Icom IC-A110EURO Service Manual Addendum page 21

Jun. 2008
[MAIN UNIT]
REF ORDER
NO. NO.
C110 4030012600 S.CER C2012 JB 1A 105M-T
C112 4550006220 S.TAN TEESVA 0J 156M8R
C113 4510008540 S.ELE EEE1CA100SR
C114 4550007610 S.TAN F931E474MAABMA
C115 4030006860 S.CER C1608 JB 1H 102K-T
C116 4030006900 S.CER C1608 JB 1H 103K-T
C117 4030009970 S.CER C1608 JB 1H 182K-T
C118 4030009630 S.CER C1608 JB 1H 822K-T
C119 4030007130 S.CER C1608 CH 1H 101J-T
C120 4030012610 S.CER C2012 JB 1C 474K-T
C121 4030006900 S.CER C1608 JB 1H 103K-T
C122 4030006860 S.CER C1608 JB 1H 102K-T
C123 4550006220 S.TAN TEESVA 0J 156M8R
C124 4030006860 S.CER C1608 JB 1H 102K-T
C126 4030011600 S.CER C1608 JB 1E 104K-T
C127 4030006900 S.CER C1608 JB 1H 103K-T
C128 4030011600 S.CER C1608 JB 1E 104K-T
C129 4510007980 S.ELE 16SVP22M-AIC
C130 4030006860 S.CER C1608 JB 1H 102K-T
C131 4030006860 S.CER C1608 JB 1H 102K-T
C132 4550007360 S.TAN F931A226MBABMA
C133 4550007610 S.TAN F931E474MAABMA
C134 4550007360 S.TAN F931A226MBABMA
C135 4030006860 S.CER C1608 JB 1H 102K-T
C138 4510008540 S.ELE EEE1CA100SR
C139 4030006860 S.CER C1608 JB 1H 102K-T
C140 4030006860 S.CER C1608 JB 1H 102K-T
C141 4030006860 S.CER C1608 JB 1H 102K-T
C148 4030006860 S.CER C1608 JB 1H 102K-T
C153 4030012600 S.CER C2012 JB 1A 105M-T
C154 4030007050 S.CER C1608 CH 1H 220J-T
C156 4030011600 S.CER C1608 JB 1E 104K-T
C164 4030006860 S.CER C1608 JB 1H 102K-T
C165 4030011770 S.CER C1608 CH 1H 060B-T
C167 4030006860 S.CER C1608 JB 1H 102K-T
C168 4510008750 S.ELE EEE1HA0R1SR
C170 4030012600 S.CER C2012 JB 1A 105M-T
C175 4550007260 S.TAN F931C475MAABMA
C177 4550007270 S.TAN F931A475MAABMA
C188 4030007070 S.CER C1608 CH 1H 330J-T
C189 4030006860 S.CER C1608 JB 1H 102K-T
C190 4030009500 S.CER C1608 CH 1H 0R5B-T
C192 4030007010 S.CER C1608 CH 1H 100D-T
4030007030 S.CER C1608 CH 1H 150J-T [A110EURO]
C193 4030006860 S.CER C1608 JB 1H 102K-T
C195 4030009990 S.CER C1608 CH 1H 200J-T
C206 4510008510 S.ELE EEE1CA471P
C208 4030007130 S.CER C1608 CH 1H 101J-T
C209 4030012610 S.CER C2012 JB 1C 474K-T
C211 4510007320 ELE 50 YXG 470M
C212 4510007320 ELE 50 YXG 470M
C213 4030006860 S.CER C1608 JB 1H 102K-T
C214 4030006860 S.CER C1608 JB 1H 102K-T
C217 4030007080 S.CER C1608 CH 1H 390J-T
C218 4030006860 S.CER C1608 JB 1H 102K-T
C220 4030006860 S.CER C1608 JB 1H 102K-T
C224 4030011600 S.CER C1608 JB 1E 104K-T
C226 4550005980 S.TAN TEESVA 1A 475M8R
C228 4030006900 S.CER C1608 JB 1H 103K-T
C229 4030006900 S.CER C1608 JB 1H 103K-T
C230 4030006900 S.CER C1608 JB 1H 103K-T
C231 4030006860 S.CER C1608 JB 1H 102K-T
C232 4030010210 S.CER C3216 JB 1C 105M-T
C233 4030012600 S.CER C2012 JB 1A 105M-T
C234 4030012600 S.CER C2012 JB 1A 105M-T
C235 4030006900 S.CER C1608 JB 1H 103K-T
C241 4030011190 S.CER GRM31M2C2H270JV01L
C242 4030018330 S.CER ERF22X 6C2H 820J D01L
C249 4030006860 S.CER C1608 JB 1H 102K-T
C250 4030006860 S.CER C1608 JB 1H 102K-T
C251 4030006860 S.CER C1608 JB 1H 102K-T
C253 4030006860 S.CER C1608 JB 1H 102K-T
C255 4030006860 S.CER C1608 JB 1H 102K-T
C256 4030008880 S.CER C1608 JB 1H 223K-T
C257 4030009970 S.CER C1608 JB 1H 182K-T
C258 4030006900 S.CER C1608 JB 1H 103K-T
C259 4030008860 S.CER C1608 JB 1H 153K-T
C260 4030006860 S.CER C1608 JB 1H 102K-T
C261 4030008880 S.CER C1608 JB 1H 223K-T
C262 4030011340 S.CER C1608 CH 1H 471J-T
C263 4030012660 S.CER C1608 JB 1E 683K-T
C264 4030007120 S.CER C1608 CH 1H 820J-T
C265 4030011600 S.CER C1608 JB 1E 104K-T
C266 4030011600 S.CER C1608 JB 1E 104K-T
C267 4030011600 S.CER C1608 JB 1E 104K-T
C268 4030011600 S.CER C1608 JB 1E 104K-T
C277 4030006860 S.CER C1608 JB 1H 102K-T
C279 4030007000 S.CER C1608 CH 1H 090D-T
C286 4030009500 S.CER C1608 CH 1H 0R5B-T
C288 4030006860 S.CER C1608 JB 1H 102K-T
C289 4030011600 S.CER C1608 JB 1E 104K-T
C290 4030011600 S.CER C1608 JB 1E 104K-T
C292 4030008920 S.CER C1608 JB 1H 473K-T
C293 4030010760 S.CER C1608 CH 1H 331J-T
C295 4030006860 S.CER C1608 JB 1H 102K-T
C298 4510008740 S.ELE EEE1HA330P
C299 4030006890 S.CER C1608 JF 1H 103Z-T
DESCRIPTION M.
LOCATION
B 106.4/11.9
B 109.4/26.5
T 101.3/21.9
B 96.3/21.4
B 96.3/26.7
T 107.9/26
T 113.4/11.9
T 110.6/8.5
T 108.5/5.7
B 6.8/21.4
T 103.5/5.7
T
T 100.6/39.8
T 101.4/44.7
B
B 56.5/44.8
B 42.3/66.8
T 80.4/16.5
T
B 72.8/18.6
T 73.4/15.3
T 65.3/15.6
T
T 61.3/16.3
T 98.7/76.7
B
B 86.8/81.9
T 82.3/73.6
B 108.8/77.3
T 59.9/34.2
B 125.8/15.6
B 111.2/44.3
T 131.7/76.5
T 130.9/73.8
B 72.4/59.7
T 74.9/57.3
T 105.3/45.8
B 115.4/66.4
B 57.2/39.9
T 90.7/37.2
T 87.9/42.7
T
[A110] T 80.6/45.2
T 80.6/45.2
T 87.7/48.8
T 78.3/48.4
T 10.3/98.5
B
B
B 82.4/29.3
T 99.4/32.2
T 48.5/86.4
B 45.6/105.1
T 74.3/78.6
B 122.5/33.4
T 96.8/33.4
B 121.1/31.9
B
B 123.5/19.3
B 35.2/52.1
B
B 112.2/4.2
B 116.1/12.7
B 126.2/8.3
B 82.9/104
B 76.8/102
B 45.3/100.6
T 73.3/66.7
B 91.6/67.7
B 103.1/78.6
B 114.4/47.7
B 65.8/24.9
B 60.4/23.6
B 68.7/23.6
B 63.8/28.6
B
B 61.3/34.8
B 58.3/33.4
B 55.2/29.6
B 55.4/26.7
B
T 113.2/18.1
T 111.9/54.7
T 53.4/19.1
T 101.4/46.2
T 83.8/36.7
T 85.3/39.2
T
B 71.6/27.9
B 64.5/46.7
B
B 50.6/54.5
T
T 26.1/49.2
B 25.3/46.6
[MAIN UNIT]
REF ORDER
H/V
NO. NO.
C300 4030011600 S.CER C1608 JB 1E 104K-T
C301 4510008580 S.ELE EEE0JA470SR
C308 4030006900 S.CER C1608 JB 1H 103K-T
C309 4030011600 S.CER C1608 JB 1E 104K-T
C312 4030006860 S.CER C1608 JB 1H 102K-T
C313 4030011600 S.CER C1608 JB 1E 104K-T
C314 4030011600 S.CER C1608 JB 1E 104K-T
C315 4030006900 S.CER C1608 JB 1H 103K-T
C316 4030011180 S.CER GRM31M2C2H220JV01L
C317 4030006900 S.CER C1608 JB 1H 103K-T
C318 4030006900 S.CER C1608 JB 1H 103K-T
C319 4030006900 S.CER C1608 JB 1H 103K-T
98/38.7
C320 4030006900 S.CER C1608 JB 1H 103K-T
C321 4030006860 S.CER C1608 JB 1H 102K-T
C322 4510008690 S.ELE EEE1EA330SP
51.2/37
C323 4030006860 S.CER C1608 JB 1H 102K-T
C324 4030006860 S.CER C1608 JB 1H 102K-T
C325 4030011600 S.CER C1608 JB 1E 104K-T
C326 4550007390 S.TAN F931C225MAABMA
83.8/1.7
C327 4030006900 S.CER C1608 JB 1H 103K-T
C328 4030006900 S.CER C1608 JB 1H 103K-T
C329 4030006900 S.CER C1608 JB 1H 103K-T
C330 4030011110 S.CER GRM31M2C2H9R0DV01L
60.5/20
C331 4030011160 S.CER GRM31M2C2H150JV01L
C332 4030006900 S.CER C1608 JB 1H 103K-T
C333 4030006900 S.CER C1608 JB 1H 103K-T
85.4/85
C337 4030011600 S.CER C1608 JB 1E 104K-T
C338 4030011600 S.CER C1608 JB 1E 104K-T
C339 4030008470 S.CER C1608 JB 1H 272K-T
C340 4030011600 S.CER C1608 JB 1E 104K-T
C341 4030006900 S.CER C1608 JB 1H 103K-T
C342 4030006860 S.CER C1608 JB 1H 102K-T
C343 4510008500 S.ELE EEE1CA101WP
C344 4030009500 S.CER C1608 CH 1H 0R5B-T
C346 4030006960 S.CER C1608 CH 1H 050C-T
C347 4030011600 S.CER C1608 JB 1E 104K-T
C348 4030006900 S.CER C1608 JB 1H 103K-T
C349 4030008650 S.CER C1608 JB 1H 332K-T
C353 4030011600 S.CER C1608 JB 1E 104K-T
C354 4030011600 S.CER C1608 JB 1E 104K-T
C358 4030006990 S.CER C1608 CH 1H 080D-T
C359 4030007050 S.CER C1608 CH 1H 220J-T
87/46.5
C360 4030006860 S.CER C1608 JB 1H 102K-T
C361 4030006950 S.CER C1608 CH 1H 040C-T
C362 4030006860 S.CER C1608 JB 1H 102K-T
C366 4030006860 S.CER C1608 JB 1H 102K-T
C374 4030006860 S.CER C1608 JB 1H 102K-T
C378 4030006870 S.CER C1608 JB 1H 222K-T
8.9/71.1
C379 4550007270 S.TAN F931A475MAABMA
8.3/68.7
C380 4550007670 S.TAN F931C105MAABMA
C381 4030011600 S.CER C1608 JB 1E 104K-T
C382 4030006900 S.CER C1608 JB 1H 103K-T
C383 4550006390 S.TAN TEESVA 1C 335M8R
C384 4030011600 S.CER C1608 JB 1E 104K-T
C385 4030008900 S.CER C1608 JB 1H 333K-T
C387 4510008510 S.ELE EEE1CA471P
C388 4510008680 S.ELE EEE1EA220SP
C389 4030006860 S.CER C1608 JB 1H 102K-T
C390 4030011600 S.CER C1608 JB 1E 104K-T
C391 4030009500 S.CER C1608 CH 1H 0R5B-T
55.7/24
C392 4030007020 S.CER C1608 CH 1H 120J-T
C395 4030006950 S.CER C1608 CH 1H 040C-T
C403 4030012600 S.CER C2012 JB 1A 105M-T
37/51.7
C404 4030012610 S.CER C2012 JB 1C 474K-T
C405 4030009520 S.CER C1608 CH 1H 020B-T
C406 4030006960 S.CER C1608 CH 1H 050C-T
C407 4030009910 S.CER C1608 CH 1H 040B-T
C409 4030006860 S.CER C1608 JB 1H 102K-T
C410 4030006860 S.CER C1608 JB 1H 102K-T
C413 4550007540 S.TAN F931C155MAABMA
C415 4030007060 S.CER C1608 CH 1H 270J-T
C416 4030007030 S.CER C1608 CH 1H 150J-T
C417 4030006860 S.CER C1608 JB 1H 102K-T
C418 4030006860 S.CER C1608 JB 1H 102K-T
C419 4030017200 S.CER GRM31BR32J102KY01L
C420 4030006900 S.CER C1608 JB 1H 103K-T
C421 4030007050 S.CER C1608 CH 1H 220J-T
C422 4030007070 S.CER C1608 CH 1H 330J-T
65.1/30
C423 4030006970 S.CER C1608 CH 1H 060D-T
C424 4030007100 S.CER C1608 CH 1H 560J-T
C425 4030006900 S.CER C1608 JB 1H 103K-T
C426 4030009990 S.CER C1608 CH 1H 200J-T
C427 4030007080 S.CER C1608 CH 1H 390J-T
54.7/34
C428 4030006900 S.CER C1608 JB 1H 103K-T
C429 4030009550 S.CER C1608 CH 1H 2R5B-T
C430 4030006900 S.CER C1608 JB 1H 103K-T
C433 4510009280 S.ELE EEE1EA4R7SR
C434 4030006960 S.CER C1608 CH 1H 050C-T
C436 4510008540 S.ELE EEE1CA100SR
C437 4510008540 S.ELE EEE1CA100SR
87.9/40
C438 4030006900 S.CER C1608 JB 1H 103K-T
C439 4030007170 S.CER C1608 CH 1H 221J-T
C441 4510008500 S.ELE EEE1CA101WP
49.7/61
C442 4030006900 S.CER C1608 JB 1H 103K-T
C443 4030011600 S.CER C1608 JB 1E 104K-T
6.5/45.5
C444 4030006900 S.CER C1608 JB 1H 103K-T
C445 4510008500 S.ELE EEE1CA101WP
C446 4030010760 S.CER C1608 CH 1H 331J-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5
DESCRIPTION M.
LOCATION
B
T 18.8/49.4
B
B 103.9/7.9
B 28.1/83.8
B 21.2/71.8
B 22.6/71.8
B 104.5/45.6
B 89.2/96.8
T
B 123.1/46.8
B 120.7/52.9
T 112.5/47.2
T 69.8/16.8
T 66.4/20.9
B 78.7/31.4
B 93.4/35.1
T
B 91.4/10.7
B 128.3/9.6
B 123.2/9.6
B 114.1/62.1
B 123.8/105.8
B 119.2/109.5
T 128.9/52.3
T 128.9/49.5
B 28.8/67.4
B 33.9/62.6
B 68.7/24.9
B 63.2/36.1
B 100.5/3.9
T 131.7/68.9
T 41.6/72.7
T 126.4/47.5
T 114.9/56.4
B 71.6/14.3
B
B 48.5/31.8
B
B 44.4/60.6
B 124.9/62.2
B 130.1/64.8
B 133.5/62.2
T 126.4/54.7
B 122.6/74.5
T 127.6/80.3
B 41.6/72.8
B
B 32.5/73.5
B 30.8/78.2
B 41.5/77.3
B 14.9/84.3
B 13.9/90.5
B 21.6/78.8
B 51.4/28.9
T 23.3/73.2
T 14.5/89.3
T
B 109.1/38.2
T 89.9/46.5
T 122.1/59.7
T 122/43.6
B
B 31.1/88.7
B 131.7/68.2
B 128.3/68.2
B 111.5/67.4
B 93.4/46.9
B
B 47.6/107.6
B 101.7/53.9
B 103.2/53.9
B 76.2/53.8
T 55.2/82.5
B 75.8/81.9
T 55.9/23.7
T 112.7/39.4
T 110/39.4
T 110.8/37.2
T 113.5/34.1
T 113.5/32.8
T 109.4/31.5
T 108.4/28.7
T 107.1/28.7
B 82.1/31.8
T 115.3/29.6
T 129.4/15.4
B 118.5/47.5
T 30.3/37.6
T 11.1/33.8
T 12.8/36.9
B 15.5/41.2
T 12.4/50.8
T 16.7/53.8
B
T 16.6/25.2
T 21.4/27.2
T
S.=Surface mount
H/V
28.8/46
91/12.4
75.9/8
57.7/33
61/52.6
27/69.9
27/72.6
1.8/94.8
96.3/9.3
94.2/85
3/13.6
5.8/18.8
