Specifications

AC line voltage:
6.5 amp Booster
10 amp Booster
Sense voltage V (input)
Sense current I (input)
NAC output voltage
NAC output current
Wire size
NAC EOL
Auxiliary supv. current
Auxiliary outputs
Auxiliary outputs disabled
under battery
Battery Requirements
Battery charger current limit
Operating environment:
Operating temperature
Operating humidity

LED indicators

The Booster has six LED indicators. There are four NAC trouble
LEDs, one battery trouble LED, and one ground fault LED.
120 V / 220/240 Vac (50/60 Hz)
250 watts
120 V / 220/240 Vac (50/60 Hz)
375 watts
10 V – 45 V DC or 14 V - 32 V
FWR (unfiltered DC)
6 mA @ 24 Vdc, 3 mA @ 12 Vdc,
12 mA @ 45 Vdc
24 V nominal
(special application output
use only)
3.0 A max. per circuit, 10 A/6.5 A
max total all NACs
18 - 12 AWG
15 KΩ
6 amps max. (3 amps max./circuit)
2 (programmable), replaces NACs
Optional – programmable after 30
seconds
Up to 10 AH
1.0 A max.
O O
32 to 120 F (0 to 49 C)
0 to 93% RH
