Page 1: Table Of Contents
7.1 Network Setup……………………..….……………………. 7.2 FTP Setup…………………………………………………… 10 7.3 Video Setup………………………………..……………….. 12 7.4 Other Setup………………………………..……………….. 12 8. Using the PA17B1080P-5m...……………..…………………... 15 8.1 Play Media Files on the CF Card…………………………. 15 8.2 Download Function…………………………………………. 18 8.3 Play the Media Files on the PC…………………………… 21 8.4 Download/ Upload Media Files…………….………………... -
Page 2: Package Contents
FTP server With the VESA standard hole (100mm x 100mm), you can mount the PA17B1080P-5m on the wall. The Eyezone PA17B1080P-5m is an ideal Digital Signage Display solution for advertising,... -
Page 3: Hardware Overview
4. HARDWARE OVERVIEW 5. REMOTE CONTROL Power on/ off Select the output mode Numeric Key Delete last entry Select a function or to play the selected file Open the setup menu Mute sound OSD display function on/ off Auto-play function on/ off Mute sound Volume up/ down Move the cursor... -
Page 4: Start The Pa17B1080P-5M
In the settings screen, you can use the “▲、▼、 、 ” buttons to select an item, and press the media files on the CF card, the PA17B1080P-5m will auto play media files after power on. “ENTER” button to confirm the selection. -
Page 5: Ftp Setup
Step 1: Click on “Start” → “Run” and type in “command”, then press “ENTER”. (If you use the PA17B1080P-5m server, please disable the DHCP function and input a fixed IP The MS-DOS window will appear, type in “ipconfig” and then press “ENTER” to get the network address, Mask, Gateway and DNS of the PA17B1080P-5m) information. -
Page 6: Video Setup
Local HTTP Server: Enable/ Disable the HTTP command function. Moscow, Saint Petersburg, (GMT-10:00) Hawaii (GMT+03:00) Volgograd Local HTTP Server Setup: To set the “Port”, “User ID” and “Password” of the PA17B1080P-5m. (GMT-09:00) Alaska (GMT+03:00) Baghdad (The Default Port: 80, User ID: root, Password: admin) Pacific GMT (U.S. - Page 7 “2～5”) until the calibration point changes the color from red to yellow. Copy the file “HDPlayerSetting.txt” on CF card to your PC. Use the “Wordpad” to open the file, and you can see all the configuration value of PA17B1080P-5m. You can modify directly the configuration value on your PC.
-
Page 8: Using The Pa17B1080P-5M
8.1 PLAY MEDIA FILES ON THE CF CARD - First Press: Adjust the brightness. Step 1: Insert the CF card with media files, then turn on the PA17B1080P-5m and press the “ENTER” - Second Press: Adjust the contrast. button on the remote control when “’mnt/CF” is highlighted to take you into the CF card. -
Page 9: Download Function
PA17B1080P-5m is downloading files. After finishing downloading files, the PA17B1080P-5m will display the files automatically. Second Press：ZOOM 02 Third Press：ZOOM 03 Screen Saver 8.2.2 Auto Download Function If there is more than one PA17B1080P-5m, you can use ftp tools to divide them into different regional group. - Page 10 Please enter the “Time SETUP” window of PA17B1080P-5m, and set up the “Download Time”, then the PA17B1080P-5m will download all the files from the FTP server at the designated time. NOTE: The filename of the media files in FTP server cannot have any spaces.
-
Page 11: Play The Media Files On The Pc
8.3 PLAY THE MEDIA FILES ON THE PC Step 5: Click the “Library” tab, and then click “Media Sharing”. Using Windows Media Player Version 11 (Windows XP/ Vista only) Step 1: Please download and install Windows Media Player Version 11 on your PC first. Step 2: Launch the Windows Media Player Version 11 and the window below will appear. -
Page 12: Download/ Upload Media Files
8.4 DOWNLOAD / UPLOAD MEDIA FILES Method 1: Connect by IE Browser Step 9: The shared folder will appear on the screen of the PA17B1080P-5m. Select the folder and click the “ENTER” button on remote control to go into the folder. - Page 13 - Select the files you want upload to the PA17B1080P-5m, or download the files to your PC. Step 6: After logging on, all the media files in the CF card on the PA17B1080P-5m will be listed. You can download and upload the media files between CF card and your PC.
-
Page 14: Http Command Function
(Default User Name: root, Default Password: admin) to log on. After logging on all the media files in the CF card on the PA17B1080P-5m will be listed. You can download and upload the media files between CF card and your PC. -
Page 15: Network Setup
PA17B1080PW). DHCP: Enable/ Disable the DHCP function. IP Address: Enter the fixed IP address, Mask, Gateway and DNS for the PA17B1080P-5m. FTP Server: Enable/ Disable the FTP Server function. You can also change the User ID, Password and port of the FTP Server. -
Page 16: Touch Screen Function
For Example: Introduction of Restaurant Step5: Copy all the files (include 1 default file and 21 media files) to the CF card, and insert to PA17B1080P-5m. Step2: Using the movie production software to create the media file which show the 10 division buttons (layer 2), and name the file “001.xxx”. -
Page 17: Troubleshooting
Step3: Press the SETUP button to save and quit the settings screen, and restart the PA17B1080P-5m. 11. TROUBLESHOOTING Step5: The PA17B1080P-5m will auto play the default file (000.xxx) repeatedly after power on. Touch the screen anywhere to play the file 001 (layer 2).
