WALL MOUNTED, ROOM SEALED,
FAN ASSISTED, GAS COMBINATION BOILER,
COMPUTERISED AND SYNTHESIZED VOICE
TECHNICAL
INFORMATION
INSTALLATION
and
SERVICE
INSTRUCTIONS
Read these Instructions thoroughly before
using the appliance
Phone numbers:
Installer
FERROLI HELPLINE
FOR SERVICE INFORMATION OR
Service Engineer
HELP TELEPHONE: 08707 282 885
ALWAYS QUOTE YOUR SERIAL NUMBER
FOR IMMEDIATE ASSISTANCE
Serial No.
ALL SPECIFICATIONS SUBJECT TO CHANGE
Lichfield Road, Branston Industrial Estate, Burton Upon Trent, Staffordshire DE14 3HD
Tel. 08707 282 885 - Fax 08707 282 886
Advertisement
Table of Contents
Related Manuals for Ferroli XIGNAL CE
Summary of Contents for Ferroli XIGNAL CE
- Page 1 INSTALLATION SERVICE INSTRUCTIONS Read these Instructions thoroughly before using the appliance Phone numbers: Installer FERROLI HELPLINE FOR SERVICE INFORMATION OR Service Engineer HELP TELEPHONE: 08707 282 885 ALWAYS QUOTE YOUR SERIAL NUMBER FOR IMMEDIATE ASSISTANCE Serial No. ALL SPECIFICATIONS SUBJECT TO CHANGE Lichfield Road, Branston Industrial Estate, Burton Upon Trent, Staffordshire DE14 3HD Tel.
-
Page 3: Table Of Contents
INDEX Page Introduction Related documents General description Technical data Appliance dimensions Boiler flow diagram Boiler main parts Installation details Location of boiler Terminal position Air supply Minimum clearance Flue system Gas supply Water system Control heating pump Additional expansion vessel Installation of boiler Preparing flue assembly Connecting the boiler... -
Page 4: Introduction
The new concept of XIGNAL CE is that it is fitted with a microcomputer to regulate the boiler performance through technically sophisticated controls. This guarantees correct and optimum operation while being extremely simple to use. -
Page 5: General Description
GENERAL DESCRIPTION The boiler is able to operate with two types of fuel gas: natural or propane (L.P.G.). The type of gas should be chosen when the boiler is ordered. Conversions can also be carried out during the installation phase .The boiler is controlled by an internal microcomputer and all settings to the regulating systems are carried out on the assembly line by use of software. -
Page 6: Technical Data
Technical data NATURAL GAS (G20) PROPANE LPG (G31) Nominal heat input (gross caloric value) 34.8 kW 34.0 kW Minimum heat input (gross caloric value) 15.1 kW 14.8 kW Nominal heat input (net caloric value) 31.3 kW 31.3 kW Minimum heat input (net caloric value) 13.6 kW 13.6 kW Nominal heat output... -
Page 7: Appliance Dimensions
Appliance Dimensions FRONT VIEW LEFT SIDE VIEW REAR VIEW 97.5 77.5 1. Electricity cable entry 2. Gas supply 3. Domestic Hot Water outlet 4. Domestic Cold Water inlet TOP VIEW 5. Central Heating Pressure relief valve 6. Central Heating Flow outlet 7. - Page 8 Model Water Bye Laws. S.p.A. 124749 AUTO 1...4 Fig. 2...
-
Page 9: Boiler Flow Diagram
Boiler flow diagram Main parts Air pressure switch Gas valve Fixing point Gas valve modulator Room sealed compartment Burner pressure test point Instrument panel Overheat thermostat Gas inlet Heat exchanger venting point Domestic hot water outlet Temperature sensing phial Domestic hot water inlet Expansion tank Central heating flow Fan air inlet pressure test point... -
Page 10: Installation Details
Location of Boiler The installation of the XIGNAL CE must be on a suitable non-combustible load bearing wall which will provide an adequate fixing for the boiler mounting bracket assembly. The location should be in an area where the water pipes will not be subjected to frost conditions. -
Page 11: Minimum Clearance
Terminal Position Air supply APPLIANCE FLUE SYSTEM ROOM-SEALED AIR VENT AREAS APPLIANCE LOCATION IN ROOM AIR VENT HIGH LEVEL: 252 cm (38 in. IN COMPARTMENT OPEN TO ROOM LOW LEVEL: 252 cm (38 in. AIR VENT Fig. 3 HIGH LEVEL: 126 cm (19 in. -
Page 12: Flue System
Flue system The boiler allows the flue outlet to be taken from the rear of the boiler or from either side. A standard flue length of 0.75 metres is provided. Alternative lengths of two or three metres can be supplied (equivalent to wall thicknesses of up to 565, 1815 and 2815 mm for rear flues and deduct 91 mm plus distance from side wall for side outlet flues). - Page 13 Cold water Additional expansion vessel C.H. (if required) Filling point C.H. Bypass Fig. 6 NOTE: A bypass must be fitted as far as possible from the boiler if thermostatic radiator valves are fitted throughout. 1. Filling point C.H. 2. Temporary connection Fig.
-
Page 14: Additional Expansion Vessel
Built-in Central Heating Water Circulating Pump The pump head available for circulating the water is given in fig. 8. N.B. - The pump is factory set at position 3. The pump is a Grundfos type 15-50 UPS series. Grundfos Pump performance graph Note - Minimum flow through boiler heat exchanger at any time should not fall below 6 litres per minute. - Page 15 Installation Note - To mount the boiler on the wall, a two person lift will be needed. UNPACKING The appliance is delivered in 2 cartons. The large carton contains the boiler, the Installation/Servicing and Users Instructions, external and internal sensors. The second carton contains the mounting jig assembly, complete with isolating valves, the assembly fixing screws and wall plugs (x4), the boiler mounting nuts and washers (x2), drilling template, flue assembly and turret.
- Page 16 Important Note - Always use two spanners to prevent twisting of soft copper pipework on the boiler. Flush out the water system. Note - The maximum inlet cold water pressure must not exceed 10 bar (145 P.S.I.) and a water governor or a pressure reducing valve will be required if the pressure is in excess of 5 bar (72 P.S.I.).
- Page 17 PREPARING THE FLUE ASSEMBLY Rear Flue Outlet (fig. 12) Important - The aluminium flue pipe must protrude into the outside grill by 2 in (50 mm), never cut it to the same length as the plastic air pipe (aluminium flue pipe = plastic air inlet pipe + 50 mm !). Aluminium flue pipe length = Plastic air inlet pipe length plus 50 mm (2") longer.
-
Page 18: Connecting The Boiler
5.0 CONNECTING THE BOILER 5.1 Place the boiler on its back. 5.2 Remove the boiler base plate, four screws (fig. 16). Remove the plugs fitted to the boiler water connections. Remove the bag of sealing washers from the boiler pipework. Remove the front panel by sliding up and pulling away from the main boiler. - Page 19 Fixing points Fig. 15 Lift here Fixing screws Fig. 16 Fig. 17...
-
Page 20: Fitting The Flue Assembly
I.E.E. Regulation and in Scotland, the electrical provisions of the Building regulations. Remote sensors The XIGNAL CE is supplied with an internal and external sensor to ensure maximum fuel savings. Room Sensor To be in a position within the property normally used for a room thermostat. -
Page 21: Wiring Diagram
Wiring diagram brown blue VOLTAGE brown brown black 1 2 3 4 1 2 3 4 5 6 7 1 2 3 4 5 6 7 white green white HDR1 voice volume yellow green orange white green black white AUTO 1...4 Fig. -
Page 22: External Sensor Location
External sensor location The external sensor should preferably be installed on the North, North-East wall or on the one facing the majority of the main living rooms in the building. The sensor must never be exposed to the first morning sunlight. Where possible, it must never be subjected to direct sunlight and should be protected if necessary. - Page 23 8 Gas conversion Only Qualified Personnel may carry out the following regulating and conversion operations. Ferroli S.p.A. declines all responsibility for damage to persons and/or property caused by unauthorized persons having tampered with the appliance. Proceed with the following conversions if the appliance must be used with a different type of gas.
- Page 24 Delicately depress pin "d" and keep it fully pressed down. If the maximum pressure value must be adjusted, slowly turn adjuster nut “e” in a clockwise direction to increase the pressure and in an anticlockwise direction to lower the pressure value. Having regulated the minimum and maximum pressure values, reset compensating tap "b".
- Page 25 Honeywell VR 4600 N 4002 valve with V7335A4014 Modureg Gas pressure Adjustment With the burner lit: Connect suitable pressure gauge to burner test point "B", and then: Disconnect air pressure compensation tube "H"; Disconnect the wires from coil "C" of the Modureg; Remove protective cover "D";...
-
Page 26: Control Panel
10. Control panel Open the hinged door for access to the programming keyboard and combined display. The instructions enabling the user to program the system are affixed to the inner part of the door. KEYBOARD The touch keyboard has been designed for immediate and simple programming. The buttons are logically grouped according to the function in question. - Page 27 DISPLAY The alphanumerical display with 2 lines of 16 characters allows the user to check the operational parameters of the boiler at any moment and to check the duration at the end of sanitary water production or heating mode. The programmed values can also be displayed, plus the relative flow rate and temperature during the production of sanitary water.
- Page 28 10.1 Programming the daily heating function Clock adjustment Press key Adjust the time using the left-hand keys SET TIME 18:10 Programming the 4 daily heating levels Press the key once or several times to set the programming level (respectively Levels 1-2- 1...4 3-4-5-6).
- Page 29 10.2 Programming the boiler parameters General information For access to the boiler programming parameters, just depress the relative function keys. The display indications will consequently change. Note that each key correspond to a single function. After having selected a function, it will be possible to quit data entry mode in two ways: - automatically after 8 sec.
- Page 30 Graph of plant delivery temperatures according to the external temperature and the set compensation curve. EXTERNAL TEMPERATURE ( ° C) TEMPERATURA ESTERNA (°C) Fig. 25...
- Page 31 Regulating the hot water temperature Press key once. Set the temperature of the hot water to the required value between 40 and 65°C using the right-hand keys . It is unadvisable to exceed a temperature of 50°C. Also remember that, when multiplied by the water flow rate per minute and for 60 minutes, the product of the temperature difference between the D.H.W.
- Page 32 10.3 Switching the boiler on and off Inspections to make when switching on for the first time When the boiler is being switched on for the first time, it is advisable to check that: the on-off valves between the boiler and systems are open; the entire system is well charged and vented;...
-
Page 33: Routine Maintenance
11 Maintenance and troubleshooting 11.1 Routine maintenance Only Qualified Personnel must carry out the following operations. Seasonal inspections of the boiler It is advisable to have Qualified Personnel check the appliance at least once a year: The pressure of the water in the cold plant must be between 0.5 and 1 bar. Check that it does not exceed 1.5 bar when hot;... -
Page 34: Diagnosis And Troubleshooting
11.2 Diagnosis and troubleshooting The microcomputer will make a complete diagnosis during boiler operation. When a fault is detected, the display will flash and give an error message. Boiler operation will be inhibited and reset at the end of the fault. Manual reset is sometimes necessary (digit key List of diagnostic messages The display and vocal message clearly indicate all types of fault. - Page 35 Defective pressure switch or clogged tubes ER 5 FAULT Check connections AIR PRESS SWITCH Replace pressure switch or clean tubes ER 6 BROKEN Water temperature too high PROTECT SENSOR ER 7 FAULT Defective heating temperature sensor Check connections or replace the sensor C.H.
- Page 36 Phone numbers: Installer Service Engineer BECAUSE OF OUR CONSTANT ENDEAVOUR FOR IMPROVEMENT DETAILS MAY VARY SLIGHTLY FROM THOSE QUOTED IN THESE INSTRUCTIONS. ALL SPECIFICATIONS SUBJECT TO CHANGE Lichfield Road, Branston Industrial Estate, Burton Upon Trent, Staffordshire DE14 3HD Tel. 08707 282 885 - Fax 08707 282 886...
