Mega Lite UniColor User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL

Table of Contents

DMX Profile Menu.............................................................................................................8
Parts List...............................................................................................................................9
.
. 3
.. 4
.. 6
...
...... 6
7
.9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UniColor and is the answer not in the manual?

Questions and answers

Related Manuals for Mega Lite UniColor

Summary of Contents for Mega Lite UniColor

  • Page 1: Table Of Contents

    USER MANUAL Table of Contents Safety Information Specifications .. 4 Main Power Connection .. 6 DMX-512 Connection ..6 Main Control Menu DMX Profile Menu......................8 Rigging the Fixture Cleaning & Maintenance....................9 Parts List..........................9...

  • Page 3: Safety Information

    Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5.

  • Page 4: Specifications

    Specifications Part Fixture 7100-UniColor CM5 White 3W (Warm White, Cool White) 7101-UniColor CM5 Color 3W (Red, Green, Blue, Amber) 7102-UniColor CM5 UV 3W (UV) 7103-UniColor CM5 White 5W (Warm White, Cool White) Mechanical Specifications DMX Connections: XLR 3 pin Or XLR 5 Pin...
  • Page 5 Ordering Information LED Color Beam Angle Fixture Color DMX Input Item Number 7100 18x3W Warm White 15° BLAK Black 3 pin in and out Cool White 25° WHIT White 5 pin in and out 45° XXXX Custom 7101 18x3W 60° Green Blue Amber...

  • Page 6: Main Power Connection

    Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. This fixture is equipped with a auto switchable power supply that will let the unit operate from 110V or 220V from 50Hz to 60Hz.

  • Page 7: Main Control Menu

    Main Control Menu for 7100, 7101, 7102 and 7103 LED model The control board on the fixture base is your interface to access and control CONTROL BOARD all the functions on the unit. Its digital display gives you a code view of the options and functions.

  • Page 8: Dmx Profile Menu

    DMX Profile for 7100, 7101, 7102 and 7103 LED model UniColor 1Channel DMX Chanel Function Description Value Dimmer Single Color LED intensity 0-255 UniColor 2 Channel DMX Chanel Function Description Value Dimmer Single Color LED intensity 0-255 Strobe Strobe (slow to fast)

  • Page 9: Rigging The Fixture

    When rigging the unit always be secured with a secondary safety attachment. The installation location of the UniColor CM5 has got to be built in the way that it can hold 10 times the weight for 1 hour with out any harming. Installation should be checked at least one time a year by a skilled person.

  • Page 10: Warranty Information

    Warranty Information Limited Warranty Unless otherwise stated, your product is covered by a one year parts and labor limited warranty. Dichroic filters and glass gobos are not guaranteed against breakage or scratches to coating. It is the owner s responsibility to furnish receipts or invoices for verification of purchase, date, and dealer or distributor.
