PROFESSIONAL WEATHER CENTER
WS-1613-IT
Operation Manual
IMPORTANT:
When a battery change is required on any of the units of this set, ALL units
have to be reset and user must go through initial set-up steps again.
FEATURES:
LCD
•
Time display (manual setting)
•
12/24 hour time display
•
Calendar display (weekday, date, month, year)
•
Time alarm function
•
Weather forecasting function with 3 weather icons and weather tendency
indicator
•
Outdoor temperature display in ºF/°C
•
Outdoor Humidity display as RH%
•
MIN/MAX value of outdoor temperature and humidity display with time & date of
recording
3
Table of Contents
Topic
Features
Function keys
LCD Screen
Time alarm setting
Weather forecast and weather tendency
Viewing history data
Viewing the min/ max weather data
Switch On/ Off buzzer
Outdoor transmission 915 MHz reception
Specification
Warranty Info
•
Low/High outdoor temperature and humidity alarm
•
Relative air pressure displayed in inHg or hPa
•
Air pressure tendency indicator for the past 12 hours (bargraph format)
•
LCD contrast selectable
Foldout stand
•
Low battery indicator
•
Hanging hole
Wind direction displayed in 16 steps
•
Wind speed displayed in mph, km/h, or m/s, and Beaufort scale
Battery compartment
Wind chill displayed in °F of °C
•
cover
•
Max wind speed displayed with time & date of recording
•
High alarm function for wind speed
•
Manual reset of outdoor temperature/ humidity, pressure and wind chill data
•
Total rainfall displayed in mm or inch
•
Storm warning alarm
•
Buzzer on/off selectable
•
Storage of 200 sets of history weather data recorded in 3-hour intervals
•
Wireless transmission at 915 MHz
•
Transmission range up to 330 feet (100 meters)
Thermo-hygro Sensor
•
•
•
Page
3
6
12
14
16
24
25
31
32
36
37
37
39
46
48
49
53
54
56
1
Remote transmission of the outdoor temperature and humidity
to the Weather Center at 915 MHz
Weather-resistant casing
Wall mounting case (to be mounted in a sheltered place. Avoid
direct rain and sunshine)
4
PROFESSIONAL WEATHER CENTER
Instruction Manual
Congratulations on purchasing this state-of-the-art Professional Weather Center as an
example of excellent design and innovative technology. Featuring time, date,
calendar, weather forecast, wind direction and speed, rainfall, outdoor temperature
and outdoor humidity, air pressure and various alarm settings for different weather
conditions, this Weather Center will provide you with extensive weather information
and forecast.
This product offers:
INSTANT TRANSMISSION is the
state-of-the-art new wireless
transmission technology, exclusively
designed and developed by
CROSSE TECHNOLOGY. INSTANT
TRANSMISSION offers you an
immediate update (every 4 seconds!)
of all your outdoor data measured
from the transmitters: follow your
climatic variations in real-time!
2
Wind Sensor
•
Connected to the thermo-hygro sensor by cable
•
Can be installed onto a mast or a horizontal panel
Rain Sensor
•
Connected to the thermo-hygro sensor by cable
•
To be mounted onto a horizontal panel
5
LA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for La Crosse Technology WS-1613-IT
Summary of Contents for La Crosse Technology WS-1613-IT
- Page 1 PROFESSIONAL WEATHER CENTER WS-1613-IT Operation Manual IMPORTANT: When a battery change is required on any of the units of this set, ALL units have to be reset and user must go through initial set-up steps again. FEATURES: Weather Center Foldout stand...
- Page 2 SETTING UP: Wireless transmission at 915 MHz - thermo- hygro sensor to the Weather Center Weather Center Rain sensor Wind sensor Cable connection Cable connection between the rain sensor between the wind sensor and the thermo-hygro and the thermo-hygro sensor sensor Note: The radio communication between the receiver and the transmitter in the open field...
- Page 3 The Bonus Receiver use 2 x AA, IEC LR6, 1.5V batteries. When the batteries need to be replaced, the low battery symbol will appear on the LCD. To install and replace the batteries, please follow the steps below: Remove the battery compartment cover. Insert the batteries observing the correct polarity (see the marking in the battery compartment).
- Page 4 CALENDAR SETTING: "Date. Month." (for 24h time display) "Month. Date." (for 12h time display) Year The date default of the Weather Center is 1. 1. of year 2005. The date can be set manually by proceeding as follows. The year digit starts flashing. Use the + or MIN/MAX key to set the year.
- Page 5 Press and hold the SET key for about 2 seconds. The hour digit of the alarm time will start flashing. Press the + or MIN/MAX key to set the hour of the alarm time. Press the SET key to confirm and advance to the minute setting. The minute digit will be flashing.
- Page 6 drops to +76.8°F (24.9°C) or below and thereafter again increases to beyond +77°F (25°C), the data will be blinking, but no alarm will be activated. It has to drop to below +75.2°F (24°C) (with a pre-set hysteresis of 1.8°F (1°C)) so that the alarm can be produced again.
- Page 7 To view the weather history: Press the HISTORY key. The latest weather record will be shown with the date and time of recording. The "HISTORY" icon will be displayed at the bottom of the LCD. HISTORY icon Press MIN/ MAX to view older records. (Press MIN/MAX and + key to view "Previous"...
- Page 8 Press and hold the SET key for about 2 seconds, then the "RESET" icon will appear at the bottom part of the LCD. Press the + key once, then the stored value will be reset to the current value and current time. Press the ALARM key to return to normal display mode.
- Page 9 mounted using the screw or cable tie provided onto a solid wall/ panel mast or mast to allow the wind to travel around the sensor unhindered from all directions (ideal mast size should be from diameter about ” (16 mm) to 1 ”...
- Page 10 No part of this manual may be reproduced without written authorization of the manufacturer. WARRANTY For warranty work, technical support, or information contact: La Crosse Technology, Ltd Springfield / Lacrosse Canada. 2809 Losey Blvd. South 1-800-661-6721 La Crosse, WI 54601 5151 Thimens Rd.
