Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information Specifications Photometrics Main Power Connection DMX-512 Connection DMX Profile Main Control Menu Size and Weight Rigging the Fixture Cleaning & Maintenance... -
Page 3: Safety Information
Check that the unit has not been damaged during transport Check that the unit has not been damaged during transport Protection Against Fire Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 1. Maintain a minimum of 1 foot distance from any type of flame. 3. -
Page 4: Specifications
Technical Information Part Numbers Fixture Item # 4340—Obra Flood N180 Mechanical Specifications Signal Connectors: Panel Mounted 5-pin XLR connectors in/out Power Connectors: Panel Mount Power Con type in/out connection (Nema 5-15 to Blue power male cable included) Thermal: Maximum ambient temperature 40° C Maximum surface temperature 60°... -
Page 5: Photometrics
Photometrics Obra Flood N180 Obra Flood N180... -
Page 6: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz Cable (USA) -
Page 7: Dmx Profile
DMX Profile Obra Flood N180 4 Channel Mode DMX Channel Function Description Value Init LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 LED Color Amber LED Intensity 0-255 Obra Flood N180 9 Channel Mode... - Page 8 Obra Flood N180 14 Channel Mode DMX Channel Function Description Value Init Dimmer Dimmer 0-255 LED Color Dark Red LED Intensity 0-255 LED Color Red LED Intensity 0-255 LED Color Fire Red Intensity 0-255 LED Color Green LED Intensity 0-255...
-
Page 9: Main Control Menu
The control board on the fixture is your interface to access and control all the functions on the unit. Its digital display gives you a code view of Mega Lite the options and functions. The following will explain each function and Obra Flood its options. - Page 10 Menu: Dim Curve Dim Curve Press Center Red Knob to select dim curve type turn knob left or right to select fixture dimmer setting, Press Set to confirm the setting (note: there is 0,1,2,3,4 options) Menu: Temperature Press Center Red Knob to read current temperature Menu: Info Fan:...
-
Page 11: Size And Weight
Size and Weight 12.75” 3.5” 11.75” 6” 2.5” 5.33” Size 12.75” x 5.33” x 11.75” Packaged Size 15” x 12.5” x 8” Weight 14lb Gross 15lb... -
Page 12: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. -
Page 13: Cleaning & Maintenance
Cleaning and Maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electronics checked by an expert every 2 years. The following points have to be considered during the inspection: 1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded. - Page 14 Customer Support Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob- lem. Please visit our website for any other related technical documents. For service related issue please contact our service dept.
