Operating Manual
HPP13D
Hydraulic Powerpack
From S/N 8264
Revised 30.08.2013
Prior to Operation
We thank you for choosing a
HYCON powerpack.
Please note that the powerpack is
delivered without hydraulic oil,
and therefore it must be filled up
with hydraulic oil prior to
operation.
To ensure smooth operation and
long-lasting performance of your
new powerpack, we recommend
that you study this operating
manual carefully and pay special
attention to the
Safety and Service
Precautions
We hope you will be satisfied
with your new HYCON power-
pack.
Best regards
HYCON A/S
HYCON A/S
Juelstrupparken 11
DK-9530 Støvring
Denmark
Tel: +45 9647 5200
Fax: +45 9647 5201
Mail
hycon@hycon.dk
www.hycon.dk
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HYCON HPP13D
Summary of Contents for HYCON HPP13D
- Page 1 HYCON A/S attention to the Juelstrupparken 11 DK-9530 Støvring Safety and Service Denmark Precautions Tel: +45 9647 5200 Fax: +45 9647 5201 We hope you will be satisfied Mail hycon@hycon.dk www.hycon.dk with your new HYCON power- pack. Best regards HYCON A/S...
-
Page 2: Table Of Contents
Contents Page Safety Precautions .....................2 Filling up Hydraulic Oil ....................2 Technical Data ......................3 Starting Instructions ....................4 Service, Maintenance and Hydraulic Settings ..............5 Oil Types ........................6 Warranty Terms ......................7 Spare Parts List ......................8... -
Page 3: Safety Precautions
Safety Precautions 1. Always use protective earplugs. The powerpack complies with the EU noise limits, but by daily long-lasting operation there is a risk of hearing defects. 2. Always connect hoses before starting. 3. Never add fuel and oil when the engine is running. 4. -
Page 4: Technical Data
The HYCON HPP13D open centre hydraulic powerpack is designed in accordance with the EHTMA categories C and D, which prescribe a minimum performance of 20 l.p.m. at 138 bar and 30 l.p.m. at 138 bar, respectively. The HPP13D is available in one version: •... -
Page 5: Starting Instructions
Starting Instructions Manual Start Electric Start Electric start of powerpack. Manual start of powerpack. Lever is pushed towards the engine block. Lever is pushed away from the engine block. Engine can be turned on and stopped by turning Engine cannot be turned on and stopped by ignition key. -
Page 6: Service, Maintenance And Hydraulic Settings
Service, Maintenance and Hydraulic Settings Service/Maintenance Daily Weekly Yearly Engine oil Check 1 x replacement Hydraulic oil Check 1 x replacement Hydraulic oil filter *) 1 x replacement Check hoses (tighten up if needed) Air filter 1 x replacement Fuel filter 1 x replacement *) Use only filters with by-pass Hydraulic Settings... -
Page 7: Oil Types
Oil Types The HYCON powerpack uses standard hydraulic oil, i.e. all types of mineral oil and biodegradable oil, which comply with the following values: Recommended viscosity 20-40 cSt Permitted viscosity 15-1000 cSt Viscosity index Min. 100 Temperature area -20° to +70° C... -
Page 8: Warranty Terms
Warranty Terms We grant 12 months warranty from the first date of operation – however, not more than 18 months from the date of delivery. The warranty applies to faults that can be related to construction and production errors. Faults caused by incorrect operation, incorrect handling, lack of maintenance or the like will not be accepted as warranty.
