Note 1: A trouble on the
Booster will be sensed on the
existing fire panels NAC circuit
causing an NAC trouble on that
panel.
In an alarm condition, the
Booster will allow NAC current
to move downstream to
devices connected to the
existing fire panel's NAC
circuit.
Note 2: Refer to the connected
fire alarm control panel's
documentation for more details
on making NAC wiring
connections.
Booster Power Supply Manual
Technical Manuals Online! - http://www.tech-man.com

AC power wiring

Booster Power
Supply Main Board
Battery
P3
L N G P4 + -
[Power.CDR]
To dedicated 120 VAC
50/60 Hz branch circuit
250 watts for 6.5 amp Booster
or
375 watts for 10 amp Booster
220/230/240 VAC
50/60 Hz branch circuit
(-220 models only)

NAC Class B wiring

NAC1
Booster Power
Supply Main Board
NAC2
NAC3
NAC4
IN
Sense 1
COM
OUT
IN
Sense 2
COM
OUT
NO
Trouble COM
Battery
NC
P3 -
L N G P4 +
[NAC Class B.CDR]

NAC Class A wiring

NAC1
Booster Power
Supply Main Board
NAC2
NAC3
NAC4
IN
Sense 1
COM
OUT
IN
Sense 2
COM
OUT
NO
Trouble COM
Battery
NC
P3 -
L N G P4 +
[NAC Class A.CDR]
Per the NEC, no field wiring can
have a potential greater than 150 Vac
with respect to earth ground.
Notification Appliance Circuit (NAC)
Notification Appliance Circuit (NAC)
1
1
P1
To next signaling
Existing fire
device or NAC
alarm panel
2 end-of-line resistor
notification
NOTES:
1 Used for another Class B NAC circuit.
P2
2 Used to connect another input circuit
or signaling device.
Notification
Appliance
Circuit (NAC)
Notification
Appliance
Circuit (NAC)
P1
To next signaling
Existing fire
device or NAC
alarm panel
1
returning to existing
notification
fire alarm panel
NOTES:
P2
Used to connect another input circuit
1
or signaling device.
UL Listed
EOL 15 K
UL Listed
EOL 15 K
NAC
circuit
NAC
circuit
