HPP06
Hydraulic Powerpack
From serial
No. 5688
Prior to Operation
We thank you for choosing a
HYCON powerpack.
Please note that the power-
pack is delivered without hy-
draulic oil, and therefore it
must be filled up with hydrau-
lic oil prior to operation.
To ensure smooth operation
and long-lasting performance
of your new powerpack, we
recommend you to study this
operating manual carefully and
pay special attention to the
Safety and Service
Precautions
We hope you will be satisfied
with your new HYCON power-
pack.
Best regards
HYCON A/S
HYCON A/S
Juelstrupparken 11
DK-9530 Støvring
Danmark
Tel: +45 9647 5200
Fax: +45 9647 5201
Mail
hycon@hycon.dk
www.hycon.dk
Advertisement
Table of Contents
Related Manuals for HYCON HPP06
Summary of Contents for HYCON HPP06
- Page 1 Danmark pay special attention to the Tel: +45 9647 5200 Safety and Service Fax: +45 9647 5201 Mail hycon@hycon.dk Precautions www.hycon.dk We hope you will be satisfied with your new HYCON power- pack. Best regards HYCON A/S...
-
Page 2: Table Of Contents
Contents Page Safety precautions .................... 2 Filling up hydraulic oil ..................2 Technical data ....................3 Starting instructions ..................4 Service, maintenance and hydraulic settings ............4 Fault location ....................5 Oil types ......................7 EC-Declaration of Conformity ................8 Warranty conditions .................. -
Page 3: Safety Precautions
Safety Precautions 1. Always use protective earplugs. The powerpack complies with the EU noise limits, but by daily long-lasting operation there is a risk of hearing defects. 2. Always connect hoses before starting. 3. Never add fuel and oil when the engine is running. 4. -
Page 4: Technical Data
Technical Data Hydraulics The powerpack is mounted with a pressure relief valve to avoid a too high pressure. Furthermore, the very efficient air cooling protects the powerpack against super- heating. Oil flow 18 l.p.m at 3300 r.p.m. Working pressure nominal 100 bar Pressure relief valve Set at 110 bar... -
Page 5: Starting Instructions
Starting Instructions Please observe the starting instructions on the front of the powerpack. Start: • • • • Check engine oil level • Check hydraulic oil level at sight glass • Connect hoses and tool • Switch fuel tap to “ON” •... -
Page 6: Fault Location
Fault Location Start by checking the hydraulic settings Before starting, check the oil level at the sight HYCON Test Equipment glass. Item No. 4040062 Check the working pressure by means of the test equipment. The test equipment com- prises a pressure gauge, a flow meter and a valve for adjustment of pressure. - Page 7 The pressure relief valve is placed on the right side of the valve block. 1. Connect the test equipment, start the powerpack and move the lever to “ON”. Then close the valve - the pressure gauge must show 110 bar. If the pressure relief valve does not show 110 bar, adjust the valve by loosening the lock nut and turning the adjustment screw in or out.
-
Page 8: Oil Types
Oil Types The HYCON powerpack uses standard hydraulic oil, i.e. all types of mineral oil and biodegradable oil, which comply with the following values: Recommended viscosity 20-40 cSt Permitted viscosity 15-1000 cSt Viscosity index Min. 100 Temperature area -20° to +70° C... -
Page 9: Ec-Declaration Of Conformity
Fax: +45 9647 5201 Mail hycon@hycon.dk www.hycon.dk We hereby declare that HPP06 hydraulic powerpack – from serial No. 5688 (with 4.8 kW petrol engine) is manufactured in conformity with the EC Directives 2006/42/EC and 2000/14/EC. Notified Body 1585: AkustikNet A/S Frederikssundsvej 179 B DK-2700 Brønshøj... -
Page 10: Warranty Conditions
Warranty Conditions We grant 12 months warranty from the first date of operation – however, not more than 18 months from the date of delivery. The warranty applies to faults that can be related to construction and production errors. Faults caused by incorrect operation, incorrect handling, lack of maintenance or the like will not be accepted as warranty.
