Super Circuits PC508-IR2 User Manual

1/3 color weatherproof vandal day/night ccd camera with thermal heater

Advertisement

Quick Links

1.Do not touch the lens or view port glass directly.
2.Do not adjust lens in a wet enviroment to avoid damage to circuitry.
3.Do not install next to another light source as this may cause
light reflection.
4.Do not place hand between camera unit and upper sort as this
it may be caught in mechanism.
5.Do not hang the camera.
6.After loosening the screw the sunshade can be adjusted backwards
and forwards.
Make sure anti-tamper screw is securely screwes back into the slot
after adjustment.
7.After opening the front cover to adjust the focus, re-attach and
secure firmly in place to enxure that the unit remains watertight.
8.When assembly is complete, check that all screw in the unit are
properly secured.
Vandal
Model : PC508-IR2
PS: The Explanation of the Red Switch on IR board
Position ON
Real 500 Pound
Can resist external impacts of
over 500 lbs.
Anti-Tamper Protection
Installed using screws that require
special tools to install/remove.
Vandal Screw
Waterproofing
Unit is waterproofed to level IP 66
with anti-fogging double glass
design.
3-Axis &
`
Vandal-proofing
Support can rotate separately in
the XYZ axes
Vandal-proof design
40 IR
Can be equipped with 40 high
intensity infra-red LED lights.
OFF
Lux Enhancement
Glare-Elimination
1
(Default)
5 Seconds
15 Seconds
2
(Default)
Front Cover Anti-Tamper
Camera Unit
Plate x1
1
Wall Anchor Plastic
User Manual
Sheath x4
2
Sunshade
Wall Anchor x4
3
Base Anti-Tamper
Postitioning Sticker
Plate
Pipe Hole
4
T20 Hollow 6-Lobe
Base Anti-Tamper
Spanner x1
Screw x2
5
Auto Low Lux Mode
Enable IR light automatically
according to distance and
brightness.
IR Projection Distance
Long distance IR light.
Long Range
Auto Exposure
Compensation
Removes over-exposure for close
up shots.
Spot Elimination
Auto ICR
For low light conditions
automatically switches
IR Cut Filter on/off.
Dual Power Supply
Design
Dual power supply board provides
DC 12/AC 24V inputs optional
`
Description
Recommend to use under
the low Lux environment
ICR Delay Time
Note.
6
The Accessories Pack
contains parts No.4~10
7
8
9
10
(
) .
Note
