EYEZONE B1080P-5
User Manual
Jun 12, 09
3 4 4 8 1 2 0
FCC Notices
It's herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is
subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
residential installation. This equipment generated uses and can radiate radio frequency
energy and if not installed and used in accordance with the instruction manual may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio of television reception, which can be determined by turning the
equipment off or on, the user is encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio TV technician for help.
CE Declaration
This device complies with CE class B.
EN55022
EN61000-3-2
EN61000-3-3
EN55024
IEC 61000-4-2
IEC 61000-4-3
Printed in Taiwan R.O.C.
All contents are subject to change without notice.
All trademarks are the property of their respective owner.
1
2
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B1080P-5 and is the answer not in the manual?

Questions and answers

Related Manuals for EYEZONE B1080P-5

Summary of Contents for EYEZONE B1080P-5

  • Page 1 FCC Notices EYEZONE B1080P-5 It’s herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. User Manual This device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Table Of Contents

    FJ Display is pleased to introduce the latest in Digital Signage technology. The Eyezone 9.2 Download Function…………………………..……………. 23 B1080P-5 is a full-featured digital signage that access to the Internet via 3.5G anywhere, anytime. 9.3 Play the Media Files on the PC…………………………… 26 The B1080P-5 can easily access to the Internet via 3.5G for automatically transmitting and...

  • Page 3: Features

    Exports the Configuration Value: You can export the configuration value to the CF card. The configuration can be modified on your PC, and can be applied to the B1080P-5 or others. Compatible with Windows Media Player 11: Play media files stored in a network computer.

  • Page 4: Remote Control

    Status 1: If the “AUTOPLAY (Movie, Picture or All Files)” function is enabled and there are OSD display function on/ off movie or picture files in the CF card, the Eyezone B1080P-5 will auto play movie or picture Auto-play function on/ off files on the CF card after power on.

  • Page 5: Setting Up

    IP Assigned by DHCP: If you have a DHCP-enabled router, please select “On”, and then the router will automatically assigns an IP address to the Eyezone B1080P-5. If you don’t have a DHCP –enabled router, select “Off” and type the network information in “Assign IP Address”.

  • Page 6: Ftp Setup

    Continental GMT (U.S. & (GMT-07:00) (GMT+03:30) Tehran Local FTP Server: Turn on/ off the Eyezone B1080P-5 server. Canada) (If you use the Eyezone B1080P-5 server, please disable the DHCP function and input a fixed (GMT-07:00) Arizona (GMT+04:00) Baku, Tbilisi, Ere van (GMT-06:00)

  • Page 7: Video Setup

    Aspecl-ratio: Select TV mode 4:3, 16:9 or 16:10. HDMI: Select the HDMI output resolution among 480i / 480p/ 720p / 1080i/ 1080p. Select the “Auto EDID”, the Eyezone B1080P-5 will scan the display device connected and set the correct resolution automatically.

  • Page 8: G Setup

    Copy the completed file “HDPlayerSetting.txt” from PC to CF card. Insert the CF card to the B1080P-5, the B1080P-5 will apply the new settings automatically. Play Button: Only for used with play buttons. The Eyezone B1080P-5 supports two options (Repeat Default / Repeat All) when the demo file finishes playing.

  • Page 9: Connection

    Step1. Insert the CF card with the completed file “HDPlayerSetting.txt” to the B1080P-5. 8.1 SETTING UP Step2. Turn on the B1080P-5, and it will dial-up and connect to cell phone system network automatically. Supports HSDPA, UMTS & GPRS System If the Dial-up process is successful, the following screen will display.

  • Page 10: Setup The Ddns Function

    9.1 PLAY MEDIA FILES ON THE CF CARD Step 1: Insert the CF card with media files, then turn on the Eyezone B1080P-5 and press the “ENTER” button on the remote control when “’mnt/CF” is highlighted to take you into the CF card.
  • Page 11 9.1.1 Using the Remote Control When Media File Is Playing PAUSE/STEP: Pause the playback or play frame by frame. SETUP: Press the button to adjust the brightness, contrast or saturation while the movie or picture ZOOM: Zoom in/ out on the movie or picture. is playing.

  • Page 12: Download Function

    Time”, then the Eyezone B1080P-5 will download all the files from the FTP server at the designated time. 9.2.2 Auto Download Function If there are more than one Eyezone B1080P-5, you can use ftp tools to divide them into different regional group. NOTE: The filename of the media files in FTP server cannot have any spaces.

  • Page 13: Play The Media Files On The Pc

    Step 3: Click the “Library” tab, and then click “Add to Library”. NOTE: f the network connection is unstable or broken, a pop-up window will appear as shown below. The Eyezone B1080P-5 will attempt to resume downloading in 2 minutes. The user can terminate the download by pressing the “RETURN” button.
  • Page 14 Step 5: Click the “Library” tab, and then click “Media Sharing”. Step 8: Confirm that the Eyezone B1080P-5 is connected to the network. In the list of devices below the “Share my media to” check box, select the device (Eyezone B1080P-5), and click “Allow” to share the media files.

  • Page 15: Download/ Upload Media Files

    Setup” item, and type IP Address (example. 192.168.1.100), Mask and Gateway for the Eyezone B1080P-5 (refer to 7.1). Step 6: After logging on, all the media files in the CF card on the Eyezone B1080P-5 will be listed. You can download and upload the media files between CF card and your PC.

  • Page 16: Rs-232 Function

    Use the tool “Tera Term” or other tools to control the Eyezone B1080P-5 with ASCII command. For example. NOTE. 1.Baud Rates: - If there are multiple Eyezone B1080P-5, you can use the “CuteFTP” tool to connect and manage files - Firmware Updating: Set up the baud rate as “115200”. easily.

  • Page 17: Http Command Function

    Confirm the “Local HTTP Server” function has been enabled, and the “Local HTTP Server Setup” set has been completed (refer to 7.2). Set your router or firewall, and open a port 80 for the Eyezone B1080P-5. The following figure is an example, please refer to your user’s manual of router for opening ports.

  • Page 18: Network Setup

    (Default User Name: root, Default Password: admin) to log on. After logging on all the media files in the CF card on the Eyezone B1080P-5 will be listed. You can download and upload the media files between CF card and your PC.

  • Page 19: Timer Setup

    Auto Power: Enable/ disable the auto power on/ off function and set the time of power on/ off. Execute the program “FJ Display” to open the “FJ Schedule Generator” window on your PC. Reboot System: After setting, click “Send” to reboot the B1080P-5. <Start> → <Programs> → <FJ Display> → < FJ Schedule Generator >...
  • Page 20 After the setup, press the “SAVE” button, and a pop-up window will appear. Select the path, then click the “SAVE” button to save your setup. NOTE: Do not rename the file (eyezone.ini), otherwise the B1080P-5 will not be able to read the file.
  • Page 21 Step 1: Click the “Add” button in the “Time Setup” section to open the “Advance Schedule Editor” NOTE: Do not rename the file (eyezone.ini), otherwise the B1080P-5 will not be able to read the file. window. Set up the Start and Stop Date, Start and Stop Time and the Week Day, then click “OK” to quit the window.

  • Page 22: Apply The Schedule On The B1080P-5

    Demo File 4：a01.xxx Demo File 5：b55.xxx Step 2: Insert the CF card to the Eyezone B1080P-5, and the Eyezone B1080P-5 will play the default file automatically while powered on. Step 3: Press one of the buttons 1-5 to play the corresponding demo file.

  • Page 23: Pir Sensor

    12.4.3 Connect to the Touch-Sensor Buttons Step 1: Connect the PIR sensor to the B1080P-5, and insert the CF card with media contents to the Open the battery cover and set the batteries (AA size) as shown below. Please note that the Eyezone B1080P-5.

  • Page 24: Troubleshooting

    13. TROUBLESHOOTING Situation Check Point Insert the CF card before turning on the B1080P-5. Check power cable and power switches. Ensure the video cables are connected between the player and the Eyezone B1080P-5. No Picture Press the “TV MODE” button on the remote control to select the correct output mode.
