Icom IC-A110EURO Service Manual Addendum page 5

Oct. 2008
[FRONT UNIT]
REF ORDER
NO. NO.
IC1 1140008780 S.IC HD6433823A19D
1140009830 S.IC HD6433823A80D
IC2 1110005771 S.IC S-80942CNMC-G9CT2G
IC3 1130007111 S.IC TC7W04FU
IC4 1130011321 S.IC CAT25C16VI-TE13
IC5 1130007570 S.IC BU4094BCFV-E2
Q1 1590000440 S.TR DTA143ZUA T106
Q2 1510000881 S.TR 2SA1622-6-TL-E
Q3 1530003281 S.TR 2SC4211-6-TL-E
Q4 1590001980 S.TR XP4315 (TX)
Q5 1590000440 S.TR DTA143ZUA T106
Q6 1590000680 S.TR DTC114EUA T106
Q7 1590000680 S.TR DTC114EUA T106
D5 1790001280 S.DIO MA111 (TX)
D6 1750000130 S.DIO DA204U T106
X1 6060000770 S.CER EFOP3684E5
L1 6200003960 S.COL MLF1608A 1R0K-T
L2 6200003540 S.COL MLF1608D R22K-T
R1 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R2 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R3 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R4 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R5 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R6 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R7 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R8 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R10 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R11 7030003370 S.RES ERJ3GEYJ 271 V (270)
R12 7030003350 S.RES ERJ3GEYJ 181 V (180)
R13 7030003350 S.RES ERJ3GEYJ 181 V (180)
R14 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R15 7030003590 S.RES ERJ3GEYJ 183 V (18 k)
R16 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
R17 7030003620 S.RES ERJ3GEYJ 333 V (33 k)
R18 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R19 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R20 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R21 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R22 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R23 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R24 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R26 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R27 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R28 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R29 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R30 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R31 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R32 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R33 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R34 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R36 7030003600 S.RES ERJ3GEYJ 223 V (22 k)
R37 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R38 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R41 7030003610 S.RES ERJ3GEYJ 273 V (27 k)
R42 7030003610 S.RES ERJ3GEYJ 273 V (27 k)
R43 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R44 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R45 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R46 7030003610 S.RES ERJ3GEYJ 273 V (27 k)
R47 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
C1 4030006860 S.CER C1608 JB 1H 102K-T
C2 4030006860 S.CER C1608 JB 1H 102K-T
C3 4030007090 S.CER C1608 CH 1H 470J-T
C4 4030007090 S.CER C1608 CH 1H 470J-T
C5 4030006860 S.CER C1608 JB 1H 102K-T
C6 4030007090 S.CER C1608 CH 1H 470J-T
C7 4030006850 S.CER C1608 JB 1H 471K-T
C8 4030006850 S.CER C1608 JB 1H 471K-T
C9 4030008560 S.CER C1608 CH 1H 300J-T
C10 4030008560 S.CER C1608 CH 1H 300J-T
C11 4030008890 S.CER C1608 JB 1H 273K-T
C12 4030011600 S.CER C1608 JB 1E 104K-T
C13 4030011600 S.CER C1608 JB 1E 104K-T
C14 4030011600 S.CER C1608 JB 1E 104K-T
C15 4030007090 S.CER C1608 CH 1H 470J-T
C16 4030011600 S.CER C1608 JB 1E 104K-T
C17 4030011600 S.CER C1608 JB 1E 104K-T
PARTS LIST
DESCRIPTION
Except [A110EURO]
[A110EURO]
Except [A110EURO]
Except [A110EURO]
[FRONT UNIT]
REF ORDER
NO. NO.
C18 4030006860 S.CER C1608 JB 1H 102K-T
C19 4030006860 S.CER C1608 JB 1H 102K-T
C20 4030011600 S.CER C1608 JB 1E 104K-T
C21 4030006860 S.CER C1608 JB 1H 102K-T
C22 4030011600 S.CER C1608 JB 1E 104K-T
C23 4550006480 S.TAN TEESVA 1C 475M8R
C24 4030011600 S.CER C1608 JB 1E 104K-T
C25 4030011600 S.CER C1608 JB 1E 104K-T
C26 4030011600 S.CER C1608 JB 1E 104K-T
C27 4550006250 S.TAN TEESVA 1A 106M8R
C28 4030006860 S.CER C1608 JB 1H 102K-T
C29 4030006860 S.CER C1608 JB 1H 102K-T
C30 4030006890 S.CER C1608 JF 1H 103Z-T
4030007090 S.CER C1608 CH 1H 470J-T
C31 4030006860 S.CER C1608 JB 1H 102K-T
C32 4030006860 S.CER C1608 JB 1H 102K-T
C33 4030006860 S.CER C1608 JB 1H 102K-T
C34 4030006860 S.CER C1608 JB 1H 102K-T
C35 4030006860 S.CER C1608 JB 1H 102K-T
C36 4030006860 S.CER C1608 JB 1H 102K-T
C37 4030007090 S.CER C1608 CH 1H 470J-T
C38 4030006860 S.CER C1608 JB 1H 102K-T
J1 6510020511 S.CNR FH12-40S-0.5SV (55)
J2 6450001471 CNR 95003-2881
DS1 5030001740 LCD HLC7453-012400
DS2 5040002030 S.LED CL-170Y-CD-T
DS3 5040002030 S.LED CL-170Y-CD-T
DS4 5040002030 S.LED CL-170Y-CD-T
DS5 5040002030 S.LED CL-170Y-CD-T
DS6 5040002030 S.LED CL-170Y-CD-T
DS7 5040002030 S.LED CL-170Y-CD-T
S1 2250000420 ECR EVQB2CFC620B
SP1 2510000880 SP SME-45W Except [GEN], [AUS]
2510000881 SP SME-C45W0819 [GEN], [AUS]
W1 7120000470 JMP ERDS2T0
W2 7120000470 JMP ERDS2T0
W3 7030003860 S.RES ERJ3GE JPW V
W4 7030003860 S.RES ERJ3GE JPW V
W6 8900007680 CBL OPC-741 (N:40 L:55)
W6 8900007682 CBL OPC-741A-1 (P0.5,N40,L55)
EP2 8930037960 LCT SRCN-1705 ZSS
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
1
DESCRIPTION
[A110EURO]
Except [A110EURO]
[A110EURO] only
[A110EURO] only
S.=Surface mount
