PROFESSIONAL WEATHER CENTER
WS-1611
Operation Manual
PROFESSIONAL WEATHER CENTER
Instruction Manual
Congratulations on purchasing this state-of-the-art Professional Weather Center as an
example of excellent design and innovative technology. Featuring time, date,
calendar, weather forecast, wind direction and speed, rainfall, outdoor temperature
and outdoor humidity, air pressure and various alarm settings for different weather
conditions, this Weather Center will provide you with extensive weather information
and forecast.
This product offers:
INSTANT TRANSMISSION is the
state-of-the-art new wireless
transmission technology, exclusively
designed and developed by LA
CROSSE TECHNOLOGY. INSTANT
TRANSMISSION offers you an
immediate update (every 4.5
seconds!) of all your outdoor data
measured from the sensors: follow
your climatic variations in real-time!
2
Table of Contents
Topic
Features
Setting up
Function keys
LCD Screen
Manual Setting
Time alarm setting
Weather alarm operations
Hysteresis
Weather forecast and weather tendency
Wind direction and wind speed measurement
Rainfall measurement
Viewing history data
Viewing the min/ max weather data
Switch On/ Off buzzer
Outdoor transmission 915 MHz reception
Positioning
Care and Maintenance
Specification
Warranty Information
FEATURES:
Weather Center
LCD
Display
Function
keys
•
Time display (manual setting)
•
12/24 hour time display
•
Calendar display (weekday, date, month, year)
•
Time alarm function
•
Weather forecasting function with 3 weather icons and weather tendency
indicator
•
Outdoor temperature display in ºF/°C
•
Outdoor Humidity display as RH%
Page
3
6
12
15
17
25
26
32
33
37
38
38
40
47
49
50
54
55
57
1
Hanging hole
Battery
compartment
cover
Stand
3

Advertisement

Table of Contents
loading

Related Manuals for La Crosse Technology WS-1611

Summary of Contents for La Crosse Technology WS-1611

  • Page 1 Table of Contents PROFESSIONAL WEATHER CENTER Topic Page WS-1611 Features Operation Manual Setting up Function keys LCD Screen Manual Setting Time alarm setting Weather alarm operations Hysteresis Weather forecast and weather tendency Wind direction and wind speed measurement Rainfall measurement...
  • Page 2 • MIN/MAX value of outdoor temperature and humidity display with time & date Thermo-hygro Sensor of recording • • Low/High outdoor temperature and humidity alarm Remote transmission of the outdoor temperature and humidity • Relative air pressure displayed in inHg or hPa to the Weather Center at 915 MHz •...
  • Page 3 Afterwards, the Weather Center will start receiving data from the sensor. The The thermo-hygro sensor should be placed in a dry, shaded area. The temperature outdoor temperature, humidity wind chill and wind speed should then be sensor has a range of 330 feet. Keep in mind that the 330 feet is in open air with no displayed on the Weather Center.

  • Page 4: Battery Change

    hygro sensor at start-up and this code must be received and stored by the Weather Center in the first 30 seconds of power being supplied to it. BATTERY CHANGE: It is recommended to replace the batteries in all units every 24 months to ensure SET key optimum accuracy of these units.

  • Page 5: Manual Setting

    Low battery indicator MANUAL SETTING: Time alarm icon The following manual settings can be changed once the SET key is pressed: • LCD contrast setting Time display • Manual time setting Calendar display • 12/24 hour time display Buzzer off indicator •...
  • Page 6 °F/°C TEMPERATURE UNIT SETTING RAINFALL UNIT SETTING Flashing Flashing The temperature display can be selected to show temperature data in °F or °C. (default °F) The total rainfall unit can be set as inch or mm. The default unit is inch. The temperature unit is flashing Use the + or MIN/MAX key to toggle between the unit “inch”...

  • Page 7: Storm Warning Threshold Value Setting

    STORM WARNING THRESHOLD VALUE SETTING Note: You may also define a switching sensitivity value for the storm warning display at a In case a storm warning alarm is activated, the downward weather tendency arrow will decrease of air pressure from .09 inHg to .27 inHg over 6 hours (Default 0.15 inHg). be flashing.
  • Page 8 Default alarm values: Press and hold the SET key for about 2 seconds. The temperature digit will start flashing. Press the + or MIN/MAX key to set the high outdoor temp alarm 32°F value. (Keep holding the key will allow the value to increase faster.) Temperature High 104°F...

  • Page 9: Weather Tendency Indicator

    Press the ALARM key once to return to the normal display mode. WEATHER FORECAST AND WEATHER TENDENCY WEATHER FORECASTING ICONS: In case the wind speed exceeds the condition for high wind speed alarm, the value Weather forecasting icons is displayed in any of the following combinations at the right will be flashing, along with the corresponding high alarm icon ("HI AL").

  • Page 10: Wind Direction And Wind Speed Measurement

    instance from the ground to the second floor of the house, the readings for the next 12-24 hours shall be discarded. WIND DIRECTION AND WIND SPEED MEASUREMENT In normal display mode, the second section of the LCD shows the following wind data. •...

  • Page 11: Viewing The Min/Max Weather Data

    Press MIN/ MAX to view older records. Min outdoor temperature with the date and time of recording (Press MIN/MAX and + key to view "Previous" and "Next" record respectively. Time and date or The records are made at 3-hour intervals) recording Note: •...

  • Page 12: Reset The Min/Max Weather Data

    Max relative pressure with the date and time of recording Maximum wind speed Time and date or recording Time and date or recording MAX wind speed value MAX relative pressure value MAX icon MAX icon RESET THE MIN/MAX WEATHER DATA To reset the aforementioned MIN/MAX weather data 1.

  • Page 13: Low Battery Indicator

    OUTDOOR SENSOR 915 MHz RECEPTION The outdoor temperature, humidity, wind data and rainfall are transmitted from the thermo-hygro sensor about every 4.5 seconds. The Weather Center will then be synchronized to the thermo-hygro sensor to receive outdoor data. The transmission range (up to 330 feet) of the thermo-hygro Sensor may be affected by the ambient BUZZER OFF icon temperature.

  • Page 14: Care And Maintenance

    An ideal mounting place for the thermo-hygro sensor would be the outer wall beneath Firstly, check that the wind-fan and the wind-vane can rotate freely before fixing the the extension of a roof, as this will protect the sensor from direct sunlight and other unit.

  • Page 15: Liability Disclaimer

    La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center. the quality of environment. La Crosse Technology, Ltd will repair or replace this product, at our option and at no • As stated on the gift box and labeled on the product, reading the “User manual”...
  • Page 16 This handbook may contain mistakes and printing errors. The information in this handbook is regularly checked and corrections made in the next issue. We accept no liability for technical mistakes or printing errors, or their consequences. All trademarks and patents are acknowledged.
