the batteries.

-5
