Jumper configuration
Booster Power Supply Manual
Technical Manuals Online! - http://www.tech-man.com
JP1 and JP2 are used to select a Class A or Class B NAC wiring
configuration. Both jumpers must be positioned to match the
SW1-5 DIP switch selection (Class A or Class B).
1
1
Class A
2
2
Class B
3
3
[Jumper.CDR]
JP1
JP2
Class A
Class B
7
