- Page 1 InfOrMatIOn safetY InstrUctIOns OperatOr UnIt InstallatIOn electrIcal cOnnectIOns prOgraMMIng Of reMOte cOntrOls release OperatIOn MaIntenance DOOR trOUblesHOOtIng WarrantY carD OPERATOR SLIDING-1300/2100 Installation and Operating Manual © DoorHan, 2012...
-
Page 2: Table Of Contents
4.3. Installation of the rack on a DoorHan door ........ -
Page 3: General Information
InfOrMatIOn GeneRAL InFoRMAtIon The SLIDING-1300/2100 operators are intended for automation of sliding gates without a pass door. It consists of a mechanical reducer in oil bath and an electric motor with a built-in control unit. The reducer and the motor have a common housing. The rack fixed on the gate transforms the rotational motion of the output sprocket into the linear motion of the gate. An external control button is connected to the control unit. The self-locking reducer ensures the gate is mechanically locked if the motor fails. If the power fails, you can open or close the gate by hand using an emergency manual release. 1.1. Basic functions • An automatic stop system ensures quick and safe stop of the motor in end positions. • Electronic noncontact limit switches ensure stop of the gate in end positions. • In case of power failure, the operator can be released with a lever, after that you can open or close the gate by hand using a chain. • The operator can be operated from stationary button or remote control in the stepped mode (open-stop-close-stop). • The control unit and motor-reducer is placed within operator’s housing. The operator produces low noise and is equipped with heat protection. The automatic SLIDING-1300/2100 operators are designed for use with sliding doors. Other than its intended use is forbidden. 1.2. technical specifications Model sLIDInG-1300 sLIDInG-2100 supply valtage, V/Hz 220 (±10%)/ Absorbed power, W 1:32 Reduction ratio Rack, mm М4×12.566 Pinion type Max. linear force, n 1 350 Max. output torque (n•m ) -
Page 4: Safety Instructions
• Do not make any changes in the automatic system not specified in this manual. • Do not install the equipment in premises containing quick inflammable substances or other dangerous environments as it can cause explosion or fire. • Do not use the operator if it needs repair or adjustment as installation defects or unbalanced door can cause injury. • Mains supply shall be connected to the automatic system via automatic switch with a minimal distance of 3 mm between the neighboring contacts. It is recommended to use a 6А automate. • Remove package of the item and dispose of it. Keep the package materials away from children. • Make sure that no objects are located within the door’s range of travel. • Never let children play in the door’s range of travel. Keep all remote control units of the operator and stationary control buttons out of the reach of children. • passage is only allowed when the gate has stopped and the operator is off. • DOORHAN shall not be held responsible in case of injury caused by misuse of the product. • DOORHAN shall not be held liable in case of improper installation of the item and damage arisen during operation. • DOORHAN is not responsible for unstable work of the automatic system when using safety devices and accessories, which are produced by other manufactures without agreement with DOORHAN. • It is highly recommended to use DOORHAN optional equipment as the accessories produced by other manufacturers can damage the automated system. • When carrying out maintenance, it is recommended to use the DOORHAN original spare parts. • Be sure that after completion of installation the installer has shown the user how to release the door in case of emergency and has given instructions on proper operation and maintenance of the automated system. • Repairs may be carried out only by qualified personnel who was trained and certified at the authorized DOORHAN centre. • The Sliding automatic system does not require any special servicing. •... -
Page 5: Operator Unit
OperatOr UnIt 3. oPeRAtoR UnIt 1. Reducer housing 2. Housing cover 3. Control unit 4. Stator 5. Condenser 6. Terminal block 7. Gear wheel 8. Operator fastening devices 9. Cover of the fastening devices 10. Release 11. Limit switches InstALLAtIon 4.1. tools 1. Set of spanners 5. pliers 2. Set of cross and straight-blade screwdrivers 6.Hacksaw for metal 3. Set of drill bits for metal 7. Electric drill 4. Set of drill bits for concrete 8. Tape measure (folding rule) 4.2. operator installation Following the instructions below is critical to safe and satisfactory operation of the operator. • Be sure that construction of the door allows its automation. -
Page 6: Installation Of The Rack On A Doorhan Door
InstallatIOn 4.3. Installation of the rack on a DoorHan door In case of installing the operator on the DoorHan sliding door, the rack installation steps are as follows. 1. place the C-profile on the shield fastening brackets (4) and fix using tapping screws. 2. Insert a bolt with semi-round head and embedded plate (1) in the C-profile. 3. place the clamp (5) on the C-profile so that the bolt (1) goes into the hole in the clamp. 4. Screw the bushing (2) on the bolt but not tighten it. The bushing (2) must press the clamp (5) to the C-profile (3). 5. position the fastening unit you made opposite the hole in the rack. 6. R epeat procedures 2–5 for other fastening units. The total quantity of fastening units shall be the same as the quantity of holes in the racks. 7. Fix the racks on the fastening units using bolts (6). 8. Level the teeth of all section elements using a free rack. 9. Tighten the fastening units. 10. M ove the door by hand and make sure that when the door moves, all the rack elements do not leave the operator’s gear wheel. -
Page 7: Installation Of Limit Switch Plates
4. C heck that the door reaches the mechanical stops Rack and that the door motion produces no friction. 5. Do not grease the rack and the gear wheel. Gear wheel Ground level 4.5. Installation of limit switch plates The SLIDING-1300/2100 operator is equipped with ferreed contacts (magnetically operated sealed switches) which response for move of the magnet fastened to the rack and produce the command for door stop. Install the end magnets in the following order. 1. Unblock the operator (see p. 7). синий 2. M ove the door by hand in open position leaving 2–5 cm before the me c hanical stop. blue 3. M ove the open limit switch magnet (red round sticker) along the rack in the direction of door opening till the magnetically operated sealed switch is off (a corresponding LED will go off on the control board). Move the magnet another 20–30 mm and fix... -
Page 8: Electrical Connections
5.1. Control unit electric diagram AttentIon! Turn off the power supply before beginning work with control board. The power cables must be laid separate from signal cables. To reduce induced noises, use cables with screened armature. Cable wires must be protected from contact with rough and sharp parts. Connection of photocells for close. If you use DoorHan PhotoCell photocells, put the jumper in NC position Radio receiver LED3 Connection of photocells for open. Capacitor If you use DoorHan PhotoCell photocells, put the jumper in NC position... - Page 9 electrIcal cOnnectIOns Control unit LeDs Indicator Function Glows Does not glow Motor supply voltage A (red) Add remote control code B (green) Emergency conditions START command pED command Close photocells Actuated not actuated Open photocells Actuated not actuated STOp STOp command Close limit switch Closed Actuated Open limit switch Closed Actuated States of light diodes when the door is in middle position and does not move are shown in bold. electrical connectors 1. ~220 (n, L, Pe) — connector on the control unit used for connection to supply voltage unit. pE — earth connection N — power supply (neutral) L — power supply (phase) 2. MotoR (n, L1, L2) — connector on the control unit used for connection to electric motor unit. Make sure that the motor is connected as shown in the electric diagram. 3. LAMP — connector used for connection of signal lamp 230 V max 40 W. It works by any move of the door leaf. The lamp blinking period is 0.5–1 sec. Low voltage contacts used for accessories 1. stARt — Full open command (no) Closing of contacts of the device connected to this terminal will cause actuation of control unit for full open and/or close of the door (the exact logic depends on position of Dip1 switch).
-
Page 10: Dip-Switches
electrIcal cOnnectIOns 5. Photo op — contacts for connection of opening safety devices (NC). Actuation of the devices causes immediate stop. Actuation of the devices connected to these terminals does not effect the operation when the door closes. If the door is closed and sensors connected to these terminals actuated, the door will not open. To connect several devices with NC contacts, connect then in series. note! If no devices are connected to these terminals, place a jumper between the contact terminals Ph op and — (see the electric diagram). 6. eMRG — contacts for connection of emergency stop devices (NC). These connections are used to protect the door leaf when it opens and closes. Any operational logic of the control unit enables immediate stop of the door after the signal from these devices. If the door does not move and the sensors connected to these terminals actuated, the door will not move. To connect several devices with NC contacts, connect them in series. note! If no devices are connected to these terminals, place a jumper between the contact terminals eMRG (see the electric diagram). 7. 24 V DC — output terminals on power supply transformer 24 V DC max load 600 mA. AttentIon! If you change position of DIp switches or mechanical regulators, turn off and then turn on again the supply voltage of the operator. Otherwise the changes made will not take effect. 5.2. DIP switches Dip1 — operation mode. If Dip1 is off, the Start command will be not taken when the door opens (on/off). Dip2 — separate control. If Dip2 is on, separate control can be realized. The device connected to the Start terminal sends an open command and the device connected to ped terminal sends a close command (on/off). -
Page 11: Programming Of Remote Controls
prOgraMMIng Of reMOte cOntrOls Adjustment of mechanical regulators Turn the corresponding regulator clockwise to encrease the setting. Turn the corresponding regulator counterclockwise to decrease the setting. Automatic close is adjusted using the Auto Cl regulator. For that you should set it in any position except the end left one. Turning the regulator right increases pause time before automatic close. PRoGRAMMInG oF ReMote ContRoLs 1. M emory cleaning. After power supply is on, hold down the "CODE" button for 10 seconds. The "A" indicator will blink for 10 seconds, then it will go out for 2 seconds and blink twice again to confirm that the codes were erased. 2. C ontrol’s code storing. To store the code of the remote control, press and hold down for 3 seconds the "CODE" button. The red A indicator will blink. Release the button. press the selected button on the remote control (which you wish to control the unit with) within 10 seconds during blinking of the red indicator. Hold down the button on the remote control until the red "A" indicator lights up for 2 seconds and goes out. The code of the remote control is stored. 3. To add several remote controls, repeat the procedure of code storing for them. You can add 65 remote controls. 4. I f no control commands are given, the automatic exit from the waiting mode will be in 10 seconds In case of disconnection of the control unit from the mains, the programmed data will be stored. -
Page 12: Maintenance
• The manufacturer reserves the right to make changes and alterations in the product design without preliminary notice. • The manual describes the procedures for installation and adjustment of the SLIDING-1300/2100 operator. • Following the operation and maintenance recommendations for the operator as well as installation procedures for the operator and the door described in the Manual will guaranty long life of the equipment and reduce risk of accidents when installing and operating the door. • Do observe safety standards at installation, operation and maintenance. • If you need a copy of this Manual, contact the DoorHan company: 120, Novaya Street, Akulovo, Odintsovo District, Moscow Region, Russia, 143002; or info@doorhan.ru. • The manufacturer (DoorHan) does not handle installation, operation, maintenance of doors and automatics and is not responsible for installation, operation and maintenance safety. • The contents of this Manual shall not be basis for any claim. tRoUBLesHootInG symptom Possible reason solution Operator does not run. -
Page 13: W Arranty Card
WarrantY carD 10. WARRAntY CARD Serial number Installation date Bar code Component part Component part Component part Component part Seller’s stamp Component part Component part Component part Component part Installation crew ............................City/town ..............Tel/fax ..............Customer Name ..............City/town ..............Address ..............postal code ..............Tel/fax ..............Guaranteeing party signature Hereby we inform you that your data will be entered in the Customer signature database of the company DoorHan and you will be notified with guarantee registration letter. We also can send you promotional materials and other explanatory materials. - Page 14 fOr nOtes...
- Page 15 fOr nOtes...
- Page 16 We appreciate very much that you have chosen the product manufactured by our company and are confident that you will be satisfied with its quality. For information on purchasing, distribution and servicing contact DoorHan regional offices or central office DoorHan 120, Novaya Street, Akulovo, Odintsovo District, Moscow Region, Russia, 143002. Tel.: +7 495 933-24-00, 981-11-33 E-mail: info@doorhan.ru www.doorhan.ru...
