DRIVE
SLIDING-1300/2100
Installation and Operation Manual
© DoorHan, 2014
OVERVIEW
SAFETY PRECAUTIONS
DRIVE ASSEMBLY
INSTALLATION
RELEASE MECHANISM OPERATION
MAINTENANCE
TROUBLESHOOTING
3
4
5
5
9
9
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLIDING-1300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DoorHan SLIDING-1300

Summary of Contents for DoorHan SLIDING-1300

  • Page 1 OVERVIEW SAFETY PRECAUTIONS DRIVE ASSEMBLY INSTALLATION RELEASE MECHANISM OPERATION MAINTENANCE TROUBLESHOOTING DRIVE SLIDING-1300/2100 Installation and Operation Manual © DoorHan, 2014...

  • Page 2: Table Of Contents

    4.4. Installation of gear rack on DoorHan door ....... . .

  • Page 3: Overview

    Control unit is set inside the drive housing with a gear motor. The drive has a low noise level and overheating protection. Sliding-1300/2100 automatic drive serves to operate sliding door. Do not use it for other purposes 1.2. Technical specifications...

  • Page 4: Safety Precutions

    Follow any instructions of this manual as improper equipment installation could result in serious damage. y Sliding-1300/2100 drive serves to automatic control of sliding door. Use the drive as intended only, any misuse of the drive is forbidden.

  • Page 5: Drive Assembly

    DRIVE ASSEMBLY 3. DRIVE ASSEMBLY 1. Gearbox housing 2. Housing cover 3. Control unit 4. Stator 5. Capacitor 6. Terminal block 7. Gear 8. Drive mounting 9. Mounting cover 10. Release mechanism 11. Limit switches 4. INSTALLATION 4.1. Tools 1. Set of wrenches 5.

  • Page 6: Drive Installation

    DRIVE ASSEMBLY Materials to install and related accessories (if any): y cable 2 × 0,5 mm (photocells transmitter, step-by-step control button); y cable 4 × 0,5 mm (photocells receiver); y cable 3 × 1,5 mm (power supply); y use cables with appropriate voltage insulation. WARNING! ELECTRIC SHOCK HAZARD! Cables of 220-240 V AC shall be installed by a qualified specialist.

  • Page 7: Installation Of Gear Rack On Doorhan Door

    DRIVE ASSEMBLY 4.4. Installation of gear rack on DoorHan door In case of drive installation on DoorHan sliding door, gear rack mounting shall be carried out as follows: 1. Install C-profile (1) on leaf mounting brackets (2) and secure 2. Get round head bolt (3) and cover plate (4) into C-profile (1) it with self-tapping screws (see figure 1).

  • Page 8: Installation Of Gear Rack On Third-Party Door

    2. Check that the door can reach mechanical stops, and there is no friction while moving the door. 3. Do not lubricate any rack or gear. 4.6. Placement of limit switches plates Sliding-1300/2100 drive is equipped with ferreed contacts (magnetic reed switches) that are responsive to the movement of magnet attached to the rack and generate a command to stop the door.

  • Page 9: Release Mechanism

    Republic or e-mail to: europe@doorhan.com. • The manufacturer (DoorHan) does not exercise direct control over the door and automatic equipment installation, their maintenance and operation and can not be responsible for the safety of the door and automatic equipment installation, operation and maintenance.
  • Page 10 NOTES...
  • Page 11 NOTES...
  • Page 12 We very much appreciate that you have chosen the product manufactured by our company and believe that you will be satisfied with its quality. For information on purchasing, distribution and servicing contact DoorHan central office at: Kralovsky VRCH 2018, Kadan, 43201, Czech Republic Telephone: +420 474 319 111 E-mail: europe@doorhan.com...
