USER MANUAL
Table of Contents
Safety Information.......................................................................................................... 3
Specifications.................................................................................................................... 4
Main Power Connection............................................................................................... 5
DMX-512 Connection................................................................................................... 5
DMX Profile......................................................................................................................... 6
Main Control Menu.......................................................................................................... 7
Rigging the Fixture..........................................................................................................9
Parts List.............................................................................................................................. 9
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mega Lite 4070-N-E Color Punch
Summary of Contents for Mega Lite 4070-N-E Color Punch
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information……………………………………………………………………………………………. 3 Specifications…………………………………………………………………………………………………….. 4 Main Power Connection………………………………………………………………………………….. 5 DMX-512 Connection…………………………………………………………………...……………..5 DMX Profile......................... 6 Main Control Menu......................7 Rigging the Fixture…………………………………………………………………………………………….9 Cleaning & Maintenance....................9 Parts List..........................9... -
Page 3: Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Technical Information
Technical Information Part Numbers Fixture 4070-N-E Color Punch Mechanical Specifications 10.25” DMX Connectors: 3-pin XLR connectors in/out Power Connections: Neutrik Power Con in/out Thermal: Maximum ambient temperature 40° C Maximum surface temperature 60° C Display: Digital 7.75” Fastening System: Mounting Yoke 9.25”... -
Page 5: Main Power Connection
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a 120 Ohm resistor between the (-) and the (+) signal into a 3 pin XLR plug and plug it in to the last fixture on the signal run. Pre-manufactured terminator plugs are available for purchase from your Mega-Lite dealer (HOS-DMXT). -
Page 6: Dmx Profile
N-E Color Punch Mode A DMX Chanel Function Description Value LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 N-E Color Punch Mode P DMX Chanel Function Description Value Dimmer 0-152 Strobe (slow to fast) 153-196 Dimmer... -
Page 7: Main Control Menu
Main Control Menu CONTROL BOARD The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options and functions. The following will explain each function and its options. Menu Down Enter DMX Address... - Page 8 Flash This function allows you to strobe the LED’s on the whole module in White color. Press Enter use the up/down keys to select desired flash settings. Press Enter to confirm the settings. Fade Scroll This function allows you to fade the LED’s on the whole module from one color to another. Press Enter use the up/down keys to select desired fade speed settings.
-
Page 9: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. - Page 10 Mega-Lite 5718 Kenwick St San Antonio, TX 78238 Ph 210-684-2600 Fax 210-855-6279 www.mega-lite.com / info@mega-lite.com...
