Page 1: Table Of Contents
PROFESSIONAL WEATHER CENTER WS-1510-IT Instruction Manual Table of Contents Topic Page Features Setting up Function keys LCD Screen Manual Setting Time alarm setting Weather alarm operations Hysteresis Weather forecast and weather tendency Wind direction and wind speed measurement Rainfall measurement... -
Page 2: Features
PROFESSIONAL WEATHER CENTER WS-1510-IT Instruction Manual Congratulations on purchasing this state-of-the-art Professional Weather Center as an example of excellent design and innovative technology. Featuring time, date, calendar, weather forecast, wind direction and speed, rainfall, indoor temperature, outdoor temperature and outdoor humidity, air pressure and various alarm settings for different weather conditions, this Weather Center will provide you with extensive weather information and forecast. -
Page 3: Setting Up
Thermo-hygro Sensor • Remote transmission of the outdoor temperature and humidity to the Weather Center at 915 MHz Weather-resistant casing • Wall mounting case (to be mounted in a sheltered place. Avoid direct rain and sunshine) • Wind Sensor Connected to the thermo-hygro sensor by cable •... - Page 4 Note: The radio communication between the receiver and the transmitters in the open field reaches distances of max 330 feet, provided there are no interfering obstacles such as buildings, trees, vehicles, high voltage lines, etc. Radio interferences created by PC screens, radios or TV sets can in some cases entirely cut off radio communication. Please consider this when choosing standing or mounting locations.
-
Page 5: Function Keys
FUNCTION KEYS: Weather Center: The Weather Center has 5 easy-to-use function keys. MIN/MAX + key HISTORY key ALARM key SET key • Press and hold to enter manual setting modes: LCD contrast, Manual time setting, 12/24 hour time display, Calendar setting, ºF/ ºC temperature unit, Wind speed unit, Rainfall unit, Pressure unit, Relative pressure reference setting, Weather tendency threshold setting, Storm warning threshold setting and Storm Alarm On/ Off setting Press to toggle between the display of Mode 1 or Mode 2:... -
Page 6: Manual Setting
Mode 1 : Wind speed, outdoor temperature and relative pressure reading are shown. Wind speed icon Outdoor temp In Mode 1, this reception icon icon is showing the condition of the reception of the signal Rel Pressure from Thermo-hygro icon transmitter Mode 2 : Wind Gust, Dew Point temperature and 24 Hour and Total Rainfall... -
Page 7: Weather Alarm Operations
°F/°C TEMPERATURE UNIT SETTING Flashing The temperature display can be selected to show temperature data in °F or °C. (default °F) The temperature unit is flashing Use the + or MIN/MAX key to toggle between “°F” or “°C”. Confirm with the SET key and enter the WIND SPEED UNIT SETTING. WIND SPEED UNIT SETTING Flashing The wind speed unit can be set as mph (mile per hour), km/h (kilometer per hour), or m/s (meter per second). - Page 8 TO EXIT THE MANUAL SETTING MODE To exit the manual setting anytime during the manual setting modes, press the ALARM key (or HISTORY key) or wait for the automatic timeout. The mode will return to the normal time display. TIME ALARM SETTING The alarm time can be set by the use of the ALARM and SET key.
-
Page 9: Hysteresis
HIGH AND LOW OUTDOOR HUMIDITY ALARM SETTING Note: The High and Low outdoor humidity alarm can be set On/Off independently according to your needs. Set the Outdoor temperature alarm value (High or Low alarm value): In the normal display mode, press the ALARM key 4 times. The High Outdoor Humidity alarm display will be shown. Press and hold the SET key for about 2 seconds. -
Page 10: Wind Direction And Wind Speed Measurement
AIR PRESSURE HISTORY (ELECTRONIC BAROMETER WITH BAROMETRIC PRESSURE TREND) The bottom section of the LCD also shows the relative air pressure value and the air pressure history. Depending on programming conditions, display of the history of air pressure is in the form of a graph consisting of vertical bars. -
Page 11: Viewing The Min/ Max Weather Data
To view the weather history: In normal display, press the HISTORY key. The latest weather record will be shown with the date and time of recording. The "HISTORY" icon will be displayed at the bottom of the LCD. When viewing History records, user may shift to see the Mode 1 or Mode 2 data by pressing the SET key. (Mode 1: with wind speed + outdoor Temp + Rel. - Page 12 Min Wind chill temperature with the date and time of recording Time and date of recording MIN wind chill value MIN icon Max Wind chill temperature with the date and time of recording Min Relative pressure with the date and time of recording Max Relative pressure with the date and time of recording Time and date or recording...
-
Page 13: Switch On/ Off Buzzer
RESET THE MAXIMUM AND MINIMUM WEATHER DATA To reset the aforementioned maximum or minimum weather data 1. to 13., you shall need to reset each of the data independently. Press MIN/MAX key to show the desired weather data. For instance, if you want to reset the minimum humidity, in the normal display you shall press the MIN/MAX key three times to show the min humidity value. -
Page 14: Positioning
LA CROSSE TECHNOLOGY SENSOR EXTENSION CABLE When you require additional length to properly mount your sensor, you can use a La Crosse Technology extension cable. The extension cable is 32 feet in length and comes with the appropriate connecter attached. Please visit your local retailer or www.greatbigoutlet.com to purchase. -
Page 15: Care And Maintenance
Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center. La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. -
Page 16: Faq
FAQ WS-1510-IT Congratulations on purchasing this state-of-the-art Professional Weather Center. Remember, for your Weather Station to work properly, it must be started correctly, using good quality alkaline batteries, and the time must be set manually. Before calling for technical support (1-888-211-1923), you may be able to correct the problem by first performing a Proper Restart, an Initial Set-up, and problem-solving with the trouble-shooting guide. - Page 17 SETTING THE MONTH MANUALLY: The Month will be flashing. Use the PLUS or MIN/MAX button to set the month. Press and release the SET button once to move to the next menu item. SETTING THE DATE MANUALLY: The numeric day will be flashing. Use the PLUS or MIN/MAX button to set the date correctly. (The unit will determine the Day of the week automatically.) Press and release the SET button once to move to the next menu item.
- Page 18 Mounting: Is the rain gauge mounted level? If mounted with screws through the base, please be sure they are only snug and not too tight. Accuracy Test: To test any La Crosse Technology rain gauge, follow these steps: Erase the Total rainfall or make note of this amount.
- Page 19 Turn Alarms ON or OFF: An alarm icon ((●)) will appear next to the alarm value set. This indicates the alarm is turned ON. To turn the alarm off Press and hold ALARM button for about 5 seconds until the alarm time shows in the date area. Press and release the ALARM button to move to Outdoor Temperature high alarm, Outdoor Temperature low alarm, Outdoor Humidity high alarm, Outdoor Humidity low alarm, and Wind Speed high alarm.
