General Signal Building BPS6 User Manual page 16

14
Technical Manuals Online! - http://www.tech-man.com
NAC1
Booster Power
Supply Main Board
NAC2
NAC3/
AUX1
NAC4/
AUX2
IN
Sense 1 COM
OUT
IN
Sense 2
COM
OUT
NO
Trouble
COM
Battery
NC
P3
L N G P4 + -
[APP-07.CDR]
NOTES:
1 Used for another Class B NAC circuit.
2 When a BPS output is programmed as
an AUX output, an EOL relay MUST be
used to supervise the AUX output.
NAC Circuit
1 1
1
From existing fire alarm
P1 panel notification circuit
or CC1 module
+
Out to EOL
+
or next device
+
P2
10 9
CC1
Module
+ + + +
8 7 6 5 4 3 2 1
Data in from
previous device or
Signature controller
+
10 9
CC1
Module
+ + + +
4 3 2 1
8 7 6 5
EOL
15 K
Data in from
2
previous device or
Signature controller
EOL
relay
CT1
Module
Data out to
next device
Data in from fire
alarm control panel
Booster Power Supply Manual
UL Listed
EOL 15 K
NAC Circuit
UL
Listed
EOL
47 K
Data out to
next device
NAC Circuit
UL
Listed
EOL
47 K
Data out to
next device
